LG LSRG309ST Service Manual

LG LSRG309ST Service Manual

30” freestanding gas range
Hide thumbs Also See for LSRG309ST:
Table of Contents

Advertisement

Quick Links

See also: Owner's Manual , Installation Manual
삼
흥
정
판
30" Freestanding Gas Range
SERVICE MANUAL
MODEL: LSRG309ST
CAUTION
BEFORE SERVICING THE UNIT, READ THE SAFETY PRECAUTIONS IN THIS MANUAL.
P/NO : MFL63290103
Website http://us.lgservice.com
Internal Use Only
February, 2010
Printed in Korea

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LSRG309ST and is the answer not in the manual?

Questions and answers

Related Manuals for LG LSRG309ST

Summary of Contents for LG LSRG309ST

  • Page 1 삼 흥 정 판 Internal Use Only Website http://us.lgservice.com 30” Freestanding Gas Range SERVICE MANUAL MODEL: LSRG309ST CAUTION BEFORE SERVICING THE UNIT, READ THE SAFETY PRECAUTIONS IN THIS MANUAL. February, 2010 P/NO : MFL63290103 Printed in Korea...

  • Page 2: Safety Precautions

    SAFETY PRECAUTIONS • Repairs of the appliance should be carried out by a licensed technician only. Incorrect repairs may result in dangerous situations. If you need repairs, contact an LG Service Center or your dealer. • If the power cord is defective, it must be replaced by a qualified service agent with a UL listed range cord.

  • Page 3: Table Of Contents

    TABLE OF CONTENTS GENERAL- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 1-1 ~ 1-5 •...
  • Page 4 (Page) COMPONENT TEST - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 4-1 ~ 4-4 •...

  • Page 5: General

    GENERAL IMPOR ANT SAFETY INSTR UCTIONS IMPOR ANT SAFETY INSTR UCTIONS Read and follow all instructions before using your oven to prevent the risk of fire, electric shock, injury to person, or damage when using the range. This guide don’t cover all possible conditions that may occur. For further assistance contact your service agent or manufacturer.
  • Page 6 GENERAL IMPOR ANT SAFETY INSTR UCTIONS IMPOR ANT SAFETY INSTR UCTIONS • Be sure your appliance is properly installed and grounded by WARNING a qualified technician. • Do not repair or replace any part of the appliance unless • DO NOT store items of interest to specifically recommended in the manual.

  • Page 7: Surface Cooking Units

    GENERAL IMPOR ANT SAFETY INSTR UCTIONS IMPOR ANT SAFETY INSTR UCTIONS SURFACE COOKING UNITS SELF-CLEAN OVENS • If the top burner flame goes out,gas is still flowing to the • Do Not Clean Door Gasket – The door gasket is essential burner until the knob is turned to the “OFF”...

  • Page 8: Model & Serial Number Label And Tech Sheet Locations

    GENERAL MODEL & SERIAL NUMBER LABEL MODEL & SERIAL NUMBER LABEL AND TECH SHEET LOCA TIONS AND TECH SHEET LOCA TIONS The Model/Serial Number label and Tech Sheet locations are shown below. Model & Serial Number Location Tech Sheet Location (On Low Rear Cover)

  • Page 9: Specifications

    GENERAL SPECIFICA TIONS SPECIFICA TIONS Model Number LSRG309ST Category Single Convection Width 30" Overall Installation type Freestanding Color availability Oven Glass Touch Control Cooktop Knob Display Scroll VFD Electronic clock & timer Control lock capability Audible preheat signal Special function Setting (6 categories) 1.

  • Page 10: Using Your Range

    USING YOUR RANGE GENERAL INFORMA TION GENERAL INFORMA TION Convection Bake / Roast Mode Rating Label During a convection bake the fan and the burner Model numbers are recorded on the rating label. run opposite of each other, however on a Rating label is located on the lower front left corner convection roast the fan and burner operate at the of the oven frame.
  • Page 11 USING YOUR RANGE CONTR OL P ANEL FEA TURES CONTR OL P ANEL FEA TURES 1. CONVECTION BAKE PAD – Touch the pad to 11. START TIME PAD – Touch this pad and then touch select baking with the Convection function. the number pad to set delayed start time.

