Farfisa Si 5050 Technical Manual

Hide thumbs

Table of Contents

Quick Links

INDEX

Project monitors series

PuntoVirgola monitors series

Intercoms

Mody push-button panels

ErreP/R push-button panels

Power supply and control unit

Service modules

Video memory

Installation instructions

Working instructions

Troubleshooting

Installation diagrams WITH COAXIAL CABLE

Mody Videokit

Si 5000M One-way videokit with application of multipolar cable art.1304

One or multi-way diagrams

Si 5050 Video-intercom system with audio-video privacy

Si 5051 Multi-way combined intercom video-intercom system with audio-video privacy

Si 5150 Video-intercom system with two automatically switched entrances, one of which is only audio

Si 5250 Video-intercom system with two automatically switched video entrances

Si 5256 Video-intercom system with two automatically switched entrances, one with surveillance camera

Si 5350 Video-intercom system with three automatically switched video entrances

Si 5550 Multi-way video-intercom system with auxiliary audio entrances and one main video entrance according to

the stairway

Si 5551 Multi-way video-intercom system with auxiliary video entrances and one main video entrance according to

the stairway

- Working diagrams

- One way additional diagrams

- Multi-way additional diagrams

4+1 video-intercom system WITHOUT COAXIAL CABLE

Installation diagrams

Si 5800 One-way video-intercom system

Si 5801 Multi-way combined intercom and video-intercom system

Si 5850 Multi-way video-intercom system with two automatically switched entrances, one of which is only audio

Si 5851 Multi-way video-intercom system with two automatically switched video entrances

TECHNICAL MANUAL

Edition 1999

VIDEO-INTERCOM SYSTEM

(GB- '99)

Page

Table of Contents

Need help?

Do you have a question about the Si 5050 and is the answer not in the manual?

