CAUTION: High Voltage Wires
WARNING Electricity is dangerous. Before commencing work,
ensure that you read and understand these instructions and isolate the
relevant circuit. This product should only be installed by a qualified
electrician or heating engineer and should be installed in accordance to
BS 7671 (IEE Wiring Regulations), or to another equivalent standard.

Introduction

The NS1002 series is a 2 channel programmer for controlling up to 2 zones. Each zone can be configured
to be either a timed zone (eg hot water circuit, towel rail circuit) or a central heating zone by adding our
Wireless Thermostat to that channel. The unit will replace most existing programmers and will fit over a
standard single or double BS4662 back box.

Specifications

Power Supply:
Switch Type:
Switch Rating:
Number of programmes:
day or 7 day.

Installation

Tools Required (Not supplied)
Philips screwdriver
Flat blade screwdriver
Long nosed pliers
Isolate the existing supply, then remove the existing Programmer (if fitted). Make a careful note of all
wiring locations of the existing programmer before removing any wires. The NS1002 will replace most
existing programmers on the market.
Then secure the wall mount onto the single or double gang back box using the two M3 screws provided.
This unit is designed for fixed wiring only. Wire the unit up following the appropriate circuit schematic
for your heating system type, ensuring that all wires are securely held and that no bare copper is visible
NS1002 Installation Guide
230V~ 50...60Hz, 2.5W (Max)
2 x SPDT
3 Amps Total load on all Channels
Up to 10 switch points per day per channel, configurable as every day, 5/2
Inspire Home Automation
www.inspirehomeautomation.co.uk
contact@inspirehomeautomation.co.uk
01202 798390
Rev 1.3
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NS1002 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Inspire NS1002

  • Page 1: Specifications

    Introduction The NS1002 series is a 2 channel programmer for controlling up to 2 zones. Each zone can be configured to be either a timed zone (eg hot water circuit, towel rail circuit) or a central heating zone by adding our Wireless Thermostat to that channel.
  • Page 2 (Table 1) may be of assistance. All diagrams are in schematic form and earths have been omitted on the drawings for clarity. The NS1002 is a class 2 device and does not require an earth. Ensure that you do not break earth continuity to the rest of the circuit.
  • Page 3 Programmer Programmer Adding a NS1002 to an existing Inspire Home Automation System with a NS1001 Wired Thermostat In this case, the Thermostat circuit should bypass the programmer so that the time control is done entirely by the Thermostat. See wiring diagrams fig. 5 and fig. 6.
  • Page 4 ° Wall mount screws are the correct size Hold the room thermostat in place and lightly tighten the screws underneath to secure the unit – these screws only need the lightest of pressure and must not be over tightened Inspire Home Automation www.inspirehomeautomation.co.uk contact@inspirehomeautomation.co.uk...
  • Page 5 The middle button is used for pairing. Colour Status Button Function Not paired to Gateway Enter Pairing Mode Orange Not connected to Gateway Enter Pairing Mode Green Connected to Gateway Enter Pairing Mode Inspire Home Automation www.inspirehomeautomation.co.uk contact@inspirehomeautomation.co.uk 01202 798390...
  • Page 6 Software Version 3.xx press and hold the ‘M’ and ‘S’ keys on the Room Thermostat until the RF indicator in the lower left hand corner starts to flash. Setting up and using your Room Thermostat This is an online guide and can be found at http://www.inspirehomeautomation.co.uk/manuals Inspire Home Automation www.inspirehomeautomation.co.uk contact@inspirehomeautomation.co.uk 01202 798390...
  • Page 7 HONEYWELL ST669 HONEYWELL ST6300, ST6400 HONEYWELL ST900A, ST900C INVENSYS LIFESTYLE LP241, LP522, LP722 POTTERTON EP2000, EP3000 RANDALL 702 SALUS EP200 SMITHS IND. CENTROLLER 1000 N SWITCHMASTER 800, 805, 900, 9000, 9001 Table 1 Inspire Home Automation www.inspirehomeautomation.co.uk contact@inspirehomeautomation.co.uk 01202 798390...
  • Page 8 © Copyright Inspire Home Automation 2015 Our hot water controller is a perfect partner for our wireless Thermostats. Find out more online! Inspire Home Automation www.inspirehomeautomation.co.uk contact@inspirehomeautomation.co.uk 01202 798390...
