Setting
STC Output Reporting
(Normally Closed)
STC Trip Delay for NSC
Check for proper operation of each programmed supervisory output by causing it to
trip the alarm panel and be sure the LED illuminates and that the STC relay trips.

Step 5: Connect and Test the Trip Input (optional)

In addition to the interface to the alarm panel, a single trip input may be connected
to the terminal block of the TG-1 Express CDMA. When the input is tripped, a
supervisory message is sent to the central station via the Telguard Communications
Center. The functionality of the Trip input can be customized via the
www.telguardonline.com

Step 6: Complete the Telguard Installation

The last step is to permanently mount the Telguard. Attach earth ground to the
grounding screw located on lower left-hand corner of printed circuit board assembly
and permanently mount the Telguard enclosure. Install the mounting screws (not
supplied). The "keyhole" mounting holes on the back of the TG-1 Express CDMA are
2.5" apart, center-to-center. Slide the enclosure onto these screws.
Telguard Interactive
The Telguard Interactive feature is an added service that provides the flexibility of
remote arming/disarming of the panel and end-user notification of events. If
enabled, the wiring and programming of the panel will vary from a standard
Telguard installation. To ensure a successful installation, four steps must be taken:
1. Enable the Telguard Interactive feature from
56046902
Values
Defaulted to report all. Available options are:
LPF, NSC, RFC, and DTF
Defaulted to a 60 second delay. Available
options are: 30 sec, 1 min, 3 min, 10 min, 20
min, 30 min, 45 min, 60 min or 24 hours
site or by a Telguard Customer Service representative.
8
