3 . 3 . 3 O p e n P o r t
3 . 3 . 3 O p e n P o r t
Open Ports allows you to open a range of ports for the traffic of special applications.
Common application of Open Ports includes P2P application (e.g., BT, KaZaA, Gnutella,
WinMX, eMule and others), Internet Camera etc. Ensure that you keep the application
involved up-to-date to avoid falling victim to any security exploits.
Click Open Ports to open the following page:
Index
Comment
Local IP Address
Enter the private IP address of the DMZ host, or click Choose PC to
select one.
Click this button and then a window will automatically pop up, as
depicted below. The window consists of a list of private IP addresses
of all hosts in your LAN network. Select one private IP address in
the list to be the DMZ host.
After you have selected one private IP from the above dialog, click
OK to save the setting.
s
s
Indicate the relative number for the particular entry that you want to
offer service in a local host. You should click the appropriate index
number to edit or clear the corresponding entry.
Specify the name for the defined network service.
Display the private IP address of the local host offering the service.
34 Vigor2110 Series User's Guide
