1
Introduction
Expansion Slots
The mainboard is equipped with 1 universal AGP slot and 5 PCI
slots.
AGP is an interface designed to support high performance 3D
graphics cards. It utilizes a dedicated pipeline to access system
memory for texturing, z-buffering and alpha blending. The universal
AGP slot supports AGP 2x with up to 533MB/sec. bandwidth and
AGP 4x with up to 1066MB/sec . bandwidth for 3D graphics
applications. AGP in this mainboard will deliver faster and better
graphics to your PC.
Onboard Audio Features
• Supports Microsoft
• AC'97 supported with full duplex, independent sample rate
converter for audio recording and playback
Onboard LAN Features (PE11-TL only)
• Integrated LAN controller
• Integrated IEEE 802.3, 10BASE-T and 100BASE-TX compatible
PHY
• 32-bit PCI master interface
• Integrated power management functions
• Full duplex support at both 10 and 100 Mbps
• Supports IEEE 802.3u auto-negotiation
• Supports wire for management
Rear Panel I/O Ports (PC 99 color-coded connectors)
• Two USB 2.0/1.1 ports
• One RJ45 LAN port (PE11-TL only)
• Two DB-9 serial ports
• One DB-25 parallel port
• One mini-DIN-6 PS/2 mouse port
• One mini-DIN-6 PS/2 keyboard por t
• One game/MIDI port
• Three audio jacks: line-out, line-in and mic-in
8
®
DirectSound/DirectSound 3D
