17. DEFAULT SPEAKERS PRESETS
KH15
0
=
KH15F
1
=
KH15M
2
=
KH15H
3
=
KH15Q
4
=
KH15IN
5
=
KH15VX
6
=
KH15GN
7
=
KH15FLP
8
=
KH15MP
9
=
KH15HP
10
=
KH15F
11
=
KH15M
12
=
KH15H
13
=
KH15Q
14
=
KH15IN
15
=
KH15VX
KH4
0
=
KH4FL
1
=
KH4FL
2
=
KH4M
3
=
KH4MP
4
=
KH4H
5
=
KH4HP
6
=
KH4Q
7
=
KH4QP
8
=
KH4FULL
9
=
KH421F
10
=
KH422F
11
=
KH431F
12
=
KH432F
13
=
KH433F
14
=
KH4FL
15
=
KH4FL
KS4
0
=
KS4FL02
1
=
KS4XT45
2
=
KS4XT12
3
=
KS4101
4
=
KS4F02_1
5
=
KS4F02_2
6
=
KS4F02_3
7
=
KS4XT200
USER'S MANUAL
Flat
Mid
High
"Hi-Hat" EQ
Warm indoor EQ
Speech EQ or BG music
Flat Studio EQ
Flat + PAD -4dB
Mid + PAD -4dB
High + PAD -4dB
Flat
Indoor EQ
Mid
Mid + PAD -4dB
High
High + PAD -4dB
"Hi-Hat" EQ
"Hi-Hat" EQ + PAD -4dB
"fullrange" preset
Array Configuration x 2 speakers 1° position (from top)
Array Configuration x 2 speakers 2° position (from top)
Array Configuration x 3 speakers 1° position (from top)
Array Configuration x 3 speakers 2° position (from top)
Array Configuration x 3 speakers 3° position (from top)
Flat
Indoor EQ
Flat preset
Extended low frequencies preset
Emphasis at 120Hz
For stand alone applications
Flat preset with 1ms delay
Flat preset with 2ms delay
Flat preset with 3ms delay
Extended at 200Hz
Preset names indicates:
Speaker model
The number of speakers installed
Position of the speaker to the others
Code and preset release
Example:
KH432F01
Preset for KH4 speaker
3 x KH4 per side
central position (second one from the top)
EQ F1 (flat rev1)
P. 20
