  • Page 1 Pressure Washers Eliminator 2000-4,1000-5 NG/LP 5 HP Single & 3 Phase Operators Manual Replacement Parts Book Delco Pressure Washers PN LIT-ELIM-DEL Rev. 3-07...
  • Page 2 Should you experience any difficulty with your Delco pressure washer, please contact your nearest Delco Distributor immediately. We are aware of your investment in an Delco pressure washer, therefore, our prime concern is that you become one of our “satisfied” owners. Please feel free to send us your comments and ideas.
  • Page 3 PRESSURE WASHER LIMITED WARRANTY 1. DELCO Cleaning Systems, LLC warrants its products for a period of one year from the date of pur- chase, against defects in material and/or workmanship. The warranty covers parts and labor, but excludes transportation. 2. Normal wear and tear items such as valves, seals, etc., are warranted for the initial 30 days following purchase by the end-user.

  • Page 4: Table Of Contents

    Table of Contents Operator Safety Instructions ............5 - 6 Introduction and Machine Specifications .

  • Page 5: Operator Safety Instructions

    Tampering with the machine's factory preset unloader valve settings and/or the pressure relief valve setting could result in a machine explosion. Do not attempt to change the settings. Discontinue use if a malfunction occurs and contact your local authorized Delco distributor.
  • Page 6 Operating a pressure washer with insufficient water flow can damage the pump. Water should be turned on full-force to avoid insufficient water flow. CAUTION: Your machine warranty will be voided if anything other than genuine Delco parts are used on your pressure washer. Always use Delco parts for replacement. Page 6...

  • Page 7: Introduction And Machine Specifications

    INTRODUCTION & MACHINE SPECIFICATIONS The Eliminator 1500-2000 LP and NG fired system can tackle the toughest industrial cleaning tasks. Standard features include dual belt driven triplex ceramic plunger pumps with low-water shut-off, 4.5 minute system shut down protection plus many more features, all built into a compact space-saving design. When you need a quick and efficient cleaning system in your maintenance program, you need the Eliminator.

  • Page 8: How To Prepare The Machine For Operation

    HOW TO PREPARE THE MACHINE FOR OPERATION NOTE: Following delivery of your Delco pressure washer, inspect the unit for shipping damage. Assembly: 1. Uncrate machine. Remove cleaner, parts package, gun and hose from shipping carton. 2. Assemble cleaner, gun, and hose. Do not install the pressure nozzle at this time.
  • Page 9 Stacking the Unit: If the cleaner is used in an enclosed area be sure there is plenty of ventilation.. Be sure the chimney is the same size as the stack on the cleaner. Poor draft will cause the unit to soot and not operate efficiently. When placing the unit for installation, keep in mind that the unit should be positioned in such a manner that the stack will be as straight as possible and protrude through the roof of the building at a proper location and at sufficient height to eliminate downdraft.

  • Page 10: Installation & Servicing Instructions

    Maintenance and repairs performed by unauthorized personnel could result in damage or injury. Servicing of this unit must always be referred to an authorized Delco distributor. Repairs, adjustments, and servicing should be limited to the operations listed below.
  • Page 11 WARNING: For your safety, if you smell gas: (A) turn off gas at line valve or meter, (B) open windows, (C) do not touch electrical switches, (D) extinguish all open flames, (E) immediately call your gas supplier. 4. When using L.P.gas, the Control must be equipped with a regulator. Make sure that no gas is present in the area before putting machine in operation.
  • Page 12 WATER in any way, DO NOT try to use it. It must be replaced. DO NOT attempt repair on gas valve . It must be replaced. DO NOT attempt repair on gas control or machine. Call an authorized Delco distributor for service. Tampering is DANGEROUS and voids all warranties.

  • Page 13: Operating Instructions

    5 minutes before resetting the system. To reset turn the main switch to pump #1/only, then back to burner #2. Repeat if needed. OPERATING INSTRUCTIONS Following delivery and installation of your Delco pressure washer, inspect the unit for shipping damage and follow these directions. 1. Observe all danger, warning, and caution statements.

  • Page 14: Maintenance

    1. Use a water softener on your water system if it is known to be high in mineral content. 2. Use only high quality Delco chemicals and follow the manufacturer's mixing instructions. 3. The cleaner should be flushed thoroughly after using the chemical solutions.
  • Page 15 NOTE: Change the oil after the first 50 hours of use and then after every 500 hours of use. SAE 30 weight oil must be used. Freeze-Up Prevention: To prevent freeze-up follow these instructions: 1. Drain the float tank. 2. Remove the spray nozzle from the wand. 3.

  • Page 16: How To Correct Problems In The Machine

    HOW TO CORRECT PROBLEMS IN THE MACHINE Problem Cause Action Oil is dripping The oil seal is worn. Contact an authorized Delco service person. Chemical not Chemical control valve Tighten all fittings. Check for leaks in plastic picking up. leaking around fittings.
  • Page 17 There is air in the suction line. Check the water supply. Make sure all fittings are tight. The valves are dirty. Contact an authorized Delco service person. The bearings are worn. Contact an authorized Delco service person. The pump check valve springs are worn.
  • Page 18 Notes: ________________________________________________________________________________________________________ ________________________________________________________________________________________________________ ________________________________________________________________________________________________________ ________________________________________________________________________________________________________ ________________________________________________________________________________________________________ ________________________________________________________________________________________________________ ________________________________________________________________________________________________________ ________________________________________________________________________________________________________ ________________________________________________________________________________________________________ ________________________________________________________________________________________________________ ________________________________________________________________________________________________________ ________________________________________________________________________________________________________ ________________________________________________________________________________________________________ ________________________________________________________________________________________________________ ________________________________________________________________________________________________________ ________________________________________________________________________________________________________ ________________________________________________________________________________________________________ ________________________________________________________________________________________________________ ________________________________________________________________________________________________________ ________________________________________________________________________________________________________ ________________________________________________________________________________________________________ ________________________________________________________________________________________________________ ________________________________________________________________________________________________________ ________________________________________________________________________________________________________ ________________________________________________________________________________________________________ Page 18 3000-4, 2000-5 NG/LP...

