Page 1: Operators Manual
Pressure Washers and Accessories KING BRUTE ( PN 09301 A ) Operators Manual and Parts Lists Rev1 11-07 Delco Pressure Washers LIT-KING-DEL Manual Page 1... -
Page 2: Limited Warranty
LIMITED WARRANTY DELCO® CLEANING SYSTEMS, we distribute top quality industrial / commercial / personal pressure washers that are designed for heavy-duty use, maximum reliability, durability, and long life. Our pressure washers are built for all duty applications and steady use due to higher quality levels. The manufacturer of this product agrees to repair or replace designated parts that prove defective within the warranty period of one (1) year listed in the chart. - Page 3 Parts / Components High Pressure Pumps Engines Electric Motors (if applicable) Burners (hot water machines) Hot Water Burner Coil (hot water machines) Frame Accessories Warranty Period and Details Five (5) year limited manufactuer warranty on pump workmanship and defects in material. Lifetime on forged brass manifold.
-
Page 4: Important Safety Precautions
IMPORTANT SAFETY PRECAUTIONS Please read the following instructions before installing and operating this equipment. DANGER THIS EQUIPMENT CAN BE HAZARDOUS TO OPERATOR SAFETY AND ONLY AUTHORIZED PERSONNEL WHO HAVE READ AND UNDERSTAND THE INSTALLATION AND OPERATION MANUAL SHOULD BE PERMITTED TO OPERATE THIS EQUIPMENT. DO NOT LEAVE WAND UNATTENDED WHILE EQUIPMENT IS RUNNING. - Page 5 14. Always cool down coil. DO NOT’S DO NOT - UNDER ANY CIRCUMSTANCES - POINT THE HIGH PRESSURE NOZZLE AT YOURSELF, OTHER PEOPLE, OR ANIMALS! 1. DO NOT use an undersized discharge nozzle. 2. DO NOT disconnect the pressure hoses or wand while the equipment is HOT, PRESSURIZED or RUNNING.
-
Page 6: Installation
INSTALLATION 1. LOCATION Avoid operating units in small areas or near exhaust fans. Adequate oxygen is needed for combustion or dangerous carbon monoxide will result. Stationary units should be installed in accordance with local plumbing and heating codes. 2. FUEL SUPPLY Oil Fired Units: Fill fuel tank with clean kerosene, No. -
Page 7: Operating The Machine
OPERATING THE MACHINE PRE-OPERATING INSTRUCTIONS 1. Connect the swivel end of the discharge hose to the cleaning gun. 2. Attach the hose to the machine outlet. 3. Check the fuel level in the fuel tank. Add fuel if required. It is best to keep fuel tank full during nonworking conditions. - Page 8 SHUT DOWN INSTRUCTIONS 1. If the burner is on turn control switch to position 1(pump). 2. Run water through the pump until cool water flows from the cleaning gun. Failure to do this could result in increased coil scaling. 3. Turn the control switch to off. 4.
-
Page 9: Maintenance Of Components
MAINTENANCE OF COMPONENTS PUMPS 1. Refer to pump section in this manual for your model of equipment. 2. Change pump oil after the first 25 hours of use. hours or 3 months, whichever comes first. A. Disconnect power supply. B. Remove drain plug on pump and drain oil. C. - Page 10 6. FUEL PUMP: To bleed air out of fuel pump, open air bleed valve on side of fuel pump. Turn machine and burner ON. When fuel looks clear (NOT FOAMING), close air bleeding valve. Air is out of fuel lines and fuel pump. A.
- Page 11 DE-SOOTING COIL Poor grades of fuel oil or inadequate combustion air will cause heavy soot build up on the outside surface of the heating coil. This will insulate the coil and restrict air flow through the coil, further aggravating the soot build up. To clean off soot, add Red Devil Soot Remover, using manufactures mixing instructions, or remove coil and clean thoroughly, or Call a Factory Authorized DELCO Dealer.
-
Page 12: Diagnosis And Maintenance
DIAGNOSIS AND MAINTENANCE PROBLEM Low Pressure Worn nozzle Belt slippage. Air leak in inlet plumbing. Pressure gauge inoperative or not registering accurately. Relief valve stuck partially plugged or improperly adjusted. Worn seat or valves. Inlet suction strainer clogged or improperly sized. - Page 13 Notes: Manual Page 13...
- Page 14 Repair Kits Valve Kit # PPA1554 Piston Kit # PPA1555 Water Seal Kit #PPA 1556 Qty 6 of each part Qty 3 of each part Qty 3 of each part included per kit included per kit included per kit Part # Description PPA1501 O-Ring PPA1502 TBD...
- Page 15 Repair Kits Part # Description PPA1560 PPA1561 Screw PPA1562 PPA1563 KnobUnloader PPA1564 AdjustmentBarrel PPA1565 RollPin PPA1567 SpringGuide PPA1568 UpperPlate PPA1569 Spring PPA1570 Lower Plate PPA1572 Piston PPA1573 O-Ring PPA1574 PistonGuide PPA1575 O-Ring PPA1576 O-Ring PPA1577 ByPassJet PPA1578 Seat PPA1579 O-Ring PPA1580 Valve Housing PPA1581...
- Page 16 BURNER (Beckett 12V) COMPONENT LOCATOR & PARTS LIST Ref.No. Part No. Qty. Description 29601A Air Shutter 29602A Air Band 29603A Escutcheon Plate 29604A Gasket, Square Plate 29605A Air Tube Flange Assembly 193871 Flange Gasket 45027A Motor 962139 Mounting Screws 1/4" - 20NC x 5/8 29606A Blower Wheel (R.W.B.
- Page 17 ELECTRICAL SCHEMATIC (12VDC) Manual Page 17...
- Page 18 GUNVALVE AND HOSE ASSEMBLY COMPONENT LOCATOR Manual Page 18...
- Page 19 GUNVALVE AND HOSE ASSEMBLY COMPONENT LOCATOR Ref. No. Qty. Part No. QC-251-22 QC-250-51 GE-600-36 GC-590-40 QC-381-22 192278 DH-477-50 QC-380-43 192276 DH-166-50 197055 DH-499-50HP Manual PARTS LIST Description O-Ring / O-Anillo Female Socket, ¼ / Ancla Hembra, ¼ Extension Tube, 3 ft / Tubo de Extensión, 3 ft Spray Gun / Pistola Aerografica O-Ring / O-Anillo Quick Coupling Socket, 3/8 / Manguito de Acomplamiento Rápido, 3/8...
- Page 20 GC 590-40 GUNVALVE COMPONENT LOCATOR Manual Page 20...
- Page 21 GC 590-40 GUNVALVE COMPONENT LOCATOR PARTS Ref. Qty. Part No. GC-765-14 8001660 GC-765-75 GC-764-44 8002258 GC-765-22 GC-764-20 GC-764-18 8001661 GC-764-41 GC-764-38 GC-764-36 GC-764-32 GC-764-30 GC-765-16 GC-765-30 GC-765-53 8000650 8000168 GC-764-50 GC-765-54 RK-775-75 Manual LIST Description Housing (Right) / Carcasa (Derecho) Housing (Left) / Carcasa (Izquierdo) Trigger / Gatillo Pin / Pasador...
