4 . 1 3 . 6 A P D i s c o
4 . 1 3 . 6 A P D i s c o
Vigor router can scan all regulatory channels and find working APs in the neighborhood.
Based on the scanning result, users will know which channel is clean for usage. Also, it can be
used to facilitate finding an AP for a WDS link. Notice that during the scanning process (about
5 seconds), no client is allowed to connect to Vigor.
This page is used to scan the existence of the APs on the wireless LAN. Yet, only the AP
which is in the same channel of this router can be found. Please click Scan to discover all the
connected APs.
first type of application. Repeater mode is for the second one.
There are three types for security, Disable, WEP and
Pre-shared key. The setting you choose here will make the
following WEP or Pre-shared key field valid or not. Choose one
of the types for the router.
Check this box to use the same key set in Security Settings
page. If you did not set any key in Security Settings page, this
check box will be dimmed.
Type 8 ~ 63 ASCII characters or 64 hexadecimal digits leading
by "0x".
If you choose Bridge as the connecting mode, please type in the
peer MAC address in these fields. Four peer MAC addresses are
allowed to be entered in this page at one time. Yet please
disable the unused link to get better performance. If you want to
invoke the peer MAC address, remember to check Enable box
in the front of the MAC address after typing.
If you choose Repeater as the connecting mode, please type in
the peer MAC address in these fields. Four peer MAC addresses
are allowed to be entered in this page at one time. Similarly, if
you want to invoke the peer MAC address, remember to check
Enable box in the front of the MAC address after typing.
Click Enable to make this router serving as an access point;
click Disable to cancel this function.
It allows user to send "hello" message to peers. Yet, it is valid
only when the peer also supports this function.
v e r y
v e r y
180 Vigor2110 Series User's Guide
