4.0

Terminal Components

4.1

Front View

NFC/Contactless
2 Programmable Function Keys
Up/Down Arrow
4.2

Terminal Ports

The figure below shows the ports used to connect the terminal to a power source, Ethernet port, PIN pad
and the RS-232 port for additional cables.
Power
© 2014 ExaDigm, Inc.
Screen
LED Lights
Power ON/OFF
PIN Pad
Ethernet
RS-232
Dial
Mini B USB
Page 4 of 16
NX1200 User Guide
Magnetic Card Reader
Feed Key
Cancel Key
Clear/Backspace Key
Enter Key
Smart Card Reader
USB
