  • Page 1 Instruction manual...

  • Page 3: Table Of Contents

    Contents Contents Page Title ■ Front page ■ Contents Page ■ Receiver installation Title 21-24 ■ For safe operation  ▶Throttle menu    Throttle trim ■ Name of parts    Throttle high point  Adjustment of steering tension  D.S.C. jack    Throttle brake    Throttle sub trim  Multi Access Port    Throttle trim rate  Headphone jack...

  • Page 4: Receiver Installation

    Receiver installation Receiver installation ● For electric cars ● For electric cars ●Motor ●Running battery ●Transmitter (EX-10 eurus) ●Servo ●ESC (Electric Speed Controller) ●Receiver (KR-409S) (CH1: steering servo, CH2: ESC) ● For gas cars ● For gas cars ●Receiver battery ●Module (RF-902S)

  • Page 5: For Safe Operation

    For safe operation For safe operation Read carefully and fully understand the following instructions for safety use. With the nature of radio controlled model, improper usage may result in serious accidents. In order to avoid these circumstances, please read following contents before use. We cannot be held responsible for problems encountered when not complying with these cautions and notices.
  • Page 6 ●Do not allow fuel or exhaust to touch plastic parts. Warning! It may attack plastic. Prohibited matters ●Make sure that model memory is matched to the model currently running. Warning! Otherwise, it may cause car to run out of control. Enforcement matters ●Make sure to stop engine (disconnect motor cables) before making function change.

  • Page 7: Name Of Parts

    Name of parts Name of parts Transmitter (front) LM2 LED indicator 2 LM3 LED indicator 3 LM1 LED indicator 1 ET1 lever Hook Minus key Plus key Steering wheel Jog dial ET3 lever 12x4 LCD Enter key Power indicator Back key ET2 lever Power switch BT2 button...

  • Page 8: Jack

    Transmitter (rear) RF Module (refer to P11) Use only a module included in this set or one that is Charging jack (refer to P10) compatible with the set. Headphone jack (refer to P8) D.S.C. jack (refer to P8) Multi Access Port (refer to P8) D.S.C.

  • Page 9: Adjustment Of Steering Wheel And Throttle Trigger

    Adjustment of steering wheel and throttle trigger Steering wheel spacer Steering wheel (inside) Reduces movable range of steering wheel. Screw Hex wrench (2mm) Tech tip Steering wheel Detach steering sponge from steering wheel. Insert hex wrench (2mm) as shown. Tighten both right and left screws to adjust movable range.

  • Page 10: Unit Preparation

    Unit preparation Unit preparation Battery installation Slide battery box lid, pressing triangle on the lid. Transmitter (bottom) Battery box lid Install R6/AA/UM3 batteries ×8 in the battery box. Note contact points. Note polarity and use fresh batteries. Depleted batteries may deteriorate radio power and cause malfunction. Contact Caution! Do not use high voltage dry batteries (such as Lithium) because...

  • Page 11: Attachment And Replacement Of Module

    Attachment and replacement of module Attach module as shown. When detaching, press both side of tabs on the module and pull out module. For frequency change (2.4GHz, 27MHz, 40MHz), replace module. Caution! Turn off transmitter before module replacement. Caution! Attach retractable antenna (optional available) when using frequency 27MHz or 40MHz.
  • Page 12 ● Receiver installation on carbon chassis When fixing the receiver to the chassis or on the mechanism deck, use more than 2 layers of double-sided tape to avoid direct contact with chassis. Chassis and mechanism deck (especially carbon material) can also conduct noise. Making space between receiver with them is recommend to ensure protection against noise.

  • Page 13: Installation And Setting Of R/C Units

    Installation and setting of R/C units Install and connect receiver, servo and ESC (for electric car) to your R/C car. Be careful and note the anti-noise measures (refer to P11). Read instruction manual included in servo and ESC carefully. Install battery in transmitter and attach module (refer to P10-11). Then, install running battery for an electric car or install receiver battery for a gas car.

  • Page 14: Procedure When Running

    Power on: Note surroundings and switch transmitter on, then switch receiver on. EX-10 eurus automatically finds unused frequency band after switching on. This function is called "carrier sense". To perform carrier sense effectively, switch the transmitter on around the running area as close as possible.

  • Page 15: Setting

    Setting Setting Functions Model menu Throttle menu 21-24    Model select    Throttle trim    Model menu    Throttle high point    Model copy    Throttle brake    Model reset    Throttle sub trim    Data pack format    Throttle trim rate    Throttle speed    Throttle punch    Throttle curve    Throttle reverse Steering menu 18-20    Neutral brake...

  • Page 16: Start Menu

    ⓐ ⓑ BATT 12.5v ⓐ ：Current model memory’ s number ⓒ ⓑ ：Current model memory’ s name EX-10 EURUS ⓒ ：Voltage ※” LOW BATT” blinked when under 9.0V. ⓓ ⓓ ：Optional function (refer to P27). 【Model menu】 (P.17) 0000000 >SELECT >...

  • Page 17: Model Menu

    ▶Model menu Model control functions. The model indicates a program with proper settings for each condition. Start menu （P.16） 【Model select】 selects the model memory. >01 0000000 >SELECT > NAME ENTER ENTER > + ‒ Select with [    ] or [    ] COPY >...

