Page 1: Instruction Manual
5625 -657/01 -657/02 Instruction Manual This instruction manual applies to machines from the following serial numbers onwards: # 2731762 296-12-18933/002 Betriebsanleitung engl. 01.06... - Page 2 This instruction manual applies to all versions and subclasses listed under "Specifications". Reprinting, copying or translation of PFAFF instruction manuals, whether in whole or in part, is not permitted without our prior permission and not without written indication of the source.
-
Page 3: Table Of Contents
Controls ........................7 - 1 Adjusting the stitch length .................... 7 - 1 Adjusting the top feed stroke on the PFAFF 5625-657/01 ..........7 - 1 Adjusting the top feed stroke on the PFAFF 5625-657/02 ..........7 - 2 Lifting the presser foot ....................7 - 2 Key for fixing the presser foot .................. -
Page 4: Contents
Clearance between the presser foot and the needle plate .......... 11 - 22 .04.22 Presser foot-to-needle plate clearance on the PFAFF 5625-657/02 ......11 - 23 .04.23 Needle thread tension release (only on the PFAFF 5625-657/01) ........ 11 - 24 .04.24 Needle thread regulator and take-up lever guard............11 - 25 .04.25 Looper thread regulator .................... -
Page 5: Safety
Safety Safety Regulations This machine is constructed in accordance with the European regulations indicated in the conformity and manufacturer's declarations. In addition to this instruction manual, please also observe all generally accepted, statutory and other legal requirements, including those of the user's country, and the applicable pol- lution control regulations! The valid regulations of the regional social insurance society for occupational accidents or other supervisory authorities are to be strictly adhered to! -
Page 6: Safety Symbols
The user must ensure that none of the safety devices are removed nor put out of work- ing order. The user must ensure that only authorized persons operate and work on the machine. For further information please refer to your PFAFF agency. 1 - 2... -
Page 7: Notes For Operating And Technical Staff
Safety Notes for operating and technical staff Operating staff .05.01 Operating staff are the persons responsible for setting up, operating and cleaning the mach- ine and for removing any disturbances in the sewing area. The operating staff are obliged to observe the following points, and must: always observe the notes on safety in this instruction manual! avoid using any working methods which adversely effect the safety of the machine! avoid wearing loose-fitting clothing or jewelry such as necklaces or rings! -
Page 8: Danger Warnings
Safety Danger warnings A working area of 1 m must be kept free both in front of and behind the mach- ine, so that easy access is possible at all times. Never put your hands in the sewing area during sewing! Danger of injury by the needle! While setting or adjusting the machine do not leave any objects on the table nor in the needle plate area! Objects may be trapped or slung out of the mach-ine! -
Page 9: Proper Use
Proper use Proper use The PFAFF 5625-657/01 is a single-needle, lockstitch special sewing machine with unison feed and pneumatically adjustable lift stroke. The PFAFF 5625-657/02 is a single-needle, lockstitch special sewing machine with unison feed and mechanically adjustable lift stroke. -
Page 10: Specifications
Specifications Specifications Stitch type: ....................401 (chainstitch) Version: ........................C N8,5 Needle size: ......................150 - 180 Needle system: ....................5640-59R Max. thread size: ......................11/3 (Synthetic or comparable sizes of other thread types) Effective balance wheel Ø: ..................80mm Presser foot clearance: .................... -
Page 11: Disposal Of The Machine
Disposal of Machine Disposal of Machine Proper disposal of the machine is the responsibility of the customer. The materials used for the machine are steel, aluminium, brass and various plastic mat- erials. The electrical equipment comprises plastic materials and copper. The machine is to be disposed of according to the locally valid pollution control regula- tions;... -
Page 12: Transport, Packaging And Storage
