- Page 1 NEW GENERATION INTERNATIONAL DESIGN GUIDE...
-
Page 2: Table Of Contents
Contents Integrated Refrigeration Features and specifications are subject to change at any time without notice. Specifications Throughout this guide, dimensions may IMPORTANT NOTE: Custom Panels vary by ± 3 mm. Wine Storage Specifications Custom Panels Sub-Zero Warranty English... -
Page 3: Integrated Refrigeration
SUB-ZERO INTEGRATED REFRIGERATION Integrated Refrigeration With custom front panels and hardware, Sub-Zero invented KEY FEATURES integrated columns, tall and drawer models that disappear • Custom front panels and hardware allow for infinite into the decor. Integrated units fit flush with other cabinets, design options. -
Page 4: Specifications
SUB-ZERO INTEGRATED REFRIGERATION Specifications Overall Dimensions COLUMN INTERIOR CAPACITY R (L) F (L) COLUMN 610 mm ICBIC-18FI ICBIC-24R 114 mm ICBIC-24FI ICBIC-30RID ICBIC-30FI ICBIC-36RID TALL 2134 1765 ICBIT-30RID ICBIT-30CIID ICBIT-36CIID DRAWER ICBID-30RP ICBID-30CI ICBID-36CI SHIPPING WEIGHT COLUMN ICBIC-18FI ICBIC-24R, ICBIC-24FI... - Page 5 SUB-ZERO INTEGRATED REFRIGERATION Overall Dimensions TALL DRAWER 610 mm 610 mm 6 mm 114 mm 10 mm 2134 1140 92 mm *864 mm 889 mm MIN TO 10 mm 10 mm 92 mm *2121 mm 2146 mm MIN TO DRAWER...
- Page 6 If a dual installation kit is not specified, a minimum 51 mm filler strip is required between units. Dual installation kits are available through an authorized Sub-Zero dealer. For questions regarding the installation, contact your authorized Sub-Zero dealer. DETAIL...
- Page 7 SUB-ZERO INTEGRATED REFRIGERATION Electrical Plumbing The electrical supply must be located within the shaded The water supply line should be located within the shaded area shown in the illustration and chart below. A separate area shown in the illustrations below. The water supply line circuit, servicing only this appliance is required.
-
Page 8: Custom Panels
SUB-ZERO INTEGRATED REFRIGERATION Custom Panels For integrated models, custom door panels and handle TYPICAL PANEL DIMENSIONS hardware must be provided. Refer to the panel requirements chart and typical panel dimensions. The thickness of the custom panel can vary. A minimum 16 mm thick panel is required, but the thickness can be increased provided it does not exceed the weight limit. - Page 9 SUB-ZERO INTEGRATED REFRIGERATION Custom Panels DOOR PANEL HEIGHT TOE KICK CLEARANCE The height of the custom door panel can extend beyond the The height of the toe kick area can extend beyond the typical panel height, provided it does not exceed the weight typical toe kick height, provided it does not exceed the limit.
- Page 10 SUB-ZERO INTEGRATED REFRIGERATION Handle Hardware Optional stainless steel tubular and pro handles are avail- able through an authorized Sub-Zero dealer. Refer to the chart and illustration below for the length and stud spacing of standard handles for integrated models. HANDLE LENGTH...
- Page 11 SUB-ZERO INTEGRATED REFRIGERATION Maximum Door Opening FULL-SCALE TEMPLATE As the panel width and/or depth increases, so does the potential for panel interference. Interference may be minimized by utilizing the 90° door stop. 19 mm PANEL DOOR OPEN MAXIMUM 105° 3 mm...
-
Page 12: Wine Storage
SUB-ZERO WINE STORAGE Wine Storage Wine finds a well-deserved place of honor in a Sub-Zero KEY FEATURES wine storage unit. Every detail is designed to ensure better • Custom front panels and hardware allow for infinite wine preservation. Cherrywood-faced racks, soft lighting, design options. -
Page 13: Specifications
SUB-ZERO WINE STORAGE Specifications Overall Dimensions COLUMN INTERIOR CAPACITY R (L) (750 ml) COLUMN 610 mm ICBIW-18 59 Bottles ICBIW-24 102 Bottles 114 mm ICBIW-30 146 Bottles TALL ICBIW-30R 86 Bottles SHIPPING WEIGHT 2134 1765 COLUMN ICBIW-18 ICBIW-24 ICBIW-30 TALL... - Page 14 SUB-ZERO WINE STORAGE Overall Dimensions TALL 610 mm 114 mm 2134 1140 10 mm 10 mm 92 mm *2121 mm 2146 mm MIN TO 45 mm TALL ICBIW-30 762 mm 143 mm 724 mm English...
- Page 15 If a dual installation kit is not specified, a minimum 51 mm filler strip is required between units. Dual installation kits are available through an authorized Sub-Zero dealer. For questions regarding the installation, contact your authorized Sub-Zero dealer. DETAIL SIDE VIEW...
- Page 16 SUB-ZERO WINE STORAGE Electrical The electrical supply must be located within the shaded area shown in the illustration and chart below. A separate circuit, servicing only this appliance is required. A ground fault circuit interrupter (GFCI) is not recommended and may cause interruption of operation.
- Page 17 SUB-ZERO WINE STORAGE Custom Panels For wine storage models, custom door panels and handle TYPICAL PANEL DIMENSIONS hardware must be provided. Refer to the panel requirements chart and typical panel dimensions. Do not install a solid panel on the glass door unit. A solid door is available as a sales accessory through an authorized Sub-Zero dealer.
- Page 18 SUB-ZERO WINE STORAGE Custom Panels DOOR PANEL HEIGHT TOE KICK CLEARANCE The height of the custom door panel can extend beyond the The height of the toe kick area can extend beyond the typical panel height, provided it does not exceed the weight typical toe kick height, provided it does not exceed the limit.
- Page 19 SUB-ZERO WINE STORAGE Handle Hardware Optional stainless steel tubular and pro handles are avail- able through an authorized Sub-Zero dealer. Refer to the chart and illustration below for the length and stud spacing of standard handles for wine storage models.
- Page 20 FOR RESIDENTIAL USE ONLY FULL TWO YEAR WARRANTY For two years from the date of original installation, your Sub-Zero product warranty covers all parts and labor to repair or replace, under normal residential use, any part of the product that proves to be defective in materials or workmanship.
- Page 21 Sub-Zero, Sub-Zero & Design, Dual Refrigeration, Constant Care, The Living Kitchen, Great American Kitchens The Fine Art of Kitchen Design, and Ingredients are registered trade- marks and service marks of Sub-Zero, Inc. Wolf, Wolf & Design, Wolf Gourmet, W & Design and the color red as applied to knobs are registered trademarks and service marks of Wolf...
- Page 22 SUB-ZERO, INC. P O BOX 44848 MADISON, WI 53744 USA WWW.SUBZERO.COM I S Z N G D G 5 / 2 0 1 3...
