Schematic Diagrams - Akai AJ-C3150R Service Manual

ELECTRICAL PARTS LIST - CONTINUED
Ref. No.
R816,819
R820
R815
R888,889
VR801
CAPACITORS
C601,602,603,604
C823,835,836
C803,804
C814
C820,821
C811,812
C817,818
C805,806
C815
C807,808,819,822,825,826 ,831
C605,816
C801,802
C809,810
C813,824
TRANSISTORS
Q806
Q804,807
Q803
Q801,802
INTEGRATED CIRCUITS
IC801
IC802
DIODES
D802,803
D801
D804
D601,602,603,604
WIRES
CON2 TO CON3
CN802 TO RECTIFIER PCB CN602 HSG CD268-3B(C) PEC 2507H-3 w/250mm
MISCELLANEOUS
HP801
CN802
CN801
Description
*CdF RESISTOR 470 ohm
*CdF RESISTOR 4.7 Kohm
*CdF RESISTOR 47 Kohm
*CdF RESISTOR 4.7 ohm
VR-E12M2GV050KAWSH&D XV012302GPVN15FS-15
A50Kx2/I /XV012311GPVN15FS-L15A50KX2
(F003-010380-025) CERAMIC CAP 0.01 uF/
50V +80%-20%
CERAMIC CAP 0.1 uF/16V +80%-20%
CERAMIC CAP 470 pF/50V +-10%
(UP050B471K-BB) (AXIAL TAPED 52mm)
CERAMIC CAP 0.047 uF/50V +80%-20%
(UP050F473Z-BB) (AXIAL TAPED 52mm)
CERAMIC CAP 560 pF/50V +-20%
(AXIAL TAPED 52mm)
#MYLAR CAP 0.1 uF/50V +-10%
#MYLAR CAP 0.0027 uF/100V +-10%
ELECT CAP 1 MFD/50V +-20% (5x11)
ELECT CAP 4.7 MFD/50V +-20% (5x11)
ELECT CAP 100 MFD/25V +-20% (6.3x11)
ELECT CAP 1000 MFD/25V +-20% (12.5x20)
*CdF ELECT CAP 47 MFD/16V +-20% (5x11)
ELECT CAP 470 MFD/10V +-20% (8x11.5)
ELECT CAP 470 MFD/16V +-20% (10x12.5)
(F008-211850-005) TRANSISTOR 2SB1566E/F
(ROHM)
TRLNPNSST-TAP&TO-092 3DG1815
TRLPNPPWR-TAP&TO-092 3CA8550
TRANSISTOR 2SK2541-T/2SK2541 (NEC)
ICAMP-POWR-ST-00002W UTC8227/LS2027/
TA8227P DIP-12H POWER AMP2Wx2
IC L-7805CV (059)
DIODE IN-4148 ROHM/TELEFUNKEN TAP**50
KEL(NS)(TAP:52mm)/NS(FAIRCHILD)/SEMTECH
ZENER DIODE 2.2V
ZENER BZX55C6V8CECCL, 6.8V, 1/2W (ROHM)
SGS-THOMSON
RECTIFIER IN-4001B
CONN PIN 4 PINS (3.5+143+3.5) PITCH 2mm
AWG26#2651
RED,NC,BLACK AWG22#UL1007 SLDG.4mm
HEADPHONE JACK STEREO 3.5mm #MSJ-2000
(8Z-CS1-604-01) (Cd FREE)
HEADER 3 PINS PEC #2507-WS-3 PITCH 2.5mm
VERTICAL REPLACE:135-005267-030
HEADER 4 PINS PEC #2507-WS-4 PITCH 2.5mm
VERTICAL REPLACE:135-005267-040
9
Mfr's Part No. Qty.
001-047151-016 2
001-047251-016 1
001-047351-016 1
001-047851-016 2
030-E12503-201 1
003-010380-050 4
003-010480-016 3
003-247110-050 2
003-247380-050 1
003-256110-050 2
004-010410-050 2
004-027210-100 2
006-001000-50D 2
006-004000-50D 1
006-010100-25D 7
006-010200-25D 2
006-047000-16D 2
006-047100-10D 2
006-047100-16D 2
008-201566-000 1
008-618150-000 2
008-685500-000 1
008-902541-000 2
010-398227-000 1
010-727805-000 1
011-004148-000 2
011-010022-120 1
011-010068-120 1
011-024001-000 4
050-040150-200 1
136-030268-C00 1
116-002000-352 1
135-2507WS-030 1
135-2507WS-040 1
