Westinghouse WBR 055 Manual

Westinghouse WBR 055 Manual

Installation start-up maintenance parts gas fired boiler residential and commercial models
Hide thumbs Also See for WBR 055:
Table of Contents

Advertisement

Quick Links

Download this manual
Installation
Start-Up
Maintenance
Parts
Warranty
WBR Models*
055 / 080 / 110
155 / 199 / 285
WBC Model*
399
* Models with:
"N" Denote Natural Gas Operation
"LP" Denote Propane Gas Operation
"PU" Denote Included Pump
This manual must only be used by a qualified installer / service technician. Read all instructions in this manual before
installing. Perform steps in the given order. Failure to do so could result in substantial property damage, severe
personal injury, or death.
Improper installation, adjustment, alteration, service, or maintenance could void product warranty and cause
property damage, severe personal injury, or death.
Westinghouse reserves the right to make product changes or updates without notice and will not be held liable for
typographical errors in literature.
NOTE TO CONSUMER: PLEASE KEEP ALL INSTRUCTIONS FOR FUTURE REFERENCE.
Gas Fired Boiler
Residential and
Commercial Models
Heat Exchanger Bears the ASME "H" Stamp
WHL-016 Rev. 4.14.16