  • Page 12: To Turn On On The Surface Burners

    USING YOUR RANGE 1. TO TURN ON THE SURFACE BURNER 4. TO TURN ON/OFF THE OVEN LIGHT 1. Be sure all the surface burners are placed in The oven light automatically turns ON when the their respective positions. door is opened. The oven light may also be 2.

  • Page 13: Bake, Timed Bake, Delayed Timed Bake

    USING YOUR RANGE 3) LANGUAGE SELECTION (English or 10. CONVECTION ROAST Spanish) CONV. Desired START 1. Touch and hold the pad for 3 seconds. ROAST Temp. Then touch the WARM pad twice. 11. FAVORITE 2. Touch “1” pad for ENGLISH or “2”...
  • Page 14 USING YOUR RANGE ARMING DRA ARMING DRA To set the warming drawer control The rack can be used in 2 ways: 1. Touch the “WARM DRAWER • In the upright position to allow low profile food SET/OFF” pad. “WARMER” begins to items to be placed both under and on top of the blink.

  • Page 15: Warming Drawer

    COMPONENT ACCESS This section instructs you on how to service each component inside the range. The components and their locations are shown below. COMPONENT LOCA TIONS COMPONENT LOCA TIONS Power PCB Relay PCB Main PCB Spark module Door locking motor &...
  • Page 16 COMPONENT ACCESS REMO VING THE B CK, CONTR OL CO REMO VING THE B CK, CONTR OL CO AND KEY P AD ASSEMBL AND KEY P AD ASSEMBL 6. Remove the 2 screws of the eyebrow from the WARNING controller sub assembly and remove the eyebrow. •...
  • Page 17 COMPONENT ACCESS REMO VING THE SP ARK MODULE (IG TRANS) REMO VING THE SP ARK MODULE (IG TRANS) AND PO WER CONTR OL BO ARD (PCB) AND PO WER CONTR OL BO ARD (PCB) 4. There are 3 PCB's (power control board). When WARNING you check PCB, check the proper pcb in default mode and check main pcb.
  • Page 18 COMPONENT ACCESS REMO VING THE COOKT OP PLA REMO VING THE COOKT OP PLA 5. Life top up at front. WARNING • DISCONNECT power supply cord from the outlet before servicing. • Replace all panels and parts before operating. • RECONNECT all grounding devices. - Failure to do so can result in severe personal injury, death or electrical shock.

  • Page 19: Removing The Cooktop Plate

    COMPONENT ACCESS REMO VING THE CASE ASSEMBL REMO VING THE CASE ASSEMBL (COOKT OP B URNER ASSEMBL (COOKT OP B URNER ASSEMBL 4. Remove the tubing fitting (5/8-inch). WARNING 5. Remove 5 phillips head screws. • DISCONNECT power supply cord from the outlet before servicing.

  • Page 20: Gas Valve

    COMPONENT ACCESS REMO VING THE COOKT OP P REMO VING THE COOKT OP P 4. To remove the valve: WARNING a) Remove the manifold panel (See the step 3 on page 3-5). • DISCONNECT power supply cord b) Remove the fitting that you need to remove. from the outlet before servicing.
  • Page 21 COMPONENT ACCESS 5. To remove the ignition switch: a) Remove the manifold panel (See the step 3 on page 3-5). b) Pry on the 2 release tabs and slide the switch off the valve stem. c) Remove the connector and remove the ignition switch.
  • Page 22 COMPONENT ACCESS REMO VING THE DOOR LA TCH & DOOR SWITCH REMO VING THE DOOR LA TCH & DOOR SWITCH b) Remove the 2 screws and then remove the bar WARNING from the door latch. c) Remove the door latch. •...
  • Page 23 COMPONENT ACCESS REMO VING THE BR OIL B URNER ASSEMBL REMO VING THE BR OIL B URNER ASSEMBL d) Remove the igniter connecter in the cavity WARNING (To get the connecter, pull the wire toward the cavity). • DISCONNECT power supply cord e) Remove the broil burner assembly.
  • Page 24 COMPONENT ACCESS VEN BO OM, THE FRAME GUIDE VEN BO OM, THE FRAME GUIDE AND THE B URNER ASSEMBL AND THE B URNER ASSEMBL 1. Turn off the electrical supply and gas supply 6. To remove the nozzle case: going to the range. - Remove the screw and then remove nozzle 2.