Questions and answers

Summary of Contents for Farfisa Si 5050

Page 1 Si 5000M One-way videokit with application of multipolar cable art.1304 One or multi-way diagrams Si 5050 Video-intercom system with audio-video privacy Si 5051 Multi-way combined intercom video-intercom system with audio-video privacy Si 5150 Video-intercom system with two automatically switched entrances, one of which is only audio...
Page 2: Intercoms
MONITORS Project series Wall-brackets for the PT5160, PT5160W and PT5160W-LCD monitors. WB5100. The wall bracket includes a WB5160. The wall bracket includes 2 termi- terminal board for connection to the nal boards for connection to the system, it is system, it is to be used when installing to be used when installing monitors with extra 2 - button monitors (control switch-ON buttons and/or 2 differentiated bells.
Page 3 MONITORS Project series Installation of the wall bracket WB5100 or WB5160 to the wall, using a 83.5mm back box and an expansion plug. Installation of the wall bracket WB5100 or WB5160 to the wall, by means of Installation of monitor onto the wall bracket. Dismounting of monitor from the wall bracket.
Page 4 MONITORS Project series Wall-brackets for the PT5660W monitor. WB5600. The wall bracket includes a WB5660. The wall bracket includes 2 termi- terminal board for connection to the nal boards for connection to the system, it is system, it is to be used when installing to be used when installing monitors with extra 2 - button monitors (control switch-ON buttons and/or 2 differentiated bells.
Page 5 MONITORS Project series 1283. Back-box for monitors PT5660W and PV1260. Place the box on the wall at a height of about 1.5m (4' 11") from the floor keeping the front edges flush-mounted and vertical to the fin- ished plaster. Installation of monitor onto the wall bracket. Supplementary push-buttons installation aaaaaaaaaaaaaaaaaaaa aaaaaaaaaaaaaaaaaaaa...
Page 6 MONITORS Project series Wall-brackets for the PT5860 and PT5860W monitors. WB5600. The wall bracket includes a WB5660. The wall bracket includes 2 termi- terminal board for connection to the nal boards for connection to the system, it is system, it is to be used when installing to be used when installing monitors with extra 2 - button monitors (control switch-ON buttons and/or 2 differentiated bells.
Page 7 MONITORS Project series Plugging in of monitor connectors to the terminal boards of wall bracket. Installation of monitor onto the wall bracket. Supplementary push-buttons installation Dismounting of monitor from the wall bracket. Audio privacy or intercommunicating service Taking out of button caps. Position for the intercom- municating service.
Page 8 MONITORS PuntoVirgola series Wall-brackets for the PV2160 and PV2160W monitors. WB2100. The wall bracket includes a WB2160. The wall bracket includes 2 termi- terminal board for connection to the nal boards for connection to the system, it is system, it is to be used when installing to be used when installing monitors with extra 2 - button monitors (control switch-ON buttons and/or 2 differentiated bells.
Page 9 MONITORS PuntoVirgola series Plugging in of monitor connectors to the terminal boards of wall bracket. Installation of monitor onto the wall bracket. Audio privacy or intercommunicating service Position for the intercommu- nicating service. Position for the audio privacy. WB2160 Supplementary push-buttons installation Inserting of extra buttons.
Page 10 MONITORS PuntoVirgola series Wall-brackets for the PV1260 monitor. For particular needs it is possible to WB1200. The wall bracket includes a termi- separate the common of the buttons nal board for connection to the system, it is to labeled P4, P5 and P6 by cutting the be used when installing 2 - button monitors W1 jumper located on the connecting (control switch-ON and door lock release),...
Page 11 MONITORS INTERCOMS PuntoVirgola series Project series PuntoVirgola series 1283. Back-box for PV1260 and PT5660W monitors. Place the box on the wall at a height of about 1.5m (4' 11") from the floor keeping the front edges flush-mounted and vertical to the fin- ished plaster.