Transport, packaging and storage Transport, packaging and storage Transportation to customer's premises All machines are delivered completely packed. Transport within the customer’s premises The manufacturer bears no liability for transport within the customer’s premises or to the in- dividual locations of use. Always ensure that the machine is only transported upright. -
Page 13: Explanation Of The Symbols
Explanation of the symbols Explanation of the symbols In this Instruction Manual, tasks to be carried out and important information are drawn to your attention by symbols. The symbols have the following meanings: Note, information Cleaning, care Lubrication Servicing, repairing, adjustment, maintenance (only to be carried out by specialist personnel) 6 - 1... -
Page 14: Controls
After pressing key 1, the required stitch length can be set by turning adjustment wheel 2. Fig. 7 - 01 Adjusting the top feed stroke on the PFAFF 5625-657/01 The top feed stroke can be set by turning adjustment wheel 1. The maximum top feed stroke is limited by the manufacturer. -
Page 15: Adjusting The Top Feed Stroke On The Pfaff 5625-657/02
Controls Adjusting the top feed stroke on the PFAFF 5625-657/02 Maschine ausschalten! Verletzungsgefahr durch unbe- absichtigtes Anlaufen der Ma- schine! Open cover on the rear side of the machine, loosen nut 1 and adjust lever 2 accordingly Fig. 7 - 03... -
Page 16: Key For Fixing The Presser Foot
Controls Key for fixing the presser foot The presser foot can be fixed by raising it, then pressing key 1 and lowering the presser foot. To release it raise the presser foot. Fig. 7 - 05 Further control elements are described in the system service manual. 7 - 3... -
Page 17: Installation And Commissioning
Installation and commissioning Installation and commissioning The machine must only be installed and commissioned by qualified personnel! It is imperative that all relevant safety regulations are observed! Installation Suitable connections for electricity must be available at the machine’s location. Make sure that a level and firm surface as well as sufficient lighting are guaranteed at the machine’s location. -
Page 18: Setting Up
Setting up Setting up All regulations and instructions in this service manual must be observed. Special attention must be paid to all safety regulations! All setting up work is only to be carried out by appropriately trained personnel. For all setting up work the machines must be disconnected from the mains by operating the main switch or by pulling out the plug. -
Page 19: Threading The Machine / Adjusting The Thread Tension
Setting up Threading the machine / adjusting the thread tensions 62-023 - - - - - Fig. 9 - 02 Switch off the machine! Danger of injury if the machine is started accidentally! Thread the needle thread as shown in Fig. 9-02. Adjust the needle thread tension by turning milled screw 1. -
Page 20: Care And Maintenance
Care and Maintenance Care and Maintenance Clean the looper compartment .... daily, several times when in continuous operation Clean the entire machine ................once a week Check the gear oil level ................daily before use Check the oil level in the oil tank for the needle head parts..... daily before use The maintenance intervals apply to an average machine running time for a single shift. -
Page 21: Checking The Oil Level / Filling In Oil
If necessary remove screw 2 and fill in oil until an air bubble is visible. Tighten screw 2 again. Only use oil with a mean viscosity of 22.0 mm²/s at 40ºC and a density of 0.865 g/cm³ at 15ºC. We recommend PFAFF sewing machine oil, part number 280-1-120 144. 10 - 2... -
Page 22: Checking The Oil Level In The Oil Tank For The Needle Head Parts / Filling In Oil
Only use oil with a mean viscosity of 22.0 mm²/s at 40ºC and a density of 0.865 g/cm³ at 15ºC. We recommend PFAFF sewing machine oil, part number 280-1-120 144. During long stop periods close valve 3. 10 - 3... -
Page 23: Adjustment
Adjustment Adjustment The illustrations in this chapter show a PFAFF 5625-657/01 with sub-class -906/07 (pneumatic presser foot lift) as a work aid. Machines without this subclass, as well as the PFAFF 5625-657/02, differ slightly in some aspects from the illustrations shown. -
Page 24: Adjusting The Basic Machine
