SO313BL
SO313IX
OPERATING AND INSTALLATION
INSTRUCTIONS OF
BUILT-IN OVEN

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SO313BL and is the answer not in the manual?

Questions and answers

Summary of Contents for Nordmende SO313BL

  • Page 1 SO313BL SO313IX OPERATING AND INSTALLATION INSTRUCTIONS OF BUILT-IN OVEN...
  • Page 2 Dear Customer, We take offering quality products that more than meet your expectations as our goal, offering you products produced in modern factories that have been carefully and extensively tested for quality. Your manual is prepared in order to help you to use your appliance that is manufactured by the most recent technology, with confidence and maximum efficiency.
  • Page 3 Contents 1- Presentation and size of product 2- Warnings 3- Preparation for installation and use 4- Using the oven 5- Cleaning and maintenance of your product 6- Service and Transport...
  • Page 4 PART 1: PRESENTATION AND SIZE OF PRODUCT LIST OF COMPONENTS : 1- Control panel 8- Wire Grill 2- Handle 9- Racks 3- Oven Door 10- Oven Light 4- Child Lock 11- Turbo Heating Element(behind the plate) 5- Tray 12- Fan (behind the plate) 6- Lower Heating Element (behind the plate) 13- Air Outlet Shutters 7- Upper Heating Element (behind the plate)
  • Page 5 PART 2 SAFETY WARNINGS READ THESE INSTRUCTIONS CAREFULLY AND COMPLETELY BEFORE USING YOUR APPLIANCE, AND KEEP IT IN A CONVENIENT PLACE FOR REFERENCE WHEN NECESSARY. THIS MANUAL IS PREPARED FOR MORE THAN ONE MODEL IN COMMON. YOUR APPLIANCE MAY NOT HAVE SOME OF THE FEATURES THAT ARE EXPLAINED IN THIS MANUAL. PAY ATTENTION TO THE EXPRESSIONS THAT HAVE FIGURES, WHILE YOU ARE READING THE OPERATING MANUAL.
  • Page 6 - During use, the appliance becomes hot. Care should be taken to avoid touching heating elements inside the oven. - During use, handles held for short periods in normal use can get hot. - Do not use harsh abrasive cleaners or sharp metal scrapers to clean the oven door glass and other surface since they can scratch the surface, which may result in shattering of the glass or...
  • Page 7 - Ensure that the supply cord is not wedged during the installation. If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons in order to prevent a hazard. - While the oven door is open, do not let children climb on the door or sit on it. Installation Warnings - Do not operate the appliance before it is fully installed.
  • Page 8 PART 3: PREPARATION FOR INSTALLATION AND USE Manufactured with best quality parts and materials, this modern, functional and practical oven will meet your needs in all respects. Make sure to read the manual to obtain successful results and not to experience any problems in the future. The information given below contain rules that are necessary for correct positioning and service operations.
  • Page 9 3.2. INSTALLATION OF BUILT_IN OVEN Cabinet cut-out sizes Min 25mm You can use either cabinet 1 or cabinet 2 cut-out sizes A DETAIL Minimum 40mm(The wooden part can be extended up to cut-out depth) Wooden part Front frame B DETAIL Countertop Built-in hob Distance between...
  • Page 10 The dimensions and material of the cabinet in which the oven will be installed must be correct and resistant to increases in temperature. In a correct installation, contact with electrical or insulated parts must be prevented. Insulating parts need to be fitted in a way to ensure that they cannot be removed by using any kind of tool.
  • Page 11 PART 4: USING THE OVEN 4.1 CONTROL PANELS Built_in Oven Oven Function Oven Thermostat Knob Control Knob Digital Timer 50° 100° 250° 150° 200° Oven Operation Light Oven Thermostat Light Oven Function Control Knob: To select the desired cooking function, turn the knob to the related symbol(Figure 11).
  • Page 12 4. USE OF YOUR PRODUCT 4.2. USING THE OVEN FUNCTION CONTROL BUTTON * The functions of your oven may be different due to the model of your product. Oven Lamp Only the oven light will be turned on and it remains on in all the cooking functions. Static Cooking Function The oven 's thermostat and warning...
