Page 1: User Manual
WALL MOUNTABLE 2.1-CHANNEL BLUETOOTH SOUNDBAR SPEAKER WITH FM RADIO USER MANUAL JSBW-650 PLEASE READ THIS USER MANUAL COMPLETELY BEFORE OPERATING THIS UNIT AND RETAIN THIS BOOKLET FOR FUTURE REFERENCE. -
Page 2: Dear Jensen® Customer
The serial number of this product is found on its bottom cover. You should note the serial number of this unit in the space provided as a permanent record of your purchase to aid in identification in the event of theft of loss. Model Number: JSBW-650 Serial Number: ____________________... -
Page 3: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS When used in the directed manner, this unit has been designed and manufactured to ensure your personal safety. However, improper use can result in potential electrical shock or fire hazards. Please read all safety and operating instructions carefully before installation and use, and keep these instructions handy for future reference. -
Page 4: Important Note
16. Battery shall not be exposed to excessive heat such as sunshine, fire or the like 17. Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type. 18. Do not attempt to dismantle, open or repair this product yourself. If a fault occurs, seek advice from your local qualified service technician or contact the distributor via the telephone number at the back of this instruction manual. -
Page 5: Installations
Attach the base as shown below and use the supplied round head screw to secure it to the sound bar. Be sure the assembled sound bar is placed on a level surface. Note: The JENSEN logo on the front of the speaker can be rotated 90 degrees for vertical mounting. - Page 6 Mounting the JSBW-650 on a wooden wall It’s important to be sure there are no electric, gas or water lines located behind the wall where you are attaching the sound bar. We recommend having this speaker professionally installed. Use the included wall mounting accessories and template to attach the sound bar to the wall.
-
Page 7: Main Unit
screws into the anchors and tighten until the screw head is fully inserted and flush with the metallic bracket. 5. Place the sound bar onto the mounting brackets. Make sure the sound bar is attached firmly to the wall. LOCATION OF CONTROLS MAIN UNIT Front View Back View... -
Page 8: Remote Control
MODE INDICATOR LED FM WIRE ANTENNA AUX-IN 1 L/R RCA CONNECTORS DC IN JACK AUX-IN 2 JACK FM TUNE + 7. VOLUME + BUTTON POWER ON/STANDBY ; SOURCE BUTTON 9. VOLUME - BUTTON 10. REMOTE INFRARED SENSOR REMOTE CONTROL 1. POWER ON/STANDBY BUTTON 2. -
Page 9: Getting Started
GETTING STARTED CONNECTING THE JSBW-650 TO EXTERNAL AUDIO DEVICES You can connect the JSBW-650 audio input to the audio output of your television or DVD Player. Please see figure below. NOTE: 1. Make sure that the power is turned off when connecting or disconnecting the other devices. -
Page 10: Listening To The Fm Radio
2.) Removed the exhausted battery and then install 1 new “CR2025” lithium battery according to the polarity diagram on the battery compartment. 3.) Insert the battery holder into the remote control and make sure it locks into place. NOTE: Only use a well-known brand of battery to ensure the longest life and best performance. -
Page 11: Bluetooth Operation
1. With the power on, press the SOURCE button on remote control or tap the /SOURCE button on main unit repeatedly to select Bluetooth mode. The Mode Indicator LED turns blue and will be flashing. The JSBW-650 is now ready to pair (link) with your Bluetooth device. - Page 12 2. Select the JSBW-650 from the devices list on your cell phone for linking. The Mode Indicator LED stops flashing and remains lit blue if the JSBW-650 and your cell phone have been re-linked successfully.
-
Page 13: Auxiliary Input
LISTENING TO AUDIO FROM A TV/DVD PLAYER/VCR OR DVR You can connect the JSBW-650 to other external audio devices using the AUX-IN 1 RCA connectors located on the back of the unit. -
Page 14: Care And Maintenance
NOTE: If you connect this unit to the Line-Out Jack of your external device then you only need to adjust the volume control of this unit. If you connected the Headphone Jack of your external device then you may need to adjust both the volume control of your external device and the volume control of this unit to find the most desirable volume setting. -
Page 15: Specification
Noise or sound Station not tuned properly for Full extend or rotate the wire antenna for best reception. distorted on FM Retune the FM broadcast station. broadcast Volume level is set too high. Decrease the volume. If the external device original sound source is of poor quality, distortion and noise are easily noticed with high-power speakers. - Page 16 90 DAY LIMITED WARRANTY AND SERVICE VALID IN THE U.S.A ONLY SPECTRA MERCHANDISING INTERNATIONAL, INC. warrants this unit to be free from defective materials or factory workmanship for a period of 90 days from the date of original customer purchase and provided the product is utilized within the U.S.A.
