User manual

Picture 25

Always climb or descend gradients
perpendicular to the slope or ramp
(picture 27)
Picture 27
Control units
The control units of the Navigator are very clearly arranged on the dashboard (picture 29). The charging
plug is located on the tiller, the freewheel lever on the rear right side of the scooter. The status
indicator is located on the dashboard. See the below picture for a survey of all control units.
Illumination
Indicator control left
Battery indicator
Claxon control left
Picture 26
Do not load or carry heavy items in
the basket while driving downhill
(picture 28)
Picture 28
Status indicator
Picture 29
Claxon control right
Excel Navigator
Snelheid instelling
Indicator control right
Page 9
