SIM Chip Installation

Note: SIM chips are only used in GSM/GPRS equipped terminals. The SIM chip slot is located under the
terminal beneath a secured panel. The door must be removed by unscrewing the screw with a small
Phillips screwdriver. Lift the door up and then off to remove.
1. The gate is located on the top right side. The SIM chip will be protected by a locking gate.
2. To open the gate, carefully use your fingernail or a small flathead screwdriver to slide the gate
from the LOCKED to the UNLOCKED position (slide to the right to unlock). The distance required
is about 1/8 inches or 3mm.
3. Once unlocked, use the square slot to open the gate. The gate is on a hinge and should NOT be
removed.
4. Once the gate is open, the SIM chip can be easily placed into the slot by inserting the card into
the grooves of the holder door. The metallic contact on the SIM card must be placed face down
(toward the contacts on the unit).
5. Close the door by pushing down and slide the gate to the left to lock it.
6. Replace the cover and tighten the screw to lock the compartment.
