- Page 1 DOMO MULTIAIR Assembly Instructions...
-
Page 2: Explanations To Symbols
Option for f irst convection fan Supplement for second convection fan Scope of Delivery E15632 Scope of Delivery E15633 B17528 Support plate including convection fan compl. B17527 Convection fan complete 3 x N112040 Duo Taptite L02724 Motor cover 4 x N106472 Duo Taptite LB00630 Air deflector complete Explanations to symbols ...Important note... -
Page 3: General Information
Dimensions Mounting Convection Fan Prepare the following at the stove: Loosen the 4 screws on the rear panel. The rear panel tilts backwards, then you can lift it off. Depending on the desired option cut off the two upper markers for one fan, for the second fan in addition the two bottom markers. - Page 4 Loosen the marked screw from the stove. This is used to secure the air Insert the wires from flame sensor and fan in the cable channel and put on the deflector below. lid. Then mount the support plate with 5 screws to the stove. To fix this and to avoid vibrations, twist the two tabs (located diagonally) with Thread the flame sensor through the oval hole in the support plate and fix it pliers.
- Page 5 Loosen the nut and the ring from the capacitor. Attach the condenser (with 2 blowers both capacitors) in the free slots behind the cable channel. In the cable channel are the three pin connector M3 for the upper convection fan 1 and the plug M4 for the lower convection fan 2. Insert the correct cable and put all cables and plugs back into the cable channel.
- Page 6 Technical and design changes, as well as typesetting and printing errors reserved © 2015 | RIKA Innovative Ofentechnik GmbH RIKA Innovative Ofentechnik GmbH 4563 Micheldorf / Austria, Müllerviertel 20 Telefon: +43 7582 686 - 41, Fax-DW: 43 E-Mail: verkauf@rika.at RIKA.AT...
