- Page 1 Pressure Washers Avenger 1000-3 NG/LP 2HP - Single Phase Operators Manual and Replacement Parts Book Delco Pressure Washers - LIT - AVEN-1000-3 - DEL...
- Page 2 INTRODUCTION Thank you for selecting a high pressure power washer from Delco Pressure Washers. Your pressure washer has been manufactured using the most advanced compo- nents in the pressure industry. When operated properly, our equipment has been designed and manufactured to give you years of trouble free, reliable use, with a minimal amount of regular maintenance.
- Page 3 PRESSURE WASHER LIMITED WARRANTY 1. DELCO Cleaning Systems, LLC warrants its products for a period of one year from the date of pur- chase, against defects in material and/or workmanship. The warranty covers parts and labor, but excludes transportation. 2. Normal wear and tear items such as valves, seals, etc., are warranted for the initial 30 days following purchase by the end-user.
-
Page 4: Table Of Contents
TABLE OF CONTENTS Operator Safety Instructions ............1 Introduction and Machine Specifications . -
Page 5: Operator Safety Instructions
DANGER: Electrocution could occur if the machine is used on a power circuit that repeatedly trips or is undersized. Have a licensed electrician check the fuse, circuit breaker or power supply, and/or contact your local authorized Delco distributor for assistance. - Page 6 Servicing of this unit must always be referred to an authorized Delco distributor. CAUTION: Your machine warranty will be voided if anything other than genuine Delco parts are used on your pressure washer. Always use Delco parts for replacement. Page 6...
-
Page 7: Introduction And Machine Specifications
INTRODUCTION & MACHINE SPECIFICATIONS The Avenger 1000-3 LP and NG fired system can tackle the toughest industrial cleaning tasks. Standard features include dual belt driven triplex ceramic plunger pumps with low-water shut-off, 4.5 minute system shut down protection plus many more features, all built into a compact space-saving design. When you need a quick and efficient cleaning system in your maintenance program, you need the Avenger. -
Page 8: How To Prepare The Machine For Operation
HOW TO PREPARE THE MACHINE FOR OPERATION NOTE: Following delivery of your Delco pressure washer, inspect the unit for shipping damage. ASSEMBLY 1. Uncrate machine. Remove cleaner, parts package, gun and hose from shipping carton. 2. Assemble cleaner, gun, and hose. Do not install the pressure nozzle at this time. -
Page 9: Water Supply
Stacking the Unit: If the cleaner is used in an enclosed area be sure there is plenty of ventilation.. Be sure the chimney is the same size as the stack on the cleaner. Poor draft will cause the unit to soot and not operate efficiently. When placing the unit for installation, keep in mind that the unit should be positioned in such a manner that the stack will be as straight as possible and protrude through the roof of the building at a proper location and at sufficient height to eliminate downdraft. -
Page 10: Installation & Servicing Instructions
Maintenance and repairs performed by unauthorized personnel could result in damage or injury. Servicing of this unit must always be referred to an authorized Delco distributor. Repairs, adjustments, and servicing should be limited to the operations listed below. - Page 11 If the gas control has been exposed to WATER in any way, DO NOT try to use it. It must be replaced. DO NOT attempt repair on gas valve . It must be replaced. DO NOT attempt repair on gas control or machine. Call an authorized Delco distributor for repairs. Tampering is DANGEROUS and voids all warranties.
-
Page 12: Operating Instructions
To reset turn the main switch to pump #1 only then back to burner #2. Repeat if needed. OPERATING INSTRUCTIONS Following delivery and installation of your Delco pressure washer, inspect the unit for shipping damage and follow these directions. 1. Observe all danger, warning, and caution statements. -
Page 13: Maintenance
1. Use a water softener on your water system if it is known to be high in mineral content. 2. Use only high quality Delco chemicals and follow the manufacturer's mixing instructions. 3. The cleaner should be flushed thoroughly after using the chemical solutions. - Page 14 How to Check / Clean the Heat Exchange Coil: (NOTE: See the Operators Safety Manual The heat exchange coil should be inspected for deposit build-up after 40 hours of use, or once a month, whichever comes first. In hard water areas a water softening system should be employed. Scaling or liming of the coils is caused by mineral deposits from the water and occurs much faster in hard- water areas and with heavier machine usage.
- Page 15 HOW TO CORRECT PROBLEMS IN THE MACHINE Problem Cause Action Oil is dripping The oil seal is worn. Contact an authorized Delco service person. Chemical not Chemical control valve Tighten all fittings. Check for leaks in plastic picking up. leaking around fittings.
