Summary of Contents for Envirovent SELV
- Page 3 Not using these items will jeopardise both the IP rating and the warranty. Due to our policy of continuous innovation and improvement EnviroVent reserves the right to alter products specification and appearance without notice.
-
Page 4: How It Works
HOW IT WORKS The EnviroVent Filterless Extract Fan works in a constant trickle mode to create background ventilation to maintain a healthy environment. Vapour tracking... -
Page 5: Installation Instructions
DO NOT REMOVE OR TAMPER WITH ELECTRONIC DO NOT CONNECT TO MAINS. The fan must be CIRCUIT BOARD connected to the SELV (12V D.C) power supply/ • This is not a user function. spur unit enclosed. Please note that the unswitched fuse spur is used on the power supply unit. - Page 6 Back carcass Central carcass (not supplied). Use the back carcass as a template - mark SELV fixing holes - drill, plug and screw the back carcass into the wall with the screws provided. Fig.3 Fit the 3 blanking plugs into holes in top chamber.
-
Page 7: Maintenance
All repair, maintenance and component replacement is carried out simply and quickly by exchanging the plug out/plug in central cartridge. The worn out cartridge can then be returned to the EnviroVent factory to be recycled/reworked. This ‘when necessary’ cartridge exchange – with re-worked components will ensure that the basic fan installation will remain intact throughout the repair cycle of the dwelling, eliminating the wasteful disposal of plastic and other non biodegradable material to landfill sites. -
Page 8: Troubleshooting
In the event of an on-site installation problem or if you have any queries regarding the EnviroVent fan, just call us and ask to talk to a member of our technical team. In the majority of cases the issue can be resolved over the phone. -
Page 9: Technical Specifications
30.8 46.2 Airflow (l/s) OPTIONS & ANCILLARIES Description Code(s) Remote Pullcord EFHTCM-RC Remote Wall Switch EFHTCM-WS Wall Mounted Kit 1RD EFWAK Ceiling Mounted Kit 1AC EFCMBR Window Fixing Kit (230V) EFWIK230V Window Fixing Kit (SELV) EFWIK12V In-line Fixing Kit EFIL-WIK... - Page 10 WARRANTY CONDITIONS AND EXCLUSIONS The EnviroVent Filterless Extract Fan is covered by a full 5 year warranty which will benefit the occupier over many years. The unit will be set according to the size of the property and will operate continuously.
- Page 12 We want to hear from you Your feedback is important to us as we strive to improve our products, services, and overall customer experience. Please email us to help us serve you better: feedback@envirovent.com EnviroVent Ltd T 01423 810 810...
