• BLADE
We strongly recommend that the blades (smooth
ones) are sharpened daily using sharpening stone
supplied with machine.
The quality of the cut depends mainly on the sharpness
of your blades and the degree of wear. The blades are
actually wearing parts, which should be replaced occa-
sionally to ensure consistent quality in the final product.

• MOTOR SEAL

The motor seal on the shaft should be lubricated re-
gularly using a food safe lubricant.
In order to keep the motor completely watertight, it is
advisable to check the motor seal regularly for wear
and tear and replace if necessary.
The motor seal can be easily replaced without having
to remove the motor, so we strongly advise you to en-
sure that is in good condition.
• BLADES, COMBS AND GRATERS
That blades on the silicing discs, the combs on the ju-
lienne discs and the graters are all wearing parts,
which have to be changed every so often to ensure
high quality cutting.
These models are fitted with a magnetic safety de-
vice and motor braking system.
As soon as you open the lid of the cutter bowl or the
vegetable attachment, the motor stops.
To restart the machine, simply close the lid and press
the green switch.
In order to avoid splashing when processing liquid
preparation, we recommend you stop the machine
before opening the lid.
12

MAINTENANCE

The blades and discs are extremely sharp.
Handle with care.
All the models are fitted with a thermal cut-out which
automatically stops the motor if the machine is left on
for too long or overloaded.
If this happens, allow the machine to cool completely
before restarting.
Never try to override the locking and safety
systems.
Never introduce any object into the container
where the food is being processed.
Never push the ingredients down with your
hand.
Do not overload the appliance.
Never switch the appliance on while it is
empty.
MACHINES IN COMPLIANCE WITH:
• The following European directives and related
national legislation:

SAFETY

- Modified "machinery" directive 98/37/EEC,
- "Low voltage" directive 73/23/EEC,
- "EMC" directive 89/336/EEC,
- "Materials and parts in food contact" directive
89/109/EEC,
- "Plastic materials and parts in food contact" di-
rective 90/128/EEC.
• The following European harmonized standards
and standards setting out health and safety
rules:
- EN 292 - 1 and - 2,
W A R N I N G
R E M E N B E R

STANDARDS

- EN 60204 -1 (1992),
- For Food Processors and blenders : EN 12852,
- For Vegetable cutting machine : EN 1678.
INDEXES OF PROTECTION:
- IP 55 for the switches.
- IP 34 for the machines.

ELECTRICAL DATA

R 502 three-phase machines
Vegetable Bowl
Motor Attachement cutter
(rpm) (rpm)
750
230 x 400V/
50 Hz
1500
750
400V/50 Hz
1500
900
220V/60 Hz
1800
860
380V/60 Hz
1700
R502 V.V. single-phase machines
Vegetable Bowl
Motor Attachement cutter
(rpm) (rpm)
300 to 300 to
230V/50-60Hz
1000 3000
Power Intensity
(Watts) (Amp.)
230V=3,1
370
400V=1,8
230V=3,6
670
400V=2,1
500 2,2
1000 2,4
500 3,6
1000 3,8
500 2,1
1000 2,2
Power Intensity
(Watts) (Amp.)
1300 12