Adjustment Adjusting the basic machine Needle height (preliminary adjustment) .04.01 Requirement When the needle bar is positioned at t.d.c., there should be a distance of approx. 11 mm between the needle point and the needle plate. 11 mm 62-024 Fig. 11 - 01 Without twisting it, adjust the needle bar 1 (screw 2) in accordance with the requirement. -
Page 25: Driving Eccentric Of The Looper (Pre-Adjust)
Adjustment Driving eccentric of the looper .04.02 (Pre-adjust) Requirement When the needle bar is positioned at b.d.c., the round side of adjustment pin 1 (part no. 61-111 643-55) should lock into groove 5. Fig. 11 - 02 Insert adjustment pin 1 in hole 2. Turn eccentric 3 (screws 4) in accordance with the requirement. -
Page 26: Feed Lifting Eccentric
Adjustment Feed lifting eccentric .04.03 Requirement When the needle bar is positioned at b.d.c., slot 3 should be vertically above shaft 4. Fig. 11 - 03 Turn eccentric 1 (screws 2) in accordance with the requirement. 11 - 4... -
Page 27: Driving Eccentric Of The Spreader
Adjustment Driving eccentric of the spreader .04.04 Requirement 1. When the needle bar is positioned at b.d.c., slot 5 of eccentric 1 should be vertically above shaft 3. 2. Spreader holder 4 should move a distance of 6 mm. 62-026 62-027 Fig. -
Page 28: Feed Driving Eccentric And Drive To Needle Bar Frame
Adjustment Feed driving eccentric and drive to needle bar frame .04.05 Requirement When the needle bar is positioned at b.d.c. 1. Slot 7 of eccentric 1 should be vertically above shaft 5 and 2. Crank 3 should be positioned vertical to shaft 6. Fig. -
Page 29: Positioning The Feed Dog
Adjustment Positioning the feed dog .04.06 Requirement When the maximum stitch length is set, the feed dog 4 should move laterally and lengthwise in the centre of the needle plate cut-out. 62-068 Fig. 11 - 06 Align device 1 (screws 2 and 3) in accordance with the requirement. 11 - 7... -
Page 30: Feed Dog Height
Adjustment Feed dog height .04.07 Requirement When the needle bar is positioned at b.d.c. and with the maximum stitch length set, the front teeth of the feed dog 4 should be 1.1 mm above the needle plate. 62-029 Fig. 11 - 07 Loosen screw 1. -
Page 31: Position Of The Needle To The Needle Hole
Adjustment Position of the needle to the needle hole .04.08 Requirement 1. Crosswise to the sewing direction, the needle should penetrate in the centre of the needle hole. 2. When the needle bar is positioned at b.d.c., there should be a distance of 0.8 mm Between the needle and the front edge of the needle hole. -
Page 32: Position Of The Looper Crosswise To The Sewing Direction
Adjustment Position of the looper crosswise to the sewing direction .04.09 Requirement When its point is positioned in the centre of the needle, looper 1 1. Should be parallel to the needle plate cut-out and 2. There should be a distance of 0.1 mm between the looper point and the needle. 62-031 0,1 mm 62-069... -
Page 33: Position Of The Looper In The Direction Of Sewing/Re-Adjusting The Looper Eccentric
Adjustment Position of the looper in the direction of sewing/re-adjusting the looper eccentric .04.10 Requirement When the needle bar is positioned 6.0 mm after b.d.c. and the stitch length is set at 8.5 mm, the looper point should be centred to the needle. 62-031 Fig. -
Page 34: Readjusting The Needle Height
Adjustment Readjusting the needle height .04.11 Requirement When the stitch length is set at 8.5 mm and the looper point approaching from the rear is in alignment with the front side of the needle, the bottom edge of the looper should be 1.0 - 1.2 mm above the eye of the needle. -
Page 35: Position Of The Spreader In The Direction Of Sewing
Adjustment Position of the spreader in the direction of sewing .04.12 Requirement With the needle bar at b.d.c. and the maximum stitch length setting, the distance between the spreader point 3 and the needle should be 4 mm. 62-032 Fig. 11 - 12 Adjust holder 1 (screw 2) in accordance with the requirement. -
Page 36: Position Of The Spreader Crosswise To The Direction Of Sewing
Adjustment Position of the spreader crosswise to the direction of sewing .04.13 Requirement 1. The point of spreader 1 should have a side distance of 0.1 mm to the looper. 2. The point of spreader 1 should be 0.1 mm above the back of the looper. 0,1 mm 62-034 62-033... -
