MOUNTING THE LENS

1
C mount type lens
2
3
2
CS mount
type lens
5
English
Please use a DC type auto-iris lens (sold separately).
Check the lens mount
Do not use a lens if the length "
camera and prevent proper installation.
1
Remove the lens mount cap from the camera.
2
Install the auto-iris lens.
CS mount type lens
Carefully align the lens mount with the camera opening, then turn the lens slowly to install it.
C mount type lens
To allow for flange-back adjustment, install the C-mount adaptor (option) on the lens mount, then carefully
align the lens mount with the camera opening and turn the lens slowly to install it.
3
Connect the lens plug to the lens iris output connector (LENS) on the side of the camera.
Depending on the type of lens, the shape of the lens plug may differ. In this case, consult your dealer or an
Authorized Sanyo Service Center.
L 5
" is more than mm. That may damage the
L