Page 12: Push-Button Panels
PUSH-BUTTON PANELS MODY series Module frames complete with back box Push-button panel in aluminium composed of modular elements, able to resolve all installation requirements. Back boxes, module frames, elec- tric door speaker, camera, rain shelter and various button modules are the basic elements in this push-button panel line.
Page 13 PUSH-BUTTON PANELS MODY series ELECTRIC DOOR-SPEAKER 1 row push-button modules (amplifier) Modules for electric door speaker (amplifier) MD 10 MD 11 MD 12 Without call buttons 1 call button 2 call buttons MD 30. It consists of a double amplifier (receiver and Button modules transmitter) with adjustable volume of 2 channels.
Page 14 PUSH-BUTTON PANELS MODY series aaaaaaaaaaaa Openings for cables. Place the box of the camera unit at a height of about 1.65m from the floor keeping the front edges flush-mounted and vertical to the fin- ished plaster. Position the camera unit in such a way that solar rays or other direct light or intense Mounting of button module.
Page 15 PUSH-BUTTON PANELS MODY series Alignment of the panel. Hood covers Mounting of frame bottom and door speaker (amplifier). Modules insertion and wall fixing of rain shel- ter. Fixing of the hood cover between the back box and the module frame. Rain shelter Top fixing of the panel.
Page 16 PUSH-BUTTON PANELS 1 row push-button MODY series Example of Mody push-button panel installations. 1 call button 2 call buttons 3 call buttons 4 call buttons 5 call buttons 6 call buttons 7 call buttons 8 call buttons 10 call buttons 7 call buttons 8 call buttons 9 call buttons...
Page 17 PUSH-BUTTON PANELS 1 row push-button MODY series Composition board of Mody push-button panels. N° Compositions and Camera Door speaker Module for Button and info or Back box and Hood Rain calls dimensions module (amplifier) speaker blank modules module frame covers shelter 1 MD40 1 MD30...
Page 18 PUSH-BUTTON PANELS 2 row push-button MODY series Example of Mody push-button panel installations. 2 call buttons 4 call buttons 6 call buttons 8 call buttons 10 call buttons 12 call buttons 14 call buttons 16 call buttons 20 call buttons 14 call buttons 16 call buttons 18 call buttons...
Page 19 PUSH-BUTTON PANELS 2 row push-button MODY series Composition board of Mody push-button panels. N° Compositions and Camera Door speaker Module for Button and info or Back box and Hood Rain calls dimensions module (amplifier) speaker blank modules module frame covers shelter 1 MD40 1 MD30...
Page 20 PUSH-BUTTON PANELS MODY series CAMERAS AMPLIFIED DOOR STATIONS ACCESS CONTROL KEYPAD MD 40. MD 100. 1 button module. FC52. This module includes: It can be applied to all systems 4+1, intercom- Access control keypad with 12 digits and 2 - solid-state camera (CCD) with auto iris, municating systems, and video-intercom sys- relays for lock release.
Page 21 PUSH-BUTTON PANELS ErreP/R series ErreP/R - TM - NP/N series ErreP/R series CAMERA UNIT ELECTRIC DOOR SPEAKER AMPLIFIED DOOR STATIONS (amplifier) 337C. It features a double amplifier (receiver 1385R. and transmitter); receiver has volume con- The camera unit is used in the multi-way RP100.
Page 22 PUSH-BUTTON PANELS ErrreP/R series Installation notes Among the back-box of the camera unit and Place the box of the camera unit at a height Position the camera unit in such a way that the push-button panel apply, before mounting of about 1.5m from the floor keeping the front solar rays or other direct light or intense on to the wall, the tips and fair leads provided edges flush-mounted and vertical to the fin-...
Page 23: Power Supply And Control Unit
POWER SUPPLY AND CONTROL UNIT 1281. STABILIZED POWER SUPPLY WITH 1382. AUDIO-VIDEO TIMER. PRS210. TRANSFORMER. SWITCHING REGULATOR. Connected to the timer art.1382, allows to Connected to the stabilized power supply It is used to power the amplified external drive at low voltage a monitor (or 2 in parallel art.1281, it allows a video-intercom system to units MD100, MD200, RP100 and RP200, in FLAT type), a camera unit with a solid state...