Page 37: Needle Guard And Thread Loop Support
Adjustment Needle guard and thread loop support .04.14 Requirement When the looper point approaching from the rear is positioned at the centre of the needle 1. Guard 1 should be touching the needle lightly and its lower edge should be positioned 0.5 mm above the needle tip. -
Page 38: Balancing Weight
Adjustment Balancing weight .04.15 Requirement When the needle bar is positioned at t.d.c., the greatest eccentricity of the balancing weight 1 should be at the bottom. Fig. 11 - 15 Adjust balancing weight 1 (screw 2) in accordance with the requirement. 11 - 16... -
Page 39: Feed Difference
Adjustment Feed difference .04.16 Requirement With the maximum stitch length set, when the balance wheel is turned, the needle and bottom feed dog should carry out the same feed strokes. + + + + + - - - - - Fig. -
Page 40: Top Feed Stroke On The Pfaff 5625-657/01
Adjustment Top feed stroke .04.17 on the PFAFF 5625-657/01 Requirement 1. When adjustment wheel 1 is set at position “5”, the top feed dog 10 and presser foot 11 should both rise 5.0 mm. 2. The standard stroke should be limited to 5 mm. -
Page 41: Top Feed Stroke On The Pfaff 5625-657/02
Adjustment Top feed stroke .04.18 on the PFAFF 5625-657/02 Requirement With the maximum feed stroke set, top feed dog 5 and presser foot 6 should each rise 5.00 mm. 62-014 62-015 Fig. 11 - 18 Remove the bottom feed dog and the needle. -
Page 42: Limiting The Top Feed Stroke
Adjustment Limiting the top feed stroke .04.19 Requirement 1. The maximum stroke of the top feed is set according to customer specifications (standard setting: 5 mm) 2. The minimum stroke should be at least 3 mm. Fig. 11 - 19 Adjust screw 1 in accordance with requirement 1. -
Page 43: Lifting Motion Of The Top Feed Dog
Adjustment Lifting motion of the top feed dog .04.20 Requirement When the stroke is set at 3 mm, the top feed dog 3 should just have reached the needle plate when the needle, when approaching from above, is at the height of the needle plate. 62-039 Fig. -
Page 44: Clearance Between The Presser Foot And The Needle Plate
Adjustment Clearance between the presser foot and the needle plate .04.21 Requirement When presser foot 1 is raised, there should be a clearance of approx. 11 mm between presser foot 1 and the needle plate. 11 mm 62-013 Fig. 11 - 21 Raise presser foot 1 with cylinder 2. -
Page 45: Presser Foot-To-Needle Plate Clearance On The Pfaff 5625-657/02
Adjustment Presser foot-to-needle plate clearance .04.22 on the PFAFF 5625-657/02 Requirement When presser foot 7 is raised 1. the hand lever 4 should be parallel to the needle thread tension unit 5, 2. the tip of crank 8 and bar 9 should be aligned and 3. -
Page 46: Needle Thread Tension Release (Only On The Pfaff 5625-657/01)
Adjustment Needle thread tension release .04.23 (only on the PFAFF 5625-657/01) Requirement When the presser foot is raised, tension disks 3 should be apart. Fig. 11 - 23 Raise the presser foot with the hand lever. Turn adjustment ring 1 (screws 2) in accordance with the requirement. -
Page 47: Needle Thread Regulator And Take-Up Lever Guard
Adjustment Needle thread regulator and take-up lever guard .04.24 Requirement 1. When the needle bar is at b.d.c., there should be a clearance of 1 mm between thread take-up lever 8 and take-up lever guard 1. 2. The thread take-up lever 8 should be centred to the take-up lever guard 1 as seen from the side. -
Page 48: Looper Thread Regulator
Adjustment Looper thread regulator .04.25 Requirement 1. When the maximum stitch length is set, thread puller 1, at the top of its stroke, should have a clearance of 28 mm to the top edge of the bedplate . 2. The eyes of thread puller 3 should be in alignment with the eyes of thread puller 1..Fig. -
Page 49: Limiting The Stitch Length
Adjustment Limiting the stitch length .04.26 Requirement For the required maximum stitch length, stop lug 1 should be touching stop 3. Fig. 11 - 26 Adjust stop lug 1 (screws 2) in accordance with the requirement. 11 - 27... - Page 50 PFAFF Industrie Maschinen AG Postfach 3020 D-67653 Kaiserslautern Königstr. 154 D-67655 Kaiserslautern Telefon: (0631) 200-0 Telefax: (0631) 17202 E-Mail: info@pfaff-industrial.com Gedruckt in der BRD Printed in Germany Imprimé en R.F.A. Impreso en la R.F.A.
