Maintenance; Motor Seal; Locking Washer; Blades - Robot Coupe CL 40 Manual

MAINTENANCE

• MOTOR SEAL

The motor seal on the shaft should be lubricated
regularly using a food safe lubricant.
In order to keep the motor completely watertight, it
is advisable to check the motor seal regularly for
wear and tear and replace if necessary.
The motor seal can be easily replaced without
having to remove the motor, so we strongly advise
you to ensure that is in good condition.

• LOCKING WASHER

To ensure that your appliance continues to run
smoothly, we recommend that you regularly check
the locking washer for wear and tear.
If the washer becomes worn, we therefore advise
you to replace it.

• BLADES

The blades of the slicing discs of the dicing
and french fry kits are wearing parts that must be
replaced from time to time, in order to maintain
optimum cutting quality.

• GRATING, JULIENNE AND RIPPLE-CUT DISCS

The grating, julienne and ripple-cut discs gradually
become blunt and should be replaced from time to
time to maintain optimum cutting quality.
TECHNICAL
SPECIFICATIONS
• WEIGHT (Lbs)
Net
CL 40
35
(without disc)
Disc 1.1

• WORKING HEIGHT

We recommend that you position the CL 40 on a
stable worktop so that the upper edge of the large
feed hopper is at a height of between 46 inches
and 52 inches.

• NOISE LEVEL

The equivalent continuous sound level when the
CL 40 is operating on no-load is less than 70 dB
(A).
The CL 40 is fitted with a magnetic safety device
and motor braking system.
As soon as you open the lid, the motor stops.
To restart the machine, simply close the lid and
press the green switch.
The CL 40 is fitted with a thermal cut-out which
automatically stops the motor if the machine is left
on for too long or overloaded.
If this happens, allow the machine to cool comple-
tely before restarting.
W A R N I N G
The blades are extremely sharp.
Handle with care.
Gross
R E M E M B E R
40
Never try to override the locking and safety
systems.
1.3
Never insert an object into the container where
the food is being processed.
Never push the ingredients down with your
hand.
Do not overload the appliance.
See warranty first then;
Should your unit require ser vice, check with
your distributor to see where local ser vice is
available. If not or if you wish your unit to be
serviced at the factory, call for return instructions

SAFETY

and ship the unit prepaid to our factory address.
PH : 1-800-824-1646
Robot-Coupe USA, Inc
Service Department Repair
264 South Perkins Street
Ridgeland, MS 39157
For service in Canada contact the Robot-Coupe
USA factory for repair instructions.

SERVICE

9
