DataTalker Owner's Manual

1.7 Specifications

1.7.1

Async Data Channel

Number of Channels
Maximum Speed
Channel Speed
Data Format
Parity
Local Echo
Flow Control
Pacing
Interface
1.7.2

Sync Data Channel

Data Format
Channel Speed
Protocol
Error Correction
Interface
1.7.3

System Control (Command Port)

Local Access
Device
Menus
Diagnostics
1.7.4

Composite Link

Number of Links
Data Format
Link Speeds
Link Protocol
Error Correction
Interface
16
One
115,200 bps
All standard speeds from 300 bps to 115,200 bps
5, 6, 7, or 8 data bits, with 1, 1.5, or 2 stop bits
Odd, even, or none
On or off selectable
XON/XOFF, CTS, or HP ENQ/ACK selectable
On or off selectable, RTS on/off, or XON/XOFF
RS-232D/ITU-T V.24; DB-25 female connector
Synchronous
Up to 128K bps
SDLC/HDLC
16-bit CRC block check with ARQ
RS-232D/ITU-T V.24; DB-25 female connector
Through DataTalker's RS232C command port
Any asynchronous keyboard terminal or PC in terminal mode (local
access only)
Menus to configure data channel, voice/fax channel(s), and
composite link. Statistics menu and test menus are provided to
monitor performance and diagnose problems.
Data or voice loopback, memory, watch dog tests, and DIP switch
definitions and settings
One
Synchronous
Up to 256K bps
Proprietary modified HDLC
16-bit CRC block check with ARQ
RS-232D/V.24 or ITU-T V.35, or use DataTalker integral modem,
DSU, or ISDN terminal adapter
