Faults
The dashboard contains a status indicator. If this lights up green without blinking the Navigator is ignited
and there are no problems. In case of a fault the status indicator indicates a fault by blinking codes. If
the status indicator shows a fault, the first thing to do is turn off the power of the Navigator and ignite
again.
If the indicator shows another fault, please count the blinks. These show a code which indicates a fault.
The flash code list below shows all the meanings of the flashes. The list also containt possible causes and
an eventual solution of the problem. If you are unable to solve the problem with help of this list, please
contact your dealer.
NUMBER OF
FAULT
BLINKS
1 Charge battery
2 Battery voltage too low
3 Battery voltage too high
4 Current time limit out
5 Brake fault
6 Gas pot not in neutral at
power up
7 Speed pot error
8 Motor volts error
9 Other internal error
All Van Os Medical products are built for a long and durable lifetime. However, during time reparation
and maintenance to your Navigator will not be renumerative any more. Your dealer will contact you in
time for this. When recycling the Navigator your should consided the below points:
at scooter recycling the current or local precautions should always be followed
•
the Navigator only contains known materials. A couple of this materials, if collected separately,
•
can be recyled
at development and build of the Navigator for all used materials were known waste disposal
•
possibilities and no risks were known for recycling persons, not containing the batteries
Make sure during recycle of the Navigator the batteries do not get damaged. They should be offered to
a certified instance or company for further disposal. When dealing with batteries always take the
needed precautions for protection of yourself and the environment.
SCOOTER
REMARKS
CONDITION
DRIVING POSSIBLE BATTERY VOLTAGE LOWERED TO LESS
THAN 23.3 V, CHARGE BATTERIES SOON
DRIVING NOT BATTERY VOLTAGE LOWERED TO LESS
POSSIBLE THAN 16.5 V, CHARGE BATTERIES
IMMEDIATELY
DRIVING NOT BATTERY VOLTAGE INCREASED TO HIGHER
POSSIBLE THAN 32 V. PROBABLY DEFECT CHARGER
DRIVING NOT DETECTOR DETECTED SHORTCUT IN THE
POSSIBLE MOTOR. WARN DEALER
DRIVING NOT CHECK IF FREEWHEEL IS DISCONNECTED
POSSIBLE
DRIVING NOT CONTACT DEALER
POSSIBLE
DRIVING NOT CONTACT DEALER
POSSIBLE
DRIVING NOT CONTACT DEALER
POSSIBLE
DRIVING NOT CONTACT DEALER
POSSIBLE
