How to Set Up Your CBA750B 3G/4G Wireless WAN Bridge
The CBA750B mobile broadband series adapters enable easy-to-install wireless
WAN connectivity in fixed business locations.
The CBA750B 3G/4G wireless WAN bridge appliance provides wireless
connectivity as either a backup or primary connection for branch SRX Series
Services Gateways.

Front Panel

4G LTE
Reserved
Power
WIMAX
(future use)
LAN
3G HSPA+
2G 1XRTT
Failover
EVDO UMTS
Edge GPRS

Left Side Panel

local device LAN
WAN data
Signal
Power over
activity
strength
Ethernet
Router/
Status
Passthrough
(USB/ExpressCard
mode
modem)
Computer or
Power
Power
switch
(12V)
Reset

Package Contents

CBA750B
Power supply adapter
Warranty and Registration
• End-User License Agreement
Information
• Safety Guide
• Quick Start Guide

Right Side Panel

Router/Passthrough
switch
(3G/4G modem ports)
ExpressCard slot
ExpressCard lock
Mounting hardware
Ethernet cable
USB
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CBA750B and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Juniper CBA750B

Summary of Contents for Juniper CBA750B

  • Page 1: Package Contents

    How to Set Up Your CBA750B 3G/4G Wireless WAN Bridge Package Contents The CBA750B mobile broadband series adapters enable easy-to-install wireless WAN connectivity in fixed business locations. The CBA750B 3G/4G wireless WAN bridge appliance provides wireless connectivity as either a backup or primary connection for branch SRX Series Services Gateways.
  • Page 2 Insert the screws into the modem and insert antennas (finger-tight only). 2. Plug the power supply into an electrical outlet. 3. Connect the power supply to the CBA750B and switch the device on (I). How to Set Up Your CBA750B 3G/4G Wireless WAN Bridge...
  • Page 3 Access the Administration Pages The CBA750B can be used immediately without any configuration changes. If you want to configure any of the advanced features, log in to the administration pages. To access the administration pages: Open a browser window and type cp/ or 192.168.0.1 in the address bar.

  • Page 4: Update The Firmware

    To restore the CBA750B to its factory default settings, press and hold the update the firmware to use the CBA750B with new modems and to access the RESET button on the side of the device for ten seconds. Reset returns the login latest features.

  • Page 5: Regulatory And Safety Information

    7.5 dBi in the cellular band, 3 dBi in the PCS band, 5.5 tout brouillage reçu, y compris un brouillage susceptible de provoquer un dBi in LTE Band 4, and 9 dBi in LTE Band 17. For the CBA750B-W the maximum fonctionnement indésirable.
  • Page 6 Products made or sold by Juniper Networks or components thereof might be covered by one or more of the following patents that are owned by or...
