Bypassing Zone
The system must be disarm,
Press [*] [4] follow by [master code]
The

BYPASS LIGHT

will on
Enter the number of the zone to by passed.
Press [#] to save & exit programming menu.
(The Led at zone that is bypass will Always Flashing)
To Unbypass Zone
The system must be disarm,
Press [*] [4] follow by [master code]
The

BYPASS LED

will on
Enter the number of the zone to unbypass.
Press [#] to save & exit programming menu.
(The Led at zone that is unbypass will Stop Flashing)
To Set The System Time
The system must be disarm,
Press [*] [1] follow by [master code]
Press [30]
Enter the me [HHMM]
Press [#] to save & exit Programming menu.
To Set The System Date
The system must be disarm,
Press [*] [1] follow by [master code]
Press [31]
Enter the date [DDMM]
Press [#] to save & exit programming menu.
To Set The System Year
The system must be disarm,
Press [*] [1] follow by [master code]
Press [32]
Enter the Year [YYYY]
Press [#] to save & exit Programming menu.
Monitor • Control • Surveillance
Interface
DHCP
DHCP Server
DHCP Table
DNS
oem-adc4936ff0a
• Then click back to the Reboot message web page (figure 10.1), click the link (h p://DEFENDER:8088/).
• Defender Smart Alarm Login page was successfully access (figure 3.0).
b. If user want to assign a sta c IP address with an IP address is no assign by Router, example, refer to
figure 10.3, 192.168.1.3 was assign by Router, if user want to use another IP address as sta c,
192.168.1.10.
• Go to Network Configura on (figure 10.0), un- ck the ENABLE DHCP and change the IP Address to
192.168.1.10 and click the Save Config bu on.
• Reboot message will shown (figure 10.1). PS: Exit (close) the browser without click the link
(h p://DEFENDER:8088/).
• Login to Router's configura on, select DSA Mac address, change the IP address to 192.168.1.10, and
change the status to sta c. Then click save.
• At computer, open Command Prompt (start->run->key in cmd)
8 25
Quick Interface Advanced Access
Start Setup Setup Management
Internet LAN Wireless
RIP2-B None
Dynamic Route : Direction :
Multicast : Disabled
IGMP Snoop : Disabled Enabled
Disabled Enabled Relay
DHCP :
Starting IP Address:
IP Pool Count:
Lease Time :
seconds (0 sets to default value of 259200)
Hostname IP Address MAC Address
oem-adc4936ff0a
192.168.1.2 00:E0:4C:77:36:54
192.168.1.3 00:04:A3:00:90:58
DNS Relay : Use Auto Discovered DNS Server Only
Primary DNS Sever : N/A
Secondary DNS Server : N/A
Figure 10.2 Router Configura on
Hostname IP Address MAC Address
Manual Config
192.168.1.3 00:04:A3:00:90:58
00:E0:4C:77:36:54
192.168.1.2
Figure 10.3
Monitor • Control • Surveillance
Maintenance Status Help
Status Expire Time
Auto 2days, 21:57:40
Auto 2days, 22:27:9
Status Expire Time
N/A
Auto 2days, 21:56:18
