Envirovent IPX4 Installation Manual page 4

03 Wiring
Wiring the fan correctly...
1. The connection into the fan MUST be a
flexible cable and NOT solid core twin
and earth, if the fan is mishandled or a
solid core twin and earth cable is forced
into the terminals you WILL break it, this
will invalidate the warranty.
2. If it is necessary to use twin and earth
you must not take it into the fan. Use a
terminal block to make the connection
between the flexible cable supplied with
the fan and your solid core twin and earth
cable.
3. Place the cables inside the void in the
back of the back carcass next to the
cable gland and secure the fan to the
wall securely.
IMPORTANT: The black grommets and
sticky pad provided must be fitted in this
unit. Not using these items will jeopardise
both the IP rating and the warranty.
Electrical Assembly
When wiring the unit in, a suitable disconnect
device such as a fused spur should be
used, do not use a plug. The means of
disconnecting the unit from the mains power
supply must be incorporated in the fixed
wiring in accordance with the wiring rules.
There must be a necessity to allow
disconnection of the appliance from the
supply after installation, unless the appliance
incorporates a switch complying with the
03
wiring regulations The disconnection may
be achieved by incorporating a switch in the
fixed wiring in accordance with the wiring
regulations.
If the supply cord is damaged, it must be
replaced by the manufacturer, its service
agent or similarly qualified persons in
order to avoid a hazard.
SHOULD YOU ENCOUNTER ANY PROBLEMS INSTALLING THIS UNIT CALL
