XD2500 Mobile Payment Terminal
User Guide
2 8 7 1 P u l l m a n S t r e e t , S a n t a A n a , C A 9 2 7 0 5
P h o n e . 9 4 9 . 4 8 6 . 0 3 2 0
F a x . 9 4 9 . 4 8 6 . 0 3 3 3
w w w . e x a d i g m . c o m

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the XD2500 and is the answer not in the manual?

Questions and answers

Related Manuals for Exadigm XD2500

Summary of Contents for Exadigm XD2500

  • Page 1 XD2500 Mobile Payment Terminal User Guide 2 8 7 1 P u l l m a n S t r e e t , S a n t a A n a , C A 9 2 7 0 5 P h o n e .
  • Page 2 The information contained in this document is subject to change without notice. ExaDigm makes no warranty of any kind with regard to this material, including, but not limited to, the implied warranties or merchantability and fitness for a particular purpose.

  • Page 3: Table Of Contents

    XD2500 User Guide Table of Contents XD2500 Mobile Terminal ..................4 Accessories, Parts, Peripherals, and Modems ............. 4 Installing the XD2500 ................... 4 Terminal Components ..................5 4.1 Front View ........................5 4.2 Terminal Ports ....................... 5 Installing a Paper Roll ................... 6 Installing and Removing the Battery Pack ............

  • Page 4: Xd2500 Mobile Terminal

    XD2500 unit Installing the XD2500 When installing the ExaDigm XD2500 for countertop, use a location near a power outlet and a telephone or direct dial connectivity if using this option. The battery time will vary according to the terminal setup and merchants desired usage.

  • Page 5: Terminal Components

    XD2500 User Guide Terminal Components Front View Terminal Ports The figure below shows the ports used to connect the terminal to a power source, telephone line and various devices such as PIN pads using the multi-port connector. © 2009 ExaDigm, Inc.

  • Page 6: Installing A Paper Roll

    XD2500 User Guide Installing a Paper Roll A paper roll is required to print receipts and reports. Follow the steps below to install a paper roll: 1. Place forefinger under flap at top of printer compartment and pull forward using force.

  • Page 7: Card Swipe

    CDMA Before you use the terminal to do live transactions with TCP/IP connections, you need to make sure the modem is activated. Contact your network carrier, ISO or ExaDigm to confirm activation. © 2009 ExaDigm, Inc. Page 7 of 10...

  • Page 8: Connecting External Readers

    XD2500 User Guide GSM/GPRS Before you use the terminal to do live transactions with TCP/IP connections, you need to make sure the modem is activated by inserting the SIM card. Contact your network carrier, ISO or ExaDigm to confirm activation. 10.0 Connecting External Readers The multi-purpose USB port allows various devices to be attached and used.

  • Page 9: Terminal Indicators

     Avoid dropping the battery and charger. If the battery or charger is dropped, especially on a hard surface, and the user suspects damage, contact ExaDigm for inspection.  Improper battery or charger use may result in a fire, explosion, or other hazard.
  • Page 10 XD2500 User Guide RF exposure information: The SAR limit of USA (FCC) is 1.6 W/kg averaged over one gram of tissue. Device types XD2500 (FCC ID: XDQ2500EXA) has also been tested against this SAR limit. The highest SAR value reported under this standard during product certification when properly worn on the body is 0.228 W/kg.