  • Page 25: Removing The Convection An Blade And Fan Motor

    COMPONENT ACCESS REMO VING THE CONVECTION AN BLADE AND F AN MO REMO VING THE CONVECTION AN BLADE AND F AN MO 1. Turn off the electrical supply and gas supply CAUTION going to the range and remove the oven racks. 2.

  • Page 26: Removing The Oven Light & Socket Assembly

    COMPONENT ACCESS REMO VING THE O VEN LIGHT & SOCKET ASSEMBL REMO VING THE O VEN LIGHT & SOCKET ASSEMBL CAUTION WARNING • DISCONNECT power supply cord • Be careful not to scratch or chip the from the outlet before servicing. oven liner paint when you remove •...

  • Page 27: Door Locking Mechanism

    COMPONENT ACCESS REMO VING THE LA TCH DRIVE ASSEMBL REMO VING THE LA TCH DRIVE ASSEMBL DOOR LOCKING MECHANISM WARNING The door lock assembly is located at the back side • DISCONNECT power supply cord of range. from the outlet before servicing. The structural elements are as below.

  • Page 28: Removing The Oven Temperature Sensor

    COMPONENT ACCESS REMO VING THE O VEN TEMPERA TURE SENSORS REMO VING THE O VEN TEMPERA TURE SENSORS WARNING • DISCONNECT power supply cord from the outlet before servicing. • Replace all panels and parts before operating. • RECONNECT all grounding devices. - Failure to do so can result in severe personal injury, death or electrical shock.
  • Page 29 COMPONENT ACCESS REMO VIING & REPLA CING THE W ARMIING REMO VIING & REPLA CING THE W ARMIING WER ELEMENT WER ELEMENT To remove the warming drawer element: WARNING 1. Remove the 2 bottom bracket screws • DISCONNECT power supply cord 2.

  • Page 30: Removing & Replacing The Lift-Off Oven Door

    COMPONENT ACCESS REMO VING & REPLA CING THE LIFT -OFF O VEN DOOR REMO VING & REPLA CING THE LIFT -OFF O VEN DOOR To replace the door: CAUTION 1. Firmly grasp • Be careful when removing and both sides of the lifting the door.

  • Page 31: Removing The Oven Door Handle & Glass

    COMPONENT ACCESS REMO VING THE O VEN DOOR HANDLE & GLASS REMO VING THE O VEN DOOR HANDLE & GLASS 6. To remove the door handle & trim WARNING a) Remove the 4 door handle screws and lift the door handle off door trim and slide up the door trim.
  • Page 32 COMPONENT ACCESS 8. To remove a hinge hanger assembly: d) Lift the inner oven door glass and bracket a) Remove the 2 top liner screws assembly out of the door liner. (See step 3 on page 3-14) b) Place the door liner assembly on a padded work surface with the hinge hangers over the edge.

  • Page 33: Removing The Oven Door Gasket & Drawer Gasket

    COMPONENT ACCESS REMO VING THE O VEN DOOR GASKET REMO VING THE O VEN DOOR GASKET & DRA WER GASKET & DRA WER GASKET c) Pull the ends of the gasket out of the liner WARNING holes. • DISCONNECT power supply cord Liner Hole from the outlet before servicing.