  • Page 18: Steering Menu

    ▶Steering menu Steering control functions. Start menu （P.16） 【Steering trim】 sets neutral position （L50∼0∼R50） >TRIM TRAVEL BALANCE > + ‒ Set with [    ] or [    ] ENTER ENTER BACK BACK ST: - …… I …… + Complete with [   ] (return) ENTER ENTER + ‒...

  • Page 19: Steering Speed

    【Steering speed】 sets servo’ s working speed. ＞T.Pos ／ R.Pos：1∼100%  TRIMRATE 10 >T.Pos ENTER ENTER Turn1 ＞Turn ／ Retun：1 ∼100 （slow） （quick）   >SPEED > PUNCH Turn2 ST: - …… I …… + BACK BACK BACK BACK R.Pos This function allows for steering speed adjustment in first part Return1 (Turn1/Return1) and later part (Turn2/Return2) separately.

  • Page 20: Dual Rate

    【Dual rate】 changes steering travel and balance while running. ＞KEY ：OFF, ET1∼５, BT1, BT2 （allocates function key） CURVE >KEY ENTER ENTER REVERSE OFF BUTTON TGLE ＞BUTTON： TRAVEL >DualRate >  TGLE （switches [dual rate] by pressing function key） ST: - …… I …… + BACK BACK BACK...

  • Page 21: Throttle Menu

    ▶Throttle menu Throttle control functions. Start menu （P.16） 【Throttle trim】 sets throttle output in neutral position （B 50∼0∼F 50） （reverse） （forward） >TRIM HPOINT F100 ENTER ENTER BRAKE B100 + ‒ Set with [    ] or [    ] BACK BACK TH: - …… I …… + Complete with [   ] (return) ENTER ENTER...

  • Page 22: Throttle Speed

    【Throttle speed】 sets throttle response (forward). >Tr.L/Tr.M M/H, Rt.H/Rt.M M/L：1∼100%  → → TRIMRATE 10 >Tr.L → ENTER ENTER Tr.M >TurnL/M/H, ReturnH/M/L：1 ∼100 （slow） （fast） >SPEED > → PUNCH TurnL TH: - …… I …… + BACK BACK TurnM BACK BACK This function allows for throttle response adjustment (forward) TurnH in slow range (TurnL/ReturnL), mid range (TurnM/ReturnM) and...

  • Page 23: Neutral Brake

    【Neutral brake】 sets brake effect in neutral position. ＞KEY ：OFF, ET1∼５, BT1, BT2 （allocates function key） REVERSE OFF >KEY ENTER ENTER BUTTON PUSH ＞BUTTON： >NutBrake > AutoStart BRAKE >  TGLE （switches [Neutral brake] by pressing function key） TH: - …… I …… + BACK BACK BACK...

  • Page 24: Acceleration

    【Acceleration】 increases throttle by pumping while throttle trigger is in preset range.   > >WIDTH ENTER ENTER TRG.L F ＞WIDTH ：OFF ∼100% （sets pumping effect） >ACCEL > IDEL UP TRG.H F > ＞TRG.L F ：1∼100% （sets start range of trigger） BACK BACK TH: - ……...

  • Page 25: Optionmenu

    ▶Option menu Other optional setting functions. Start menu （P.16） 【CH3, CH4】 settings for 3 and 4 channel radio control. ＞TYPE： PUSH >CH3 > >TYPE ENTER ENTER SUBTRIM  PUSH , 2∼5WAY （※1） （switches POS by pressing） > RSP DD:NORM REVERSE OFF  STmix , THmix （for steering mixing ※2）...

  • Page 26: Input

    【Input】 【Setup】 allocates functions to function keys.     ＞E 1∼５, B 1∼2 （ET lever） （BT button） RSP DD:NORM >E1 S:TRIM >Setup > ENTER ENTER ENTER ENTER E2 T:TRIM AdjustVR >INPUT > > 《Set up》 DISPLAY AutoRep E3 T:BRAKE > BACK BACK S:TRIM OptionMenu...

  • Page 27: Display

    OPT:DISPLAY Steering monitor BATT 12.5v Throttle monitor ST: - …… I …… + CH3 monitor EX-10 EURUS CH4 monitor Response + ‒ Set with [    ] + ‒ To reset values press both [    ] for a second 【Intelligent recognition module】...

  • Page 28: Buzzer

    【Buzzer】 allocates beep sound to functions. （ T01∼20 , Mut , DEF ） （Custom tone） （ mute） （default） >Click Click ENTER ENTER S.Alarm Click 《Function》 >Buzzer > S.Alarm Stop watch alarm S.PAlm CustomTone > S.PAlm Stop watch pre-alarm BACK BACK OptionMenu S.Navi BACK...

  • Page 29: Stopwatch

    【Stop watch】 stop-watch and lap time record function. ＞KEY ：OFF, ET1∼５, BT1∼2 （allocates stop-watch function key） CustomTone > >KEY ENTER ENTER LAP.KEY OFF ＞LAP.KEY ：OFF, ET1∼５, BT1∼2 （allocates lap time function key） >StopWatch > Down Timer > TH.Start > ※１ ＞TH.Start （...

  • Page 30: Spec

    Spec Spec ■ Transmitter：KT-409H   Operating system：steering wheel & throttle trigger   Number of channels：4   Transmit frequency band：entire frequency band (using high frequency module)   Neutral pulse：1.5mSec   Power source：R6/AA/UM3 battery x 8, or 8 cell battery pack   Current consumption：approx. 80mAh (excl. high frequency band) ■...
