Akai AJ-C3150R Service Manual page 10

ELECTRICAL PARTS LIST - CONTINUED
Ref. No.
WIRES
TO CASS DECK MOTOR B+
TO CASS DECK MOTOR B-
CASS DECK SW
CASS DEKC TO GND
FROM E/H TO CN301
MISCELLANEOUS
CN301
MOTOR-, MOTOR+, L.SW2, L.SW1 *CdF SOLDERING PIN
TUNING PORTION
RESISTORS [All are +-5% 1/16w (1/8w) tape & wheel resistors unless otherwise specified]
R414,418
R409,410,411,417,424,425,426,442, *CdF RESISTOR 10 Kohm
443,446
R436,435,434
R422,423
R432
R403,405,407
R415,420,421,429,460
R413,416,419,431
R430
R433
R402
CAPACITORS
C406,429,433
C408,413,436
C431,435
C428
C415
C430,434
C403,404,405,411,412
C438
C401,402
C437,439
C409
C417,418
C432
C424,425
C422
Description
JP WIRE AWG26#1007 3x3mm 150mm RED
JP WIRE AWG26#1007 3x3mm 150mm BLACK
*CdF JP WIRE AWG26#1007 3x3mm 250mm WHITE
JP WIRE AWG26#1007 5x5mm 90mm BLACK
HSG CD368-4B(C) PEC 2507-H-4 w/234mm BLK
SHIELD WIRE AWG30#UL2547/3C SLDG.2mm
HEADER 4 PINS PEC #2507-WS-4 PITCH 2.5mm
VERTICAL REPLACE:135-005267-040
CASSDECK-SM-F-212+2P TK20FX-V683-900
CKD KIT w/o MOTOR,RP/H,E/H (CD1811)
MOTOR-DC-012V-NORMAL 12V #SM-3425S-2B
SAMSON
RP/HEAD-&&-&&&&&&&&& #6PA (CHENWEI)
RP/HEAD-ST-TECHRECO& #APX4211X(S3)
*CdF RESISTOR 1 Kohm
*CdF RESISTOR 100 Kohm
*CdF RESISTOR 12 Kohm
*CdF RESISTOR 220 ohm
*CdF RESISTOR 2.2 Kohm
*CdF RESISTOR 330 ohm
*CdF RESISTOR 3.3 Kohm
*CdF RESISTOR 4.7 ohm
RESISTOR 51 Kohm
RESISTOR 5.6 Kohm
CERAMIC CAP 0.001 uF/50V +80%-20%
(F003-010380-025) CERAMIC CAP 0.01 uF/
50V +80%-20%
CERAMIC CAP 0.0015 uF/50V +80%-20%
CERAMIC CAP 330 pF/50V +-10%
CERAMIC CAP 0.015 uF/50V +-10%
(UP050B153K-B-BZ) (AXIAL TAPED 52mm)
CERAMIC CAP 10 pF/50V +-5% (NPO)
(CC45-CH1H100J/RBU04CH100J-L)
CERAMIC CAP 100 pF/50V +-5% (NPO)
(CC45-CH1H101J/RBU04CH101J-L)
CERAMIC CAP 15 pF/50V +-5% (NPO)
(CC45-CH1H150J/RBU04CH150J-L)
CERAMIC CAP 20 pF/50V +-5% (NPO)
(CC45-CH1H200J/RBU04CH200J-L)
CERAMIC CAP 30 pF/50V +-5% (NPO)
(CC45-CH1H300J/RBU04CH300J-L)
#MYLAR CAP 0.01 uF/100V +-10%
#MYLAR CAP 0.018 uF/100V +-10%
POLY CAP 390pF/50V +-5% (B391J09P2HH33AAA)
*CdF ELECT CAP 0.1 MFD/50V +-20% (VX/5x11)
ELECT CAP 0.47 MFD/50V +-20% (5x11)
11
Mfr's Part No. Qty.
051-673150-006 1
051-673150-009 1
051-673250-008 2
051-675090-009 1
136-040368-C01 1
135-2507WS-040 1
137-300000-002 4
150-700683-K00 1
151-123425-000 1
152-020006-000 1
152-024211-000 1
001-010251-016 2
001-010351-016 10
001-010451-016 3
001-012351-016 2
001-022151-016 1
001-022251-016 3
001-033151-016 5
001-033251-016 4
001-047851-016 1
001-051351-016 1
001-056251-016 1
003-010280-050 3
003-010380-050 3
003-015280-050 2
003-033110-050 1
003-215310-050 1
003-410050-050 2
003-410150-050 5
003-415050-050 1
003-420050-050 2
003-430050-050 2
004-010310-100 1
004-018310-100 2
005-039100-000 1
006-000100-50C 2
006-000400-50D 1