  • Page 34: Removing A Side Panel

    COMPONENT ACCESS REMO VING A SIDE P ANEL REMO VING A SIDE P ANEL 7. Remove the 6 screws from the left or right side WARNING panel. • DISCONNECT power supply cord from the outlet before servicing. • Replace all panels and parts before operating.
  • Page 35 COMPONENT ACCESS REMO VE THE O VEN V VE (SAFETY V REMO VE THE O VEN V VE (SAFETY V & GAS REGULA & GAS REGULA c) Remove the 4 connectors. WARNING d) Remove the 4 screws and than lift the oven valve.

  • Page 36: Component Test

    COMPONENT TEST Before testing any of components, perform the following checks: NOTE: 1. The most common cause for control failure is corrosion on connectors. Therefore, disconnecting and reconnecting wires will be necessary throughout test procedures 2. ALL units in the first few days of use should be checked for mis-wiring or loose connections 1.

  • Page 37: Door Locking Motor

    Components Test procedures Results Normal: Approximately Door locking Motor 1. Refer to page 3-13 for the servicing procedure 2.6 kΩ ± 10% 2. Measure the resistance If not replace (Multiple meter scale: R x 1000) Abnormal: Infinite(open) below 5Ω (shorted) Door latch Door latch Micro Switch...

  • Page 38: Door Switch

    Components Test procedures Results Door switch 1. Refer to page 3-8 for the servicing procedure Door open Door closed 2. Measure the resistance after cooling down (Multiple meter scale: R x 1) Continuity Infinite Normal: Approximately 1. Measure the resistance after cooling down Oven lamp 5 Ω...

  • Page 39: Broil Or Bake Igniter

    Components Test procedures Results Normal: 45 Ω ~ 100 Ω Broil or bake igniter 1. Refer to page 3-9 or 3-10 for servicing procedure. (Room Temperature 2. Measure the resistance after cooling down. Resistance) (Multiple meter scale : R x 1) If not replace Oven (safety) valve Normal: Approximately...

  • Page 40: Conversion To Lp Gas

    CONVERSION TO LP GAS 2. CONVERT THE PRESSURE REGULATOR WARNING WARNING • Turn off the electrical supply and gas supply going to the range. • Do not remove the pressure • Replace all panels and parts before regulator from the range. operating.
  • Page 41 - Failure to do so can result in severe personal BURNER OUTPUT RATINGS; BTU/HR injury, death or electrical shock. LP (Propance) Gas, 10” W.C.P MODEL BTU RATE ORIFICE CODE LSRG309ST LSRG309ST CAUTION BURNER 9,500 • Be careful when you work on the 9,100...
  • Page 42 • Turn off the electrical supply and 5) For the extra burner (right front) of gas supply going to the range. LSRG309ST, three orifice spuds will be • Replace all panels and parts before needed. operating. 6) Put the old orifice spuds into conversion kits •...
  • Page 43 CONVERSION TO LP GAS 2) Release the connector of the lgniter. WARNING 3) Remove the orifice spud from nozzle holder using a 13/32” or 10mm wrench. • Turn off the electrical supply and 4) Install the LP orifce spud(C) to the nozzle gas supply going to the range.
  • Page 44 4) Insert a small, flat bladed screwdriver into the WARNING valve shaft as shown in Fig. 1. On the right front valve for model LSRG309ST • Turn off the electrical supply and there is a secondary adjustment for the low gas supply going to the range.

  • Page 45: Composition Of Control

    COMPOSITION OF CONTROL Front Main PCB (P/N : EBR52349501) Back Power PCB (P/N : EBR57124701) Controller assembly Relay PCB (P/N : EBR52349701) Control Supporter Front Key PCB (P/N : EBR52350001) Back PCB case assembly...

  • Page 46: Oven Main Pcb

    COMPOSITION OF CONTROL Oven Main PCB Oven Main PCB P/N : EBR52349501 wer PCB wer PCB P/N : EBR57124701 CN10 CN10 CN10 CN10 CN10 CN10 CN10 CN10 CN10 CN10 CN10 CN10 CN10 CN10 CN10 CN10 CN10 CN10 CN10 CN10 CN10 CN10 Rela y PCB...

