- Page 1 LAM1210 Electric Hob LAM1211 LAM1213 User & Installation Guide...
- Page 2 LAMONA Appliances Dear Customer, Congratulations on your choice of hob which has been designed to give you excellent service. The user manual will help you use your product quickly and safely. Please read this user manual before installing and using the hob.
- Page 3 User manual LAM1210 / LAM1211 / LAM1213 This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved.
- Page 4 LAMONA Appliances Unattended cooking on a hob with fat or oil can be dangerous and may result in fire. NEVER try to extinguish a fire with water, but switch off the appliance and then cover flame e.g. with a lid or a fire blanket.
-
Page 5: Table Of Contents
User manual LAM1210 / LAM1211 / LAM1213 Index 01 - Before Using the hob 02 - Safety General Fire safety advice If a pan catches Deep fat frying If you have an Electrical Fire 03 - Using your hob Controls... -
Page 6: Before Using The Hob
LAMONA Appliances 01 - Before using the hob Make sure that you have removed all packaging, wrappings, stickers and from the hob surface. It is recommended that you clean and wash the hob surface before using for the time. Before using the hob for the first time switch the hotplates on to full power for five minutes, without placing any pans on top. -
Page 7: Fire Safety Advice
User manual LAM1210 / LAM1211 / LAM1213 Deep-fat frying presents more Never use the hob surface as a chopping board or food preparation area, as this may dangers in your kitchen lead to it becoming damaged. Never put metal cooking utensils, cutlery, ever ll a chip pan (or other deep fat fryer) knives or other metal objects on the hob. -
Page 8: Using Your Hob
LAMONA Appliances 03 - Using the hob - Electric Hob Do not use the hob if the surface is cracked, as electrical parts are directly beneath. Switch off the appliance at the supply to prevent electric shock and contact your supplier. -
Page 9: Hob Layout
User manual LAM1210 / LAM1211 / LAM1213 Hob layout Rear Left Zone (Rappid) Ø145mm 1500w Rear right control Knob Suitable for 6” or 15cm diameter saucepan Rear left control Knob Rear Right Zone (Standard) Ø180mm 1500w Front left control Knob Suitable for 7”... -
Page 10: Cleaning And Maintenance
LAMONA Appliances 04 - Cleaning & maintenance How to clean your hob Switch plates off and let cool. If necessary, Wipe any spillage as soon as possible after the treat plates with a cleaning agent (cleaner/ hob has cooled. conditioner available in selected stores). -
Page 11: Clearances And Dimensions Requirements
User manual LAM1210 / LAM1211 / LAM1213 Clearances and dimensions requirements Minimum distance between carcasses must be equal to width of hob 400mm min 55mm min 50mm min between hob and rear wall 560mm (>60mm to cut out aperture) 490mm... -
Page 12: Connect To The Electricity Supply
LAMONA Appliances Place the hob in the aperture, checking the hob is Installation above an oven covering the worktop along all four sides. Set the If the appliance is installed with an oven front edge of the appliance parallel with the front of underneath, please leave atleast 25mm of the worktop. -
Page 13: Technical Data
User manual LAM1210 / LAM1211 / LAM1213 Technical Data Outer Dimentions Width 580mm Depth 510mm Height 58mm Cutout Dimentions Width 560mm Depth 490mm Cook Zones Rear Left Zone (Rapid) Ø145mm 1500w Rear Right Zone (Standard) Ø180mm 1500w Front Left Zone (Rapid) Ø180mm 2000w... -
Page 14: Your Guarantee
LAMONA Appliances 06 - Your guarantee Product Guarantee Details (UK only) breakdown repairs. (Details of which are shown on your Proof of Purchase Document). Any claim during the period of the guarantee (MUST BE ACCOMPANIED BY THE PROOF OF PURCHASE) The product must be correctly installed and operated in accordance with the manufacturer’s... - Page 15 User manual LAM1210 / LAM1211 / LAM1213 _ 15...
- Page 16 LAMONA Appliances Notes...
- Page 17 User manual LAM1210 / LAM1211 / LAM1213 Notes _ 17...
- Page 18 Issue 6 27/04/2015 If supplied, please stick your self adhesive product rating plate here, or make a note of the product serial number below in the box below for future reference. Serial Number : ...................
