INSTALLATION MANUAL ELECTRIC RANGE Please read these instructions thoroughly before installing and operating the range. LSES302S LSRE307S www.lge.com MFL57205803 (REV.02 150709)
Part 1 SAFETY BEFORE YOU BEGIN Remove all tape and packing materials before using the range. Dispose of all plastic bags after unpacking the range. Never allow children to play with packing materials. IMPORTANT SAFETY INSTRUCTIONS Read and follow all instructions before using your oven to prevent the risk of fire, electric shock, personal injury, or damage when using the range.
Page 3
Part 1 SAFETY PREPARE TO INSTALL THE RANGE WARNING TOOLS NEEDED Safety Glasses • The information in this manual Tape Measure should be followed exactly. - A fire or electrical shock may result causing property damage, personal injury or death. Gloves Pencil WARNING...
Part 2 PREPARE TO INSTALL THE RANGE INSTALLATION DRAWINGS (LSRE Series only) NOTE SAVE FOR THE USE OF THE LOCAL ELECTRICAL INSPECTOR. CLEARANCES AND DIMENSIONS (Figure 1) To install range refer to the following Figure 1. Safety Glasses For installation in CANADA, a Free-standing range is not to be installed closer than (12mm) from any adjacent surface.
Page 5
Part 2 PREPARE TO INSTALL THE RANGE INSTALLATION DRAWINGS (LSES Series only) NOTE SAVE FOR THE USE OF THE LOCAL ELECTRICAL INSPECTOR. CLEARANCES AND DIMENSIONS (Figure 1) To install range refer to the following Figure 1. Safety Glasses For installation in CANADA, a Free-standing range is not to be installed closer than (12mm) from any adjacent surface.
Part 3 ELECTRICAL CONNECTIONS ELECTRICAL CONNECTION CONNECT RANGE CORD REQUIREMENTS The Rear Access cover must be removed. Loosen the three screws with a screwdriver. The terminal block This appliance must be installed and grounded on a will then be accessible. branch circuit by a qualified technician in accordance with the National Electrical code ANSI/NFPA NO.
Part 3 ELECTRICAL CONNECTIONS Safety Glasses 3-wire connection with a power supply cord Tape Measure WARNING Pencil Gloves • The middle (neutral or ground) wire of a 3 wire power cord or a 3 wire conduit has to be connected to the middle post of the main terminal block.
Part 3 ELECTRICAL CONNECTIONS Safety Glasses 4-wire connection with a power supply cord 3-wire connection: conduit Tape Measure Install the conduit as follows: WARNING Pencil Gloves Remove the Conduit connection plate from the rear of • Only a 4-conductor power-supply cord drawer body and rotate it as shown in Figure 5.
Part 3 ELECTRICAL CONNECTIONS 4-wire connection: conduit 1. Follow the instructions under “Install the conduit 4-wire connection as follows” on page 7 to correctly install the strain relief. DO NOT install the conduit without a strain relief. 2. Loosen the 2 lower left and right screws from the terminal block.
Part 4 INSTALL THE RANGE Replace the access cover on the range back. To replace the wire cover, insert double projections in the pockets located below the opening and tighten the three screws. Safety Glasses Tape Measure Use a spirit level to check your adjustments. Place the level diagonally on the oven rack, and check each Safety Glasses direction for level.
MANUAL DE INSTALACIÓN ESTUFA ELÉCTRICA Sírvase leer cuidadosamente estas instrucciones antes de instalar y poner a funcionar la estufa. LSES302S LSRE307S www.lge.com P/No.: MFL57205803...
Sección 1 SEGURIDAD ANTES DE COMENZAR Quite todas las cintas y materiales de embalaje antes de usar la cocina. Elimine todas las bolsas de plástico después de desempacar la cocina. Nunca permita que los niños jueguen con los materiales de empaque. INSTRUCCIONES IMPORTANTES DE SEGURIDAD Lea y siga todas las instrucciones antes de utilizar su cocina para evitar el riesgo de incendio, descarga eléctrica, lesiones personales o daños cuando use la cocina.
Page 13
Sección 1 SEGURIDAD PREPARATIVOS PARA INSTALAR LA ADVERTENCIA ESTUFA • La información de este manual debe HERRAMIENTAS NECESARIAS seguirse al pie de la letra. - Puede provocarse una descarga eléctrica generando daños a la propiedad, lesiones Nivel Destornillador Phillips personales o la muerte. ADVERTENCIA Destornillador Llave de...
Page 14
Sección 2 PREPARATIVOS PARA INSTALAR LA ESTUFA ILUSTRACIONES DE INSTALACIÓN (solo en la serie LSRE) NOTA GUÁRDELO PARA EL USO DEL INSPECTOR LOCAL DE INSTALACIONES ELÉCTRICAS. HOLGURAS Y DIMENSIONES (Figura 1) Consulte la figura 1 a continuación para la instalación de la estufa. Si se va a instalar en CANADÁ, una estufa autónoma no podrá...
Page 15
Sección 2 PREPARATIVOS PARA INSTALAR LA ESTUFA ILUSTRACIONES DE INSTALACIÓN (solo en la serie LSES) NOTA GUÁRDELO PARA EL USO DEL INSPECTOR LOCAL DE INSTALACIONES ELÉCTRICAS. HOLGURAS Y DIMENSIONES (Figura 1) Consulte la figura 1 a continuación para la instalación de la estufa. Si se va a instalar en CANADÁ, una estufa autónoma no podrá...
Sección 3 CONEXIONES ELÉCTRICAS REQUISITOS DE LAS CONEXIONES CÓMO CONECTAR EL CABLE DE LA ESTUFA ELÉCTRICAS Este artefacto deberá instalarse y conectarse a tierra en un Debe quitarse la cubierta de acceso posterior. Use un destornillador para aflojar los tres tornillos. Entonces se circuito de red por un técnico certificado, de acuerdo con la edición más reciente del código de la National Electrical podrá...
Page 17
Sección 3 CONEXIONES ELÉCTRICAS Conexión de 3 alambres con un cable de alimentación ADVERTENCIA • El cable medio (neutral o a tierra) de un cable de energía de 3 clavijas o un conducto de 3 clavijas debe conectarse a la posición media del bloque terminal principal.
Page 18
Sección 3 CONEXIONES ELÉCTRICAS Conexión de 4 alambres Conexión de 3 alambres con un cable de alimentación conducto portacables Instale el conducto portacables de la ADVERTENCIA manera siguiente: • Sólo deberá utilizarse un equipo con cable de Quite la placa de conexión de conductos portacables de la energía de 4 conductores clasificado 120/240 voltios, parte posterior del cuerpo del cajón y déle vuelta como se 50 amperios y marcado para utilizar con cocinas con...
Page 19
Sección 3 CONEXIONES ELÉCTRICAS Conexión de 4 alambres conducto portacables 1. Siga las instrucciones de “Cómo instalar el Conexión de 4 alambres conducto pasacables” de la página 7 para instalar el aliviador de tensión de manera correcta. NO instale el conducto sin un protector. 2.
Sección 4 CÓMO INSTALAR LA ESTUFA Reponga la cubierta de acceso en la parte posterior de la estufa. Para reponer la cubierta de alambre, inserte las salientes dobles en las cavidades ubicadas debajo de la abertura y apriete los tres tornillos. Utilice un nivel de burbuja para verificar sus ajustes.
Page 24