  • Page 47: Diagnosis Through Schematic

    DIAGNOSIS THROUGH SCHEMATIC Symptom : Oven hot(F-6) -. Check: All heater relays are open/short Symptom : Sensor error or no heating(F-1,F-2,F-11) -. Check : Sensor resistance Symptom : no heating(F-11) -. Check : relative part Symptom : Oven lamp not operating -.

  • Page 48: Check The Failure Code (F-Code)

    CHECK THE FAILURE CODE (F-code) ■ When the oven has some failure on cooking - Cancel the cook. - In case of failure , F-code will not display during normal operation. - It memorizes F-code logs in EEPROM. ■ Check the failure code as follow these steps. 1.

  • Page 49: Failure Code Summary

    FAILURE CODE SUMMARY Code Description How to detect Check point Opened Sensor Oven sensor remains open for over 1 min 1. Wiring during cooking. 2. Oven Sensor Shorted Sensor Oven sensor is short for over 1 min 1. Wiring during cooking. 2.

  • Page 50: Checking Flow Chart By Failure

    CHECKING FLOW CHART BY FAILURE Symptom Check Point 1. Power Failure 1. Check Electric Wiring (Dead) 2. Check the Power PCB and Main PCB Voltage 2. No Display 10-1...

  • Page 51: Power Failed(Dead), No Display

    CHECKING FLOW CHART BY FAILURE Power Off Power Failed(Dead), No display? Replace the defective Is the electric wiring normal? harness Measure the resistance Power On State Power cord and CN01’s connection Go to No 4 Check the key beep. Touch Normal : continuity the “clear key”, Is the beep Abnormal : infinite...
  • Page 52 CHECKING FLOW CHART BY FAILURE Power On Power On Replace the Replace the Check the voltage of Is the voltage of Main Power PCB Main PCB Power PCB PCB’s Vcc 4.5V ~ 5.5V? Is the voltage as below? Check the voltage between pin2 and pin3 of IC2 PIN No.
  • Page 53 CHECKING FLOW CHART BY FAILURE Symptom Check Point 1. No heating 1. Check Gas supply 2. F11 2. Check Electric Wiring 3. Check Heater’s Resistance. 4. Check the Sensor. 10-4...
  • Page 54 CHECKING FLOW CHART BY FAILURE Power Off Oven does not heat, F-11 Replace the Is the glowbar ignitor failed glowbar normal? Power Off Measure the resistance of each glowbar Reconnect or (The resistance is shown on next page) repair the Is the disconnect or loose connector connector?
  • Page 55 CHECKING FLOW CHART BY FAILURE Power Off Range Of the resistance Heater Min[Ω] Max [Ω] Replace the Broil Glowbar 45.0 400.0 Is the resistance of failed thermistor thermistor normal? Bake Glowbar 45.0 400.0 Gas Valve(Broil) Check: Gas Valve(Bake) Pins 1and 2 of CN5 wiring in main PCB Normal - approximately 1.09kΩ...

  • Page 56: Warm Drawer Does Not Heat

    CHECKING FLOW CHART BY FAILURE Power Off Warm drawer does not heat Replace the Is the drawer heater normal? failed thermistor Measure the resistance Power Off of drawer heater Reconnect or Normal - approximately 24Ω repair the Is the disconnect or loose connector connector? 1.

  • Page 57: Door Lock System Failure, F-10

    CHECKING FLOW CHART BY FAILURE Symptom Check Point 1. Door Lock System 1. Check the Electric wiring Failure 2. Check the Motor’s Resistance 2. F-10 3. Check the Relay PCB(Lock Motor Relay) 10-8...
  • Page 58 CHECKING FLOW CHART BY FAILURE Power Off Door Lock System Failure,F-10? Replace the Is the door lock switch micro switch (micro switch) normal? Note : measure the resistance of Just after self-clean start, the door lock motor starts to rotate. door lock switch normally open type During that time if the door lock switch does not operate...