  • Page 19: Assembly Drawing No. 1

    Delco Eliminator 2000-4, 1000-5, NG/LP 1 & 3 Phase Drawing #1 Machine Layout...

  • Page 20: Assembly Drawing No. 2

    Delco Eliminator 2000-4, 1000-5 NG/LP, 1 & 3 Phase Drawing #2...

  • Page 21: Parts List

    199161 Valve Pilot Shut Off x x x x 52758A Clamp, Grounding x x x x 57005A Pilot Burner Delco x x x x 197523 Pressure Regulator- LP 56707A Pilot Orifice .014 191099 Pressure Regulator Adapter 85804A Screw 1⁄4- 20 x 1/2...

  • Page 22: Assembly Drawing No. 3

    Delco Eliminator 2000-4 & 1000-5 NG/LP 1 & 3-Phase...

  • Page 23: Parts List

    Delco Eliminator 2000-4 NG/LP, 1000-5 NG/LP (Single & 3 Phase) Drawing No. 3 Parts List Ref. Part No. Qty. Description 69133A Float Tank Avenger S.S. x x x x 196133 Nozzle Spray 5.5x40°x1⁄4"SS 196170 " " 8.0 x 40° x 1⁄4"SS 193947 Grommet Rubber 7/16 ID x 15/16"...

  • Page 24: Assembly Drawing No. 4

    Delco Eliminator 2000-4 & 1000-5 NG/LP, 1 & 3-Phase Drawing #4...

  • Page 25: Parts List

    77039B Label, Made in the USA x x x x 77027A Label, Warning x x x x 72139A Decal, Shut Down Delco x x x x 77029B Label, Warning Belt Guard x x x x 77060A Label, Machine Avenger 77061A "...

  • Page 26: Pump Drawing 2000-4, 1000-5 Ng/Lp

    Delco Eliminator Models 2000-4, 1000-5 NG/LP 1 & 3-Phase - Pump 45947A PUMP PARTS LIST Recommended Grades of Pump Oil: High quality SAE #30 -40 non-detergent oil. PUMP CAPACITY: 40 FLUID OUNCES Ref No. Qty. Part No. Description 1 ....1 ....IP 400-02 ......MANIFOLD 2 ....

  • Page 27: Parts List & Repair Kits

    Delco Eliminator Models 2000-4, 1000-5 NG/LP 1 & 3-Phase - Pump 45947A Pump Parts List Cont. Ref No. Qty. Part No. Description 21 ....1 ....IP 500-90 ......CRANKSHAFT (IP 305-14 PUMP) 21 ....1 ....IP 500-20 ......CRANKSHAFT (IP 255-16 PUMP) 22 ....
  • Page 28 Repair Kits for Pump 45947A (for machines up to 3500 PSI) RK 371-01 VALVE REPAIR KIT Ref No.Qty.Part No. Description 9 ..6 ..PF 026-01 ..O-RING (VALVE PLUG) 11 ..6 ..IP 100-23 ..VALVE ASSEMBLY RK 711-02B PLUNGER SEAL REPAIR KIT Ref No.Qty.Part No.

  • Page 29: Electrical Schematic With Shut Down Timer

    DELCO Eliminator 2000-4 NG/LP, 1500-5 NG/LP (Single Phase) Electrical Schematic...

  • Page 30: Electrical Schematic Without Shut Down Timer

    Delco Eliminator 2000-4 & 1000-5 NG/LP 3 Phase with shut down timer. Electrical Schematic 2/2010 Addendum...
  • Page 31 Notes: ________________________________________________________________________________________________________ ________________________________________________________________________________________________________ ________________________________________________________________________________________________________ ________________________________________________________________________________________________________ ________________________________________________________________________________________________________ ________________________________________________________________________________________________________ ________________________________________________________________________________________________________ ________________________________________________________________________________________________________ ________________________________________________________________________________________________________ ________________________________________________________________________________________________________ ________________________________________________________________________________________________________ ________________________________________________________________________________________________________ ________________________________________________________________________________________________________ ________________________________________________________________________________________________________ ________________________________________________________________________________________________________ ________________________________________________________________________________________________________ ________________________________________________________________________________________________________ ________________________________________________________________________________________________________ ________________________________________________________________________________________________________ ________________________________________________________________________________________________________ ________________________________________________________________________________________________________ ________________________________________________________________________________________________________ ________________________________________________________________________________________________________ ________________________________________________________________________________________________________ ________________________________________________________________________________________________________...
  • Page 32 This book has important information for the use and safe operation of this machine. Failure to read this book prior to operating or attempting any service or maintenance procedure to your Delco machine could result in injury to you or to other personnel; damage to the machine or to other property could occur as well. You must have training in the operation of this machine before using it.
