Removing and Emptying the Dustbin

G
1. Turn off the power switch.
2. Press down the dustbin release button and pull out the dustbin.
3. Place the dustbin over a waste bin, slide the two clips to open the fencing plates and empty the dustbin in the
waste bin.
4. Close the fencing plates, reinsert the dustbin and push until you hear a clicking sound.

Cleaning and Replacing the Filter

1. Place the dustbin over a waste bin and slide the two clips to open the fencing plates.
2. Take the filter out of the dustbin by pulling the flaps.
3. Clear the dirt on the filter using the maintenance brush.
4. Insert clean filter or new filter to the dustbin and close the fencing plates.
To buy new filters, please contact Vileda customer service address (see last page).

Cleaning Main Brushes

Main brushes do not need to be cleaned after each use. However, regular cleaning is recommended to avoid
excessive build-up of hair that could damage the robot.
1. Turn off the power switch and put the robot on a flat surface with its bottom up.
2. Remove the brush retainer by pushing on the flap.
3. Take out the main brush and the rubber brush as shown in the illustration.
4. Remove all hairs and dirt from both brushes. Plus, clean the brush chamber.
5. Wipe out dirt on the shaft and bearing of the brush.
6. Place brushes back into the slot.
7. Put the brushes retainer back and push until you hear a clicking sound.
9
