I — INTRODUCTION
SCOPE OF MANUAL. This Quick Start Guide covers
the installation and operation of the Kepco RKW Series of
PFC (Power Factor Corrected), RoHS (Reduction of Haz-
ardous Substances) compliant, programmable switching
power supplies. Full specifications are listed in the applica-
ble Operator's Manual that can be downloaded from the
Kepco web site:
• 300W: www.kepcopower.com/support/
opmanls.htm#rkw300
• 600W: www.kepcopower.com/support/
opmanls.htm#rkw600
• 1500W: www.kepcopower.com/support/
opmanls.htm#rkw1500
DESCRIPTION. The Kepco RKW Programmable Series
switching power supplies come in 300W, 600W and 1500W
sizes (see Table 1). Each size has 3.3V, 5V, 12V, 15V, 24V,
28V and 48V models.
Units may be operated with a nominal 100V a-c to 240V a-
c (input voltage range 85 to 265 Va-c), 50-60 Hz (input fre-
quency range 47-66Hz). They will also operate on 110V to
370V d-c input. Overvoltage, overcurrent, overtemperature,
fan failure and power failure protections and an isolated
remote TTL ON-OFF control are provided for all models.
Series
Model
RKW
Output Current (Amperes d-c)
300W
Adjustment Range (Volts d-c)
Model
RKW
Output Current (Amperes d-c)
600W
Adjustment Range (Volts d-c)
Model
RKW
Output Current (Amperes d-c)
1500W
Adjustment Range (Volts d-c)
KEPCO, INC. 131-38 SANFORD AVENUE
©2010, KEPCO, INC
Data subject to change without notice
An ISO 9001 Company.
SINGLE OUTPUT
PROGAMMABLE POWER SUPPLIES
TABLE 1. RKW OUTPUT RATINGS
Rating 3.3V
3.3-70K
70A
1.8-3.6
3.3-150K
150A
1.8-3.6
3.3-375K
375A
1.8-3.6
FLUSHING, NY. 11355 U.S.A.
http://www.kepcopower.com
An LED "output voltage ON" light and an output voltage
adjust trimmer are provided.
II — INSTALLATION
MOUNTING THE POWER SUPPLY: Refer to Figure
1. The unit may be mounted on one mounting surface. Note
the restrictions for maximum penetration of mounting
screws (M4): 0.24 in (6 mm) from case. The air surrounding
the power supply must not exceed the ambient values
given in the graph in Figure 4.
CONNECTIONS: Figure 2 shows proper connection of
one or more loads using either remote or local sensing. If
local or remote sensing is not configured, the unit will
not work properly. The unit is shipped with local sense
cables in place for Local sensing. For remote sensing,
remove the local sense cables and connect the +S and –S
terminals to the load. Remote sensing compensation is up
to 0.4V per load wire (0.15V for 3.3V models, 0.25V for 5V
models). Transient recovery specs may not be met when
remote sensing is used. If oscillations set off overvoltage
protection, install one electrolytic capacitor (470µF min)
between +S and + and one between – and –S terminals.
The AC input power is applied via the terminal block. Make
sure to connect the AC input Neutral, Line and Ground
wires to the respective terminals of the terminal block (see
Figure 3). Sensing (either Local or Remote) MUST be
used.
5V 12V 15V
5-60K 12-27K 15-22K
60A 27A 22A
3.5-6.0 7.2-14.4 10.5-18.0
5-120K 12-53K 15-43K
120A 53A 43A
3.5-6.0 7.2-14.4 10.5-18.0
5-300K 12-125K 15-100K
300A 125A 100A
3.5-6.0 7.2-14.4 10.5-18.0
TEL (718) 461-7000
email: hq@kepcopower.com
228-1672 REV 2
RKW
Programmable
24V 28V
24-14K 28-12K 48-7K
14A 12A
16.8-28.8 19.6-33.6 33.6-52.8
24-27K 28-23K 48-13K
27A 23A
16.8-28.8 19.6-33.6 33.6-52.8
24-65K 28-55K 48-32K
65A 55A
16.8-28.8 19.6-33.6 33.6-52.8
FAX (718) 767-1102
48V
7A
13A
32A
