1
Introduction
Desktop Management Interface (DMI)
The mainboard comes with a DMI 2.0 built into the BIOS. The DMI
utility in the BIOS automatically records various information about
your system configuration and stores these information in the DMI
pool, which is a part of the system board's Plug and Play BIOS.
DMI, along with the appropriately networked software, is designed
to make inventor y, maintenance and troubleshooting of computer
systems easier. Refer to chapter 4 for instructions on using the DMI
utility.
1.1.2 Intelligence
Dual Function Power Button
Depending on the setting in the "Soft-Off By PWRBTN" field of the
Power Management Setup, this switch will allow the system to enter
the Soft-Off or Suspend mode.
Wake-On-Ring
This feature allows the system that is in the Suspend mode or Soft
Power Off mode to wake-up/power-on to respond to calls coming
from an external modem or respond to calls from a modem PCI
card that uses the PCI PME (Power Management Event) signal to
remotely wake up the PC. Refer to "Resume On LAN/Ring" ("IRQ/
Event Activity Detect" field) in the Power Management Setup section
in chapter 3 for more information.
Wake-On-LAN
The Wake-On-LAN function allows the network to remotely wake
up a Soft Power Down (Soft-Off) PC . Your LAN card must support
the remote wakeup function. Refer to "Wake-On-LAN Connector" in
chapter 2 and "Resume On LAN/Ring" ("IRQ/Event Activity Detect"
field) in the Power Management Setup section in chapter 3 for more
information.
10
Important:
If you are using a modem add-in card, the 5VSB power source
of your power supply must support ≥720mA.
