PART LIST—Model No. PFEVEX72910.0
Item Description
1 Console
2 Console fixed screw
3 Handle bar tube set
4 Screw M8*12
5 Handle bar flex tube
6 Bushing ( D shape )
7 Adjustable Knob
8 Brake knob
9 Flat washer OD20*8.5*2.0T
10 Hand brake piece
11 Brake Clamp
12 Brake piece
13 Screw M8*45
14 Saddle
15 Saddle tube set
16 Tube end cap
17 Saddle adjust set
18 Cover (L)
19 Cover (R)
20 Screw M4*20
21 Screw 5/16*25
22 Crank protect cap
23 Crank (L R)
24 Pedal(L R)
25 Leveling Cap
26 Moving wheel
27 Flat washer OD20*ID8.5*1.5T
28 M8*8T nylon nut
29 Carriage screw M10*94
30 Front stabilizer
Qty. Item Description
1 31 M10*10T nylon nut
2 32 M6*6T nylon nut
1 33 Screw M6*38
4 34 Sleeve 1
1 35 Flywheel axle
4 36 Nut M10
3 37 Sleeve 2
1 38 Inductor
2 39 Small sleeve
1 40 Flat washer OD20*ID10.5*2.0T
1 41 Flywheel
2 42 Chain wheel
2 43 Flywheel axle bushing
1 44 Bushing
1 45 Rear stabilizer
3 46 Arc washer OD20*ID10.5*1.5T
1 47 Bearing R12
1 48 Snap Ring
1 49 Chain plate
16 50 Chain
2 51 Reaction connection wire 1
2 52 Reaction connection wire 2
2 53 Wire protect cap
2 54 Main frame
4 55 Brake Cable
2 56 Flat washer OD16*ID8.5*1.5T
2 57 Screw M6*16
2 58 Flywheel locking steel wire
4 59 Padlock
1 60 Key
61 6001ZZ bearing
11
Qty.
6
2
2
2
1
3
1
1
1
1
1
1
1
1
1
4
2
2
1
1
1
1
4
1
1
4
1
1
1
1
2