-
Page 16: How To Correct Problems In The Machine
Incorrect voltage or frequency. Check the voltage and frequency. The motor is wet. Contact an authorized Delco service person. The coils are limed. Delime the coils. See Operator Safety Manual The nozzle is dirty. Remove and clean the nozzle. - Page 17 No spark and no pilot gas. No main Power. Check breakers or fuses. Faulty transformer. Contact an authorized Delco service person. Faulty vac switch. Contact an authorized Delco service person. Faulty limit switch, high limit switch. Contact an authorized Delco service person.
- Page 18 Notes: ________________________________________________________________________________________________________ ________________________________________________________________________________________________________ ________________________________________________________________________________________________________ ________________________________________________________________________________________________________ ________________________________________________________________________________________________________ ________________________________________________________________________________________________________ ________________________________________________________________________________________________________ ________________________________________________________________________________________________________ ________________________________________________________________________________________________________ ________________________________________________________________________________________________________ ________________________________________________________________________________________________________ ________________________________________________________________________________________________________ ________________________________________________________________________________________________________ ________________________________________________________________________________________________________ ________________________________________________________________________________________________________ ________________________________________________________________________________________________________ ________________________________________________________________________________________________________ ________________________________________________________________________________________________________ ________________________________________________________________________________________________________ ________________________________________________________________________________________________________ ________________________________________________________________________________________________________ ________________________________________________________________________________________________________ ________________________________________________________________________________________________________ ________________________________________________________________________________________________________ ________________________________________________________________________________________________________ Page 18...
-
Page 19: Assembly Drawing No. 1
Delco Avengers 1000-3 NG/LP, (Single Phase) Assembly Drawing No. 1 Machine Layout Page 19... -
Page 20: Assembly Drawing No. 2
Delco Avengers 1000-3 NG/LP (Single Phase) Assembly Drawing No. 2 Page 20... -
Page 21: Parts List
199161 Valve Pilot Shut Off x x x x 52758A Clamp, Grounding x x x x 57005A Pilot Burner Delco x x x x 197523 Pressure Regulator- LP 56707A Pilot Orifice .014 191099 Pressure Regulator Adapter 85804A Screw 1⁄4- 20 x 1/2... -
Page 22: Assembly Drawing No. 3
Delco Avengers 1000-3 NG/LP (Single Phase) Assembly Drawing No. 3 Page 22... -
Page 23: Parts List
Delco Avengers 1000- 3 NG/LP (Single Phase) Drawing No. 3 Parts List Ref. Part No. Qty. Description 69133A Float Tank Avenger S.S. x x x x 196133 Nozzle Spray 5.5x40°x¼"SS 196170 " " 8.0 x 40° x ¼"SS 193947 Grommet Rubber 7/16 ID x 15/16" x x x x 197051 Nipple Coupler Quick 1/4"... -
Page 24: Assembly Drawing No. 4
Delco Avengers 1000-3 NG/LP (Single Phase) Assembly Drawing No. 4... -
Page 25: Parts List
77039B Label, Made in the USA x x x x 77027A Label, Warning x x x x 72139A Decal, Shut Down Delco x x x x 77029B Label, Warning Belt Guard x x x x 77060A Label, Machine Avenger 77061A "... -
Page 26: Pump Drawing 1000-3 Ng/Lp
DELCO Avenger 1000- 3 NG/LP (Single Phase) Pump Drawing... -
Page 27: Parts List
DELCO Avengers 1000- 3 NG/LP (Single Phase) Pump Parts List Ref. Part No. Description Ref. Part No. Description IP-400-04 Hex Head Cap Screw (M8 x 70) IP-500-35 Socket Cap Screw (M6 x 30) IP-200-46 Plunger Retaining Screw Ref. Part No. -
Page 28: Electrical Schematic With Shut Down Timer
DELCO Avengers 1000-3 NG/LP (Single Phase) Electrical Schematic... -
Page 29: Electrical Schematic Without Shut Down Timer
Notes: ________________________________________________________________________________________________________ ________________________________________________________________________________________________________ ________________________________________________________________________________________________________ ________________________________________________________________________________________________________ ________________________________________________________________________________________________________ ________________________________________________________________________________________________________ ________________________________________________________________________________________________________ ________________________________________________________________________________________________________ ________________________________________________________________________________________________________ ________________________________________________________________________________________________________ ________________________________________________________________________________________________________ ________________________________________________________________________________________________________ ________________________________________________________________________________________________________ ________________________________________________________________________________________________________ ________________________________________________________________________________________________________ ________________________________________________________________________________________________________ ________________________________________________________________________________________________________ ________________________________________________________________________________________________________ ________________________________________________________________________________________________________ ________________________________________________________________________________________________________ ________________________________________________________________________________________________________ ________________________________________________________________________________________________________ ________________________________________________________________________________________________________ ________________________________________________________________________________________________________ ________________________________________________________________________________________________________... - Page 30 1111 E. Lake Francis Dr. • Siloam Springs, AR 72761 • 1-800-BUY-DELCO...
