HelmView™
Accessory Kit
Installation Guide
00-02-0629
08-08-07
Section 78

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HelmView GPS Kit and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Murphy HelmView GPS Kit

  • Page 1 HelmView™ Accessory Kit Installation Guide 00-02-0629 08-08-07 Section 78...
  • Page 2 The latest version of this manual can be found at www.fwmurphy.com. Warranty A limited warranty on materials and workmanship is given with this FW Murphy product. A copy of the warranty may be viewed or printed by going to www.fwmurphy.com/support/warranty.htm Please read the following information before installing.
  • Page 3: Table Of Contents

    Table of Contents HelmView Accessory Kit Structure... 1 HelmView Mounting Kit ...1 GPS Kit ...2 NMEA Backbone Kit...2 Multisensor Kit...3 Gimbal Mount...3 Remote Keypad ...4 Mounting Instructions ... 6 ® Installing an NMEA 2000 Cable and Connector Network Basics...7 Installing Terminators ...8 Supplying Power ...8 Ground the Network ...9 Checking Your Network ...9...
  • Page 4 (THIS PAGE INTENTIONALLY LEFT BLANK)
  • Page 5: Helmview Accessory Kit Structure

    HelmView Accessory Kit Structure The following accessory kits are available for the HelmView Model HV1000: • HelmView Mounting Kit (PN 78-70-0232) • GPS Kit (PN 78-70-0261) • NMEA Backbone Kit (PN 78-70-0266) • Multisensor Kit (PN 78-70-0267) • EVC Kit (PN 78-70-0366) •...
  • Page 6: Gps Kit

    GPS Kit This kit includes a Map card and connections. NOTE: Optional detailed area upgrades for map cards may be purchased at any Navionics dealer. NMEA Backbone Kit Section 78 08-08-07 - 2 - 00-02-0629...
  • Page 7: Multisensor Kit

    Multisensor Kit Gimbal Mount NOTE: Mounting method and hardware used depend on mounting surface. May be mounted using lag bolts or, if surface is not thick enough, using nuts and bolts. Also, a “pass-through” hole will need to be cut out for all cables running up to the display.
  • Page 8: Remote Keypad

    Remote Keypad The Remote Keypad works with Murphy’s PV1000 and HV1000 model displays. It allows a user to enter keypad commands whenever display installations are not conveniently located for easy access. The keypad contains the same navigation, menu and selection keys as found on the displays, making it an easy transition to use.
  • Page 9 Product Dimensions Electrical Connection Section 78 00-02-0629 08-08-07 - 5 -...
  • Page 10: Mounting Instructions

    Mounting Instructions Mounting options are shown below. Mounting option 1: On a mounting flange and 1-inch pipe (not included in kit) using provided flange, screws and washers. NOTE: Must be located as close as possible to the center of gravity of the boat.
  • Page 11: Installing An Nmea 2000 ® Network

    Installing an NMEA 2000 Installing an NMEA 2000 consists of interconnecting NMEA 2000 electronic devices using plug-and-play cables and connectors. The following pages provide a brief description of how to setup a NMEA 2000 network using five basic steps: 1. Cable and Connector Network Basics 2.
  • Page 12: Installing Terminators

    Maximum Number of Devices A maximum of 50 physical devices shall be connected to the network, and the disconnection of any device shall not interrupt any other device on the network. NMEA 2000 Cable Micro cables contain five wires: One twisted pair (red and black) for 12VDC power, one twisted pair (blue and white) for signal and a drain wire (bare).
  • Page 13: Ground The Network

    Maximum Power Supply Voltage Drop The NMEA 2000 network is designed to work properly as long as there is no more than a 1.5 volt difference in the power supply voltage between any two devices on the network. Therefore, you should perform an estimate of the voltage drop across a network using the following equation: Voltage Drop = 0.1 x Network Loads x Network Length x Cable Resistance / 100 Where:...
  • Page 14 Industries, Inc. This document, including textual matter and illustrations, is copyright protected by Murphy Industries, Inc., with all rights reserved. (c) 2007 Murphy Industries, Inc. Other third party product or trade names referenced herein are the property of their respective owners and are used for identification purposes only.