  • Page 59: Sensing Fail, F-1, F-2

    CHECKING FLOW CHART BY FAILURE Symptom Check Point 1. Sensing Fail 1. Check the Electric Wiring 2. F-1 2. Check the Test Mode 3. F-2 3. Check the Sensor’s Resistance 10-10...
  • Page 60 CHECKING FLOW CHART BY FAILURE Sensing Fail, F-1, F-2? Power Off Reconnect or repair the Is the disconnect or loose connector connector? 1. Sensor connection 2. CN05 of Main PCB Power On Go to No 1 Is the value of thermistor normal? Check: using the test mode Sensor...

  • Page 61: Oven Too Hot, F-6, F-16

    CHECKING FLOW CHART BY FAILURE Symptom Check Point 1. Oven hot 1. Check the Resistance of the Relay. 2. F-6 10-12...
  • Page 62 CHECKING FLOW CHART BY FAILURE Oven too hot, F-6, F-16? 2pin(CN10) Power Off Bakel(RY6) Relay Replace the Resistance L:TAB1 L:TAB1 L:TAB1 L:TAB1 L:TAB1 Is the resistance of L:TAB1 L:TAB1 L:TAB1 L:TAB1 L:TAB1 L:TAB1 L:TAB1 L:TAB1 L:TAB1 L:TAB1 L:TAB1 L:TAB1 L:TAB1 failed thermistor thermistor normal? Check:...
  • Page 63 CHECKING FLOW CHART BY FAILURE Power On Replace the Main PCB Is the Relay operation signal (EBR52349501) Nomal? In Idle Mode (press the clear), Check the voltage of Diode 1. Both D40 ends. 2. Both D41 ends 2. Both D41 ends Normal: - approximately 0 V Abnormal:...
  • Page 64 CHECKING FLOW CHART BY FAILURE Symptom Check Point 1. Keypad Failure 1. Check the Door Locking System. 2. F-3 Error 2. Check the Electric Wiring. 10-15...

  • Page 65: Error (Touch-Sensor Key Error) Or Key Does Not Input

    CHECKING FLOW CHART BY FAILURE Power On F-3 error (Touch-sensor key error) Or Key does not input Replace The Key PCB Is the Key PCB (EBR52350001) normal operation? Power Off Check: Reconnect Re-connect CN1 of or repair the Is the disconnect or Key PCB and CN3 of connector loose connector?

  • Page 66: Key Operation Test

    CHECKING FLOW CHART BY FAILURE Key operation Test [Fig.1] How to check Key operation 1. Keys should be accessed according to priority and check the buzzer operation when key is accessed 2. If change the key access order, the buzzer make another beep 3.

  • Page 67: Trouble Shooting

    TROUBLE SHOOTING BEFORE CALLING FOR SER VICE BEFORE CALLING FOR SER VICE Before you call for service, review this list.It may save you time and expense. The list includes common occurrences that are not the result of defective workmanship or materials in this appliance. PROBLEMS POSSIBLE CAUSES SOLUTIONS...
  • Page 68 TROUBLE SHOOTING PROBLEMS POSSIBLE CAUSES SOLUTIONS Food does not bake or roast • Improper oven controls setting. • See the “USING THE OVEN” section in properly user’s guide. • Incorrect rack position. • See the “USING THE OVEN” section in user’s guide.
  • Page 69 TROUBLE SHOOTING PROBLEMS POSSIBLE CAUSES SOLUTIONS Oven will not selfclean • The oven temperature is too high • Allow the range to cool to room to set a self-clean operation. temperature and reset the controls. • Improper oven controls setting. •...
  • Page 70 TROUBLE SHOOTING PROBLEMS POSSIBLE CAUSES SOLUTIONS Oven racks are difficult to • The oven racks were cleaned in a • Apply a small amount of vegetable oil to a slide self-clean cycle. paper towel and wipe the edges of the oven racks with the paper towel.

  • Page 71: Exploded View