Page 24: Service Modules
SERVICE MODULES 1273TV. EXCHANGER. 2443. RELAY AMPLIFIER FOR INTERCOM- 1471. RELAY UNIT. MUNICATING SYSTEMS. It is used in systems with 2 or more video It is suitable for video intercom systems where A low voltage, low current (DC/AC) unit, it entrances for switching automatically the it is necessary to have the intercommunicat- can switch voltages up to 50Vac/dc and 5A...
Page 25: Video Memory
VIDEO MEMORY 8-images video memory. It records the image, hour and date of the last Terminals Video input 1Vpp composite into 75Ω 8-persons which have made a call from the OUT Video output 1Vpp composite into 75Ω video-intercom panel. 12V Power supply 12V either ac or dc This video memory can be connected to any 12Vdc input (from the monitor) video-intercom system.
Page 26: Installation Instructions
INSTALLATION INSTRUCTIONS WIRE CROSS SECTION 1304. Multipolar cable with 10 distance terminal wires of different cross sections 165 Ft 100m 330 Ft 200m 660 Ft 300m 990 Ft and coaxial cable of 75Ω. It can be art. 1382 S mm² S mm²...
Page 27 INSTALLATION INSTRUCTIONS 476. Video distributor-amplifier. Terminals Technical data Power supply 21 ± 3Vdc It allows for the distribution of the video signal General ground Operating current at max. load 250mA coming from the cameras on 5 independent 14 Positive power supply Gain at max.
Page 28: Working Instructions
WORKING INSTRUCTIONS Check that the connections of the system are In case more calls occur simultaneously, a In these systems the control switch ON from carried out correctly. protection circuit against overloading and the monitors can interrupt a running commu- Put the system in use by connecting the short circuiting is provided to disable the nication, for this reason it is advisable to...
Page 29: Troubleshooting
TROUBLESHOOTING The probability of breakdown in the video- Preliminary checks intercom systems is obviously greater than in - Check for the presence of the mains voltage - Check the voltage output of the power supply (see in detail the values indicated in the intercom system.
Page 30 (GB- '99)
Page 31: Installation Diagrams
INSTALLATION DIAGRAMS The following pages show the installation diagrams most often used in the video-intercom system. Upon request Farfisa supplies installation diagrams for the configurations not present in this manual. Multi-way systems with 1, 2 and 3 entrances Combination intercom video-intercom systems...
Page 32: Mody Videokit
PV2160+WB2160 MD40+MD72+MD11+MD30 1281 1382 1443 As a service ACI Farfisa supplies one-way The “base” installation diagram of video kits For one-way systems with several monitors systems in Video Kits, which include all the is in this same page. and/or parallel intercoms, with or without in-...
Page 33 Electric door speaker ... According to the number of users. * The protective shelters are to be used instead of back boxes and decorative shields. ** Articles not provided by ACI Farfisa. Working instructions See page 28. Note Application of MD100 and MD200 modules in one and multiway systems...
Page 34 One and multi-way systems Si 5050 VIDEO-INTERCOM SYSTEM WITH AUDIO-VIDEO PRIVACY 75 Ω VC n 75Ω VC 1 75Ω The 75Ω resistance inserted between terminals 1 and 3 of monitors is supplied with the product. It is not to be added.
Page 35 Notes for systems of Project series: Notes for systems of PV260, PV260W ** Articles not provided by ACI Farfisa. intercoms: - to cut the jumper W1 that links the - remove the jumper that links termi- Working instructions terminals 3 and 7.
Page 36 Multi-way systems Si 5051 MULTI-WAY COMBINED INTERCOM VIDEO-INTERCOM SYSTEM WITH AUDIO-VIDEO PRIVACY 75 Ω VC n 75Ω VC 1 75Ω The 75Ω resistance inserted between termi- nals 1 and 3 of monitors is supplied with the prod- CT + SC uct.
Page 37 ... According to the number of users. * The protective shelters are to be used instead of back boxes and decorative shields. ** Articles not provided by ACI Farfisa. Note Working instructions - The A and F terminals of article 1382 can be...
