Lunette 2 Series

Curved Fixed Frame Projection Screen
User's Guide
Important Safety and Warning Precautions
Please follow these instructions carefully to ensure proper maintenance and safety with your Lunette
Series Fixed Frame Curved Screen
1. When hanging the screen up, please make sure that no other objects – such as power switches, outlets,
furniture, ladders, windows, etc., occupy the space designated for your Fixed-Frame screen.
2. Regardless if the screen is hung on or installed into the wall; make sure that the proper mounting anchors
are used and that the weight is supported appropriately by a strong and structurally sound surface just as any
large and heavy picture frame should.
(Please consult a home improvement specialist for the best advice on installation.)
3. Frame parts are made of high quality velour-surfaced aluminum and should be handled with care.
4. When not in use, cover the screen with a furniture sheet to protect it from dirt, grime, paint, or any other
impurities.
5. When cleaning, use a soft cloth moistened with warm water to remove any marks on the frame or screen
surface.
6. Never attempt to use any solutions, chemicals, or abrasive cleaners on the screen surface.
7. In order to avoid damaging the screen, avoid touching it directly with your fingers, writing tools, or any
other sharp or abrasive objects.
8. Spare parts should be placed out of reach of small children in accordance with household safety guidelines.
CAUTION:
The projection screen frame is made of high-quality aluminum alloy and should be handled with care.
Use a soft cloth with warm water to remove any spots on the screen material surface.
To avoid damaging the screen material, never attempt to use any solutions, chemicals, or abrasive
cleaners on the screen itself, and never attempt to touch the screen with your fingers or sharps/abrasive
objects.
2/3/2016
www.elitescreens.com


Advertisement

loading
Need help?

Need help?

Do you have a question about the Lunette 2 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Elite Screens Lunette 2 Series

  • Page 1   Lunette 2 Series   Curved Fixed Frame Projection Screen User’s Guide Important Safety and Warning Precautions Please follow these instructions carefully to ensure proper maintenance and safety with your Lunette Series Fixed Frame Curved Screen 1. When hanging the screen up, please make sure that no other objects – such as power switches, outlets, furniture, ladders, windows, etc., occupy the space designated for your Fixed-Frame screen.
  • Page 2   Hardware and Parts List A. Dry-wall anchor B. 1.77” L –Bracket x 2-4 pcs C. 3.54” L-Bracket D. Lower Bracket x 12 pcs x 0-2 pcs x 2pcs 125” models and above = 2 pcs  125” models and above = 2pcs  Under 125” = 0 pcs  Under 125” = 4 pcs  E. M5x15 screws F. Wood screws G. Plastic clip plate x H.
  • Page 3   Frame Assembly and Screen Material Installation 1. Insert both Elbow Joints (I) into each Horizontal Curved Frame and join all four frame parts together as shown below.     2. After making sure that all four corners join at right angles (forming a perfect rectangle), fasten the four angles together by using M5x15 screws (E).
  • Page 4 (2) Begin by securing the four corners in the following sequence A→B→C→D (Fig.6). (3) Insert the fix the plates as shown on Fig. 5. Fix plate ① is about 10cm away from the frame’s corner. Fix plate ② is about 5cm away. (Fig.7)   ...
  • Page 5   J  O    Fig.10   K  N    L    (6) Fasten the remainder of the fix plates in the empty locations in the red markings to complete attaching the screen material. (Fig.11)     Fig.11        Black backing for AcousticPro Models This procedure only applies to AcousticPro models.
  • Page 6: Installation

    Center Support Bar 1. Center Support Bar may be packed in a plastic tube with the screen material. Center support bar 2. Insert the Center Support Bar into the upper top groove on the back of the frame (note: this not the same groove where the fix plate inserts) with the bottom end near the center point of the frame, and place it in at an angle so that both ends of the bar are aligned with the groove.
  • Page 7 1. Use butterfly screws to install the upper bracket as shown in following diagrams     Use two 1.77” brackets to assemble an Use one 1.77” bracket and one 3.54” bracket to   upper bracket for models below 125” assemble an upper bracket for models 125” and above. 2.
  • Page 8: Bottom Bracket

    Top Bracket  Frame  Bottom Bracket  H= Overall height  F=H‐149.9mm (5.9”)  For H Measurement, please view the dimensions table at:  Note: Two (2) or more people must install the frame for added safety.  www.elitescreens.com/index.php/download/product‐dimension‐table‐and‐line‐drawings   4. Mount the frame on the wall mount in the center. Then, slide the upper brackets over to the frame grooves and gently pull the frame down onto the bracket.
  • Page 9 Installation diagram   of frame and bracket Base line  Swing the bottom  bracket to the left or  right to fit it in the  groove of the lower  frame.  For a local Elite Screens contact or Technical Support, please visit  www.elitescreens.com     2/3/2016  www.elitescreens.com  9   ...