  • Page 13 4. USE OF YOUR PRODUCT Grilling Function The oven 's thermostat and warning lights will be turned on, the grill heating element will start operating. The function is used for grilling and toasting foods, use the upper shelves of oven. Lightly brush the wire grid with oil to stop foods sticking and place foods in the centre of the grid.
  • Page 14 ENERGY SAVING During use of electrical cookers , it is required to use saucepans having flat bases. Choose a cookware of proper size. Using a lid will reduce cooking times. Minimize the amount of liquid or fat to reduce cooking times. When liquid starts boiling ,reduce the temperature setting.
  • Page 15 4. USE OF YOUR PRODUCT 4.3. USING TIMER Use of digital timer Time Adjustment: The time must be adjusted before starting to use the oven. Following the power supply to the oven, the symbol (A) and the three “0” on the screen will begin to flash. Press the (+) and (-) keys simultaneously.
  • Page 16 4. USE OF YOUR PRODUCT Audible Warning Time Adjustment: The time must be adjusted before starting to use the oven. Following the power supply to the oven, the symbol (A) and the three “0” on the screen will begin to flash. Press the (+) and (-) keys simultaneously.
  • Page 17 4. USE OF YOUR PRODUCT using the (+) and (-) buttons while the timer is in his position. Some time after the adjustment operation is completed, the day’s time wil appear on the screen and the symbols (A) and will begin to continuously light on the screen. While doing this, the oven will also start to operate.
  • Page 18 4. USE OF YOUR PRODUCT Full- Automatic Programming: This function is used to cook after a certain period of time, within a certain duration. The food to be cooked is put into the oven. The oven is adjusted to the desired cooking function.
  • Page 20 4.8. ACCESSORIES USED IN THE OVEN It is recommended that you use the containers indicated on the table depending on the food you will cook in your oven, you can also use glass containers, cake cutters, special oven trays suitable for use in your oven, available in the market. Pay attention to the information given by the manufacturer firm concerning this issue.
  • Page 21 Installation of the Shelves 5. Rack 4. Rack 3. Rack 2. Rack 1. Rack WARNING- Fit the grid correctly into any correspondent rack in the oven cavity and push it to the end.
  • Page 22 PART 5: CLEANING AND MAINTENANCE OF YOUR OVEN 5.1. CLEANING Before starting to clean your oven, be sure that all control buttons are off and your appliance is cooled off. Unplug the appliance. Do not use cleaning materials containing particles that might scratch the enamelled and painted parts of your oven.
  • Page 23 Scrubbing with steel cleaning wires may harm the vitroceramic glass surface. Formation of dust on the surface should be cleaned up using a dampened cloth. Changes in colour which might occur on the ceramic glass surface do not affect the functional structure or permanence of the vitroceramic.
  • Page 24 PART 6: SERVICE AND TRANSPORT 6.1. REQUIREMENTS BEFORE CONTAINING TO SERVICE If the oven does not operate : The oven may be plugged off, there has been a black out. On models fitted with a timer, time may not be regulated. If the oven does not heat : The heat may be not adjusted with oven’s heater control switch.
  • Page 25 Trademark SO313BL Model Standard Energy Consumption at Energy Efficiency Class Load E (kWh) E < 0.80 A(High Efficiency) 0.80 < E < 1.00 1.00 < E < 1.20 1.20 < E <1.40 1.40 < E < 1.60 1.60 < E <1.80 G(Low Efficiency) 1.80 <...
  • Page 26 The symbol on the product or on its packaging indicates that this product may not be treated as household waste. Instead it shall be handed over to the applicable collection point for the recycling of electrical and electronic equipment. By ensuring this product is disposed of correctly, you will help prevent potential negative consequences for the environment and human health, which could otherwise be caused by inappropriate waste handling of this...
