PARTS LIST

ITEM № PART № DESCRIPTION
1 WC-61565 PANEL, L-SHAPED
2 WC-61562 COVER, FRONT
3 WC-37176 KIT, UCM & LABEL INSTRUCTIONS
3A WC- 728 CONTROL MODULE, 220V TP2S/TP2T
4 WC-39593 LABEL, UCM OVERLAY 3-BATCH SINGLE
4A WC-39592 LABEL, UCM OVERLAY 2-BATCH SINGLE
4B WC-39591 LABEL, UCM OVERLAY 1-BATCH SINGLE
5 WC-3417 BREWCONE ASSY, W/SPLASH POCKET BRN
6 WC-1853 FAUCET, ASSEMBLY TPC
7 WC-1805 SEAT CUP, FAUCET
8 WC-61287 PANEL, INTERSECTION RIGHT
9 WC-61561 COVER, TOP
10 WC-37122* KIT, DUMP VALVE RIGHT 120V 14W
10A WC- 854 VALVE, BREW DUMP RIGHT 240V 12W TP/TPC
11 WC-2977-101 FITTING, SPRAYHEAD
12 WC- 844-101* VALVE, BY-PASS W/RESISTOR
12A WC- 844-102 VALVE, BY-PASS, 220V NON-ADJUSTABLE RSTR
13 WC- 442* SOLENOID, LOCK BREWCONE RIGHT
13A WC- 446 SOLENOID, LOCK BREW CONE RIGHT 220V
14 WC-5851 COVER, TANK 2/NOTCHES
15 WC-5310* TUBE, 5/16" I.D. X 1/8" SILICONE
16 WC-43062* GASKET, TANK LID
17 WC-5502-01* KIT, PROBE, ASSY WATER LEVEL W/HEX FITTING, O-RING & NUT
18 WC-62032 TANK, COMPLETE TP2S ULTEM FITTINGS
19 WC-5350 TUBE, ½" ID x 1/8W SILICONE
20 WC-4394* GUARD, SHOCK HEATING ELEMENT, 2 REQ'D
21 WC- 906-04* ELEMENT, HEATING 2KW 220V W/JAM NUT
22 WC- 522* THERMOSTAT, RESET
23 WC-43055* GUARD, SHOCK RESET THERMOSTAT
24 WC-2402P* ELBOW, 3/8"FL x 3/8" NPT PLATED
25 WC- 847* VALVE, WATER INLET 2GPM 120V 10W
25A WC- 883 VALVE, INLET 2 GPM 240V 10W
26 WC-61285 PANEL, L-SHAPE RIGHT
27 WC-29050* SPRAYHEAD, AMBER ADVANCED FLOW
28 WC-8591* CAPACITOR X2
29 WC- 103* SWITCH, TOGGLE NON-LIT DPST 25A 125/250VAC
30 WC-1501 FUSE HOLDER ASSY W/5A FUSE
31 WC-8559 RELAY, SOLID STATE W/INTEGRATED HTSNK
32 WC-3528 LEG, 4" ADJUSTABLE
33 WC-61290 COVER, CENTER WRAP
34 GEM-6* FILTER, 500PK 12½" X 4"
35 WC-5231* COMPOUND, SILICONE
36 WC-1438-101* SENSOR, HEATING TANK
37 WC-37132 KIT, VALVE REPAIR
38 WC-3765L* KIT, VALVE REPAIR WATER INLET
* RECOMMENDED PARTS TO STOCK.
