Section 6 ... Printer Control Codes and Resident Fonts

Character Hex/Dec
EOT
BS
HT
LF
VT
FF
CR
SO
SI
XON
AUXON
XOFF
NORM
AUXOFF
CANCEL
ESC
EXTEND
EXTEND OFF
Status All
Status buffer
Printer Command Strings
ESC+F+1 (default)
ESC+F+2
ESC+F+3
ESC – G
The graphic character set
ESC - 'A'
ESC – 'P' – alpa
ESC – 'M' - '000' - cr
ESC - 'M' - 'nn0' - cr
ESC – 'M' - 'C'
ESC – 'M' - 'nnm' - cr
^B
10
04/04 End Of Text
08/08 Back Space
09/09 Horizontal Tab
0A/10 Line Feed
0B/11 Vertical Tab
0C/12 Form Feed
0D/13 Carriage Return
0E/14 Shift Out – Select double wide print
0F/15 Shift In – Clear double wide print
11/17 Transmitter On.
12/18 Printer on.
13/19 Printer receiver is off
14/20 Return to default 42 column mode
15/21 Printer to Host: printer is off
18/24 Cancel and reset printer buffer. Default to Standard font.
1B/27 Escape
1C/28 Extended print
1D/29 Extended print off/Normal print
Report Buffer, power timer and battery status
Report number of characters received in buffer
Printer Function
Standard ASCII and International character set
Hebrew ASCII and Hebrew character set
IBM PC ASCII and IB M PC character set
Select 6-bit graphic print mode
From character '?'(3FH) to TILDA (7EH), CR & LF
Select Text Print Mode. Cancel Graphic mode.
Time and date print and Format control
Disable the power down timer
sets the power down timer to nn seconds
Reset Auto power down to 20 seconds
Select optional Magnetic Card reader
Request printer Status Report:
Print buffer:
Battery Voltage:
Magnetic card reader:<ESC> <M><4 ASCII digits><CR><LF>
CONTROL ACTION
Report Format
<ESC> <B><4 ASCII digits><CR><LF>
<ESC> <V><4 ASCII digits><CR><LF>
