3 . ID setting
FROM PC OR PREVIOUS MODULE
TO NEXT MODULE
ADDRESS FOR REMOTE CONTROL
ID 39
KH4FL01
PRESET LOADED
ADDRESS X 10
ADDRESS X 1
RESET BUTTON
PRESET SCROLL
4 . Single module control
USER'S MANUAL
On this bars you can see all the
modules connected in your net.
Click once on the ID module
that you want control.
Module status panel
Pressing this button you can have a
refresh of the modules connected.
Preset slots on the module
Press to change preset