Page 38 One and multi-way systems Si 5150 VIDEO-INTERCOM SYSTEM WITH TWO AUTOMATICALLY SWITCHED ENTRANCES, ONE OF WHICH IS ONLY AUDIO 75 Ω VC n 75Ω The 75Ω resistance inserted be- tween terminals 1 and 3 of monitors is supplied with the product. It is not to be added.
Page 39 ... According to the number of users. * The protective shelters are to be used instead of back boxes and decorative shields. ** Articles not provided by ACI Farfisa. Note Working instructions - The A and F terminals of article 1382 can be It is similar to the basic system connected to a maximum of 6 lamps (24V-3W).
Page 40 One and multi-way systems Si 5250 VIDEO-INTERCOM SYSTEM WITH TWO AUTOMATICALLY SWITCHED VIDEO ENTRANCES 75 Ω VC n 75Ω The 75Ω resistance inserted between terminals 1 and 3 of monitors is supplied with the product. It is not to be added. Graphic overlap point for extension of diagram (see page 48).
Page 41 ... According to the number of users. * The protective shelters are to be used in- stead of back boxes and decorative shields. ** Articles not provided by ACI Farfisa. Note - The A and F terminals of article 1382 can be For one-way systems or video connected to a maximum of 6 lamps (24V-3W).
Page 42 One and multi-way systems Si 5256 VIDEO INTERCOM SYSTEM WITH TWO AUTOMATICALLY SWITCHED ENTRANCES, ONE WITH AN OUTDOOR OR INDOOR SURVEILLANCE CAMERA 75 Ω VC n 75Ω The 75Ω resistance inserted between terminals 1 and 3 of monitors is supplied with the product.
Page 43 ... According to the number of users. * The protective shelters are to be used instead of back boxes and decorative shields. ** Articles not provided by ACI Farfisa. Note - The A and F terminals of article 1382 can be connected to a maximum of 5 lamps (24V-3W).
Page 44 One and multi-way systems Si 5350 VIDEO-INTERCOM SYSTEM WITH THREE AUTOMATICALLY SWITCHED VIDEO ENTRANCES 75 Ω VC n 75Ω The 75Ω resistance inserted be- tween terminals 1 and 3 of monitors is supplied with the product. It is not to be added. Graphic overlap point for extension of diagram (see page 48).
Page 45 X According to the number of auxiliary entrances. * The protective shelters are to be used instead of back boxes and decorative shields. ** Articles not provided by ACI Farfisa. Working instructions It is similar to the basic system described on page 28, but with the...
Page 46 Multi-way systems Si 5550 MULTI-WAY VIDEO-INTERCOM SYSTEM WITH AUXILIARY AUDIO ENTRANCES AND ONE MAIN VIDEO ENTRANCE ACCORDING TO THE STAIRWAY " A " 75 Ω " A " 75 Ω VC n VC n 75Ω 75Ω Nn (a) Nn (a) 75Ω...
Page 47 X According to the number of auxiliary entrances. * The protective shelters are to be used instead of back boxes and decorative shields. ** Articles not provided by ACI Farfisa. Working instructions It is similar to the basic system described on page 28, but with the...
Page 48 Multi-way systems Si 5551 MULTI-WAY VIDEO-INTERCOM SYSTEM WITH AUXILIARY VIDEO ENTRANCES AND ONE MAIN VIDEO ENTRANCE ACCORDING TO THE STAIRWAY " A " " A " 75 Ω 75 Ω VC n VC n 75Ω 75Ω Nn (a) Nn (a) 75Ω...
Page 49: Installation Diagrams
Working diagrams EXTENSION OF VIDEO INTERCOM SYSTEM All installation diagrams in this technical manual we have used only Extension of a ONE-WAY system one monitor for each user. It is possible to “personalise” the installa- To plan a one-way system with several monitors and/or parallel tion, by matching properly to the “base”...
Page 50 Working diagrams EXTENSION OF VIDEO INTERCOM SYSTEM Extension of a MULTI-WAY installation in several apartments Extension in a one apartment of a MULTI-WAY system To plan a multi-way system with several monitors and/or parallel To plan a multi-way system, with several monitors and/or parallel intercoms in a one apartment, with or without intercommunicating intercoms, in 2 or more apartments, with or without intercommuni- service, proceed as follows:...
Page 51 Working diagrams ADDITIONAL DIAGRAM FOR 2 PARALLEL MONITORS VC =PT5160 + WB5100 PT5660 + WB5600 + 1283 PT5860 + WB5600 PV2160 + WB2100 PV1260 + WB1200 + 1283 75Ω or, if intercommunicating VC =PT5160 + WB5160 PT5660 + WB5660 + 1283 PT5860 + WB5660 PV2160 + WB2160 PV1260 + WB1260 + 1283...
