Q S I
UICK ETUP NSTRUCTIONS
Note: See manual for detailed descriptions and instructions.
S 1: D L
TEP ETERMINE OCATION
Prior to connecting the power supply and audio source, consider where TX90 will be installed for best coverage
of the listening area. Ideally, the TX90 should be pointed toward the listening audience where the receivers can
pick-up the TX90's transmission line-of-sight. See manual for coverage drawings.
S 2: C P
TEP ONNECT OWER
Connect the supplied power supply to the back of the TX90 (FIG. A). The red LED "Power On" indicator will
illuminate.
S 3: C A
TEP ONNECT UDIO
For single channel mode, plug the audio cable with the installed Phoenix connector in "Channel A" OR the
"Channel B" connector. For two channel operation, plug the audio cables with Phoenix connectors in both
"Channel A" AND "Channel B" connector. NOTE: By default, the WIR TX90 is set to operate in two channel
mode. To turn Channel A or Channel B on/off, refer to the instructions in Step 5. For optimal performance,
turn OFF channels not in use.
S 4: S
TEP ELECTING A
The TX90 offers two sets of carrier frequencies for Channel A and Channel B:
2.3 and 2.8MHz or 3.3 and 3.8MHz. The TX90 is preset to 2.3 and 2.8MHz. Move the slide switch to select a
pair of operating frequencies.
S 5: S
TEP ELECTING A
To activate a channel, press the "CHANNEL" button until the channel "ON" indicator lights. To operate both
channel A and B, press the "CHANNEL" button until both "ON" indicators light.
S 6: S A
TEP ELECT THE
The TX90 offers three presets for the most common audio applications: Music, Voice, and Hearing Assist. The
TX90 is factory set "Music" mode for maximum audio quality. To change this preset, press "CHANNEL"
button to active channel to set preset for, then press the "PRESETS" button until indicator light shows your
selection. After 10 seconds, the setting will be stored.
S 7: A A
TEP DJUST UDIO
To adjust the audio input level, first activate the channel(s) you want to adjust by pressing the "CHANNEL"
button, then press the "VOLUME" button. Turn the "ADJUST" knob clockwise to increase the input signal or
counter-clockwise to decrease the input signal until the channel "Level" indicator is flashing. After 10 seconds,
the setting will be stored.
Audio level NORMAL (optimal): the audio indicator level will flash at a 1 second rate.
Audio level too HIGH: the audio indicator level will stay on or flash erratically.
Audio level too LOW: the audio indicator level will be off.
S 8: A T
TEP DJUST ONE
To adjust the tone, first activate the channel(s) you want to adjust by pressing the "CHANNEL" button, then
press the "TONE" button. The tone indicator will light. Now turn the "ADJUST" knob clockwise to emphasize
high frequencies (best for hearing assistance use) and counter-clockwise to decrease the high frequency empha-
sis. After 10 seconds, the setting will be stored.
S 9: L
TEP ISTEN WITH
Important: Make sure the infrared receiver being used is on the same frequency as the WIR TX90! Refer to
the operating instructions that came with your receiver.
See manual for detailed descriptions and instructions. If you are still having difficulty with your system,
please call customer service at 800-843-3544.
/C
OVERAGE
S
OURCE
F
REQUENCY
C
HANNEL
P A
UDIO ROCESSING PPLICATION
I L
NPUT EVEL
R
ECEIVER
®
P
RESET
3