Page 52 Working diagrams ADDITIONAL DIAGRAM FOR 4 PARALLEL MONITORS 1471 1 3 5 6 75Ω P1-T1 P1-T1 P1-T1 P1-T1 P2-T2 P2-T2 P2-T2 P3-T3 P2-T2 P3-T3 P3-T3 P3-T3 P4-T4 P4-T4 P4-T4 P4-T4 P1-T1 Terminal I (art.1382) 1281 1281 symbol for terminal monitor PV2160 VC = PT5160 + WB5100 symbol for terminal...
Page 53 Working diagrams ADDITIONAL DIAGRAM FOR 1 MONITOR AND 1 INTERCOM 75Ω CT = PT510 PV100 Terminal A SR40 (art.1382) or, if intercommunicating P1-T1 PT520 + SR40 + PT501 PV260 + SR40 + SP10 symbol for terminal P1-T1 monitor PT5160, symbol for terminal PT5660, PT5860, VC = monitor PV2160...
Page 54 Working diagrams ADDITIONAL DIAGRAM FOR 1 MONITOR AND 3 PARALLEL INTERCOMS 1471 1 3 5 6 75Ω SR40 P1-T1 P2-T2 P3-T3 Terminal A VC = CT =PT510; PV100; 924 (art.1382) PT5160 + WB5100 or, if intercommunicating P1-T1 symbol for terminal PT5660 + WB5600 + 1283 PT520 + SR40 + PT501 monitor PT5160,...
Page 55 Working diagrams ADDITIONAL DIAGRAM FOR MULTI-WAY SYSTEMS WITH 3 INTERCOMMUNICATING PARALLEL MONITORS (Diode 100V-1A / type 1N4002) VC =PT5160 + WB5100 PT5660 + WB5600 + 1283 PT5860 + WB5600 PV2160 + WB2100 75Ω PV1260 + WB1200 + 1283 or, if intercommunicating VC =PT5160 + WB5160 PT5660 + WB5660 + 1283 PT5860 + WB5660...
Page 56 4+1 VIDEO-INTERCOM SYSTEM CAMERA The products of this line allow for the realiza- tion of a system with 4 common wires for all monitors, and one for each user, without using the coaxial cable. It is possible to receive a call from any moni- tor, from the external station, it is possible to see, communicate with the caller and release the electric door lock.
Page 57 4+1 VIDEO-INTERCOM SYSTEM 1 row push-button MODY series Composition board of Mody push-button panels. N° Compositions and Camera Module with 2 diode Button and info or Back box and Hood Rain calls dimensions module speaker module blank modules module frame covers shelter 1 MD40D...
Page 58 4+1 VIDEO-INTERCOM SYSTEM Monitors series Project Measures for the installation of the PT5111. Two-colour flat monitor with two Technical data wall bracket WB5111 to the wall, and Power Supply 18÷24Vdc buttons, one for control switch ON and one for recommended height from the floor. Operating current 0.35A door lock release, audio-video privacy, elec-...
Page 59 4+1 VIDEO-INTERCOM SYSTEM Monitors series PuntoVirgola Measures for the installation of the PV 2111. Two-colour flat monitor with two wall bracket WB2111 to the wall, and recommended height from the floor. buttons, one for control switch ON and one for door lock release, audio-video privacy, elec- tronic microphone, electronic modulated call note, terminal board for the connection to the...
Page 60: Power Supply
4+1 VIDEO-INTERCOM SYSTEM Power supply Technical data Note Input voltage 127 o 230Vac - The power supply is not provided with fuses, Frequency 50/60Hz but all of its outputs are protected against Power 48VA overloading and short circuiting by tempera- Switch-ON time: 100 sec.
Page 61 4+1 VIDEO-INTERCOM SYSTEM Working instructions Check that the connections of the system are timer and therefore to shut off the system. interrupt, by means of a relay art.1471, all the carried out correctly. In the absence of calls from the door station, control switches ON when the video system is Put the system in use by connecting the from any monitor (if provided in the system) it...
Page 62 4+1 VIDEO-INTERCOM SYSTEM Si 5801 MULTI-WAY COMBINED INTERCOM AND VIDEO INTERCOM SYSTEM 150Ω F H Y X DV2D DV4D F H Y X PT511 PV111 924D PT511 + SM50 Intercom without private conversa- Intercom with private conversation. tion. F H Y X DV2D DV4D F H Y X...
Page 63 4+1 VIDEO-INTERCOM SYSTEM Si 5850 MULTI-WAY VIDEO-INTERCOM SYSTEM WITH 2 AUTOMATICALLY SWITCHED VIDEO ENTRANCES, ONE OF WHICH IS ONLY AUDIO. 150Ω F H Y X DV2D DV4D F H Y X VC = PT5111 + WB5111 PV2111 + WB2111 PV1211 + WB1211 + 1283 F H Y X DV2D DV4D...
Page 64 4+1 VIDEO-INTERCOM SYSTEM Si 5851 MULTI-WAY VIDEO-INTERCOM SYSTEM WITH 2 AUTOMATICALLY SWITCHED VIDEO ENTRANCES. 150Ω F H Y X DV2D DV4D F H Y X VC = PT5111 + WB5111 PV2111 + WB2111 PV1211 + WB1211 + 1283 F H Y X DV2D DV4D F H Y X...
