Electrical Parts List ................................................................................................................................ 6
Printed Circuit Boards ........................................................................................................................... 13
Wiring Diagram ..................................................................................................................................... 15
Schematic Diagrams ............................................................................................................................. 17
Alignment Set-up Procedures ................................................................................................................ 21
Equipment Connection Diagrams ........................................................................................................... 22
Voltage Chart ....................................................................................................................................... 24
IC Lead Identification and Internal Diagrams ........................................................................................... 26
Block Diagrams .................................................................................................................................... 30
Exploded Drawing Parts List .................................................................................................................. 32
Exploded Drawing ................................................................................................................................. 34
Many electrical and mechanical parts in this chassis have special safety characteristics.
These safety characteristics often pass unnoticed and the protection afforded by them cannot
necessarily be obtained by using replacement components rated for higher voltage, wattage, etc.
Replacement parts that have these special safety characteristics are identified in this manual
and its supplements; electrical components having such features are identified by
schematic diagram and the parts list.
Before replacing any of these components, read the parts list in this manual carefully.
The use of substitute replacement parts that do not have the same safety characteristics as
specified in the parts list may create shock, fire or other hazards.
PORTABLE CD SYSTEM
AJ-C3150R
CONTENTS
PRODUCT SAFETY NOTICE
Page
in the
Advertisement
Table of Contents
Related Manuals for Akai AJ-C3150R
Summary of Contents for Akai AJ-C3150R
-
Page 1: Table Of Contents
PORTABLE CD SYSTEM AJ-C3150R CONTENTS Page Specifications & Performance Specifications .................... 3 Electrical Parts List ..........................6 Printed Circuit Boards ........................... 13 Wiring Diagram ............................. 15 Schematic Diagrams ..........................17 Alignment Set-up Procedures ........................ 21 Equipment Connection Diagrams ......................22 Voltage Chart ............................ -
Page 2: Specifications
SPECIFICATIONS GERENAL Power Source :AC 120V ~ 60Hz (USA & CANADA) :AC 220V ~ 50Hz (China) :AC 230V ~ 50Hz (Europe & Hong Kong) :AC 240V ~ 50Hz (Australia) :DC 12V (8xC size or UM-2 batteries) Power Consumption Specifications subject to change without notice. PERFORMANCE SPECIFICATIONS GENERAL TEST CONDITION Power Supply... - Page 3 PERFORMANCE SPECIFICATIONS - CONTINUED (AM) SECTION, AMPLITUDE, MODULATION TEST ITEMS UNIT NOMINAL LIMIT 1. Tuning Range 522 - 1620 2. I. F. ±3 3. S/N 5mV/m 0.999MHz 4. Sens. (at S/N 20dB) 0.603MHz dBµV 0.999MHz dBmV 1.404MHz dBmV 5. I.F. Rej. 0.603MHz 6.
-
Page 4: Printed Circuit Boards
PERFORMANCE SPECIFICATIONS - CONTINUED CASSETTE SECTION TEST ITEMS UNIT NOMINAL LIMIT 1. Tape Speed (B-111LNA) 3000 3% / -3% 2. Wow & Flutter Rms (JIS R.M.S.) (B-111LNA) 0.35 0.45 3. Fast Forwards Time Sec. 100 - 180 4. Rewind - Time Sec. -
Page 5: Electrical Parts List
ELECTRICAL PARTS LIST Ref. No. Description Mfr's Part No. Qty. MAIN PCB PCB CD1831T-02-01 (94HB) 033-001831-400 KEY & DISPLAY PCB PCB CD1831T-02-02 (94HB) 033-001831-400 BATTERY PCB PCB CD1831T-01-03 (94HB) 033-001831-400 BATTERY PCB PCB CD1831T-01-04 (94HB) 033-001831-400 RECTIFIER PCB PCB CD1790-01-07 (94V0) 033-001790-100 CD PORTION RESISTORS [All are +-5% 1/16w (1/8w) tape &... -
Page 6: Wiring Diagram
ELECTRICAL PARTS LIST - CONTINUED Ref. No. Description Mfr's Part No. Qty. C162 CERAMIC CAP 0.0068 uF/50V +80-20% 003-068280-050 C154 CERAMIC CAP 56pF/50V +-5% (NPO) 003-456050-050 (CC45-CH1H560J/RBU04CH560J-L) C112,113 ELECT CAP 3.3 MFD/50V +-20% (5x11) 006-003000-50D C106,118,157,161,163 ELECT CAP 100 MFD/10V +-20% (5x11) 006-010100-10D C115,116,175,319 ELECT CAP 22 MFD/25V +-20% (5x11) - Page 7 ELECTRICAL PARTS LIST - CONTINUED Ref. No. Description Mfr's Part No. Qty. TRANSISTORS Q111 (F008-800111-113) TR NPNSST-RAD&SC-072 008-801143-000 DTC114TS(TP)(ROHM)/KRC-111M (KEC) Q112 TRANSISTOR 2SK2541-T/2SK2541 (NEC) 008-902541-000 SWITCHES SW101,102,103,104,105,106,107, TACT SWITCH 4P 5mm 100G #1102A-4/ 021-110200-002 EVQ PAC 05R (=021-KHH901-000) WIRES CN108 TO CN110 FFC CABLE 16 PINS L=160mm PITCH:1mm 040-160160-101 RLW8027-1A(01-0735C-3F16-152S04N08-08NN)
-
Page 8: Schematic Diagrams
ELECTRICAL PARTS LIST - CONTINUED Ref. No. Description Mfr's Part No. Qty. R816,819 *CdF RESISTOR 470 ohm 001-047151-016 R820 *CdF RESISTOR 4.7 Kohm 001-047251-016 R815 *CdF RESISTOR 47 Kohm 001-047351-016 R888,889 *CdF RESISTOR 4.7 ohm 001-047851-016 VR801 VR-E12M2GV050KAWSH&D XV012302GPVN15FS-15 030-E12503-201 A50Kx2/I /XV012311GPVN15FS-L15A50KX2 CAPACITORS C601,602,603,604... - Page 9 ELECTRICAL PARTS LIST - CONTINUED Ref. No. Description Mfr's Part No. Qty. REMOTE CONTROL PORTION RESISTOR [All are +-5% 1/16w (1/8w) tape & wheel resistors unless otherwise specified] R101 *CdF RESISTOR 22 ohm +-5% 1/16W (1/8W) 001-022051-016 CAPACITORS C198 CERAMIC CAP 0.02 uF/50V +80%-20% 003-020380-050 EC101 ELECT CAP 100 MFD/10V +-20% (5x11)
- Page 10 ELECTRICAL PARTS LIST - CONTINUED Ref. No. Description Mfr's Part No. Qty. WIRES TO CASS DECK MOTOR B+ JP WIRE AWG26#1007 3x3mm 150mm RED 051-673150-006 TO CASS DECK MOTOR B- JP WIRE AWG26#1007 3x3mm 150mm BLACK 051-673150-009 CASS DECK SW *CdF JP WIRE AWG26#1007 3x3mm 250mm WHITE 051-673250-008 CASS DEKC TO GND...
- Page 11 ELECTRICAL PARTS LIST - CONTINUED Ref. No. Description Mfr's Part No. Qty. C426 ELECT CAP 1 MFD/50V +-20% (5x11) 006-001000-50D C410 ELECT CAP 3.3 MFD/50V +-20% (5x11) 006-003000-50D C416,419,420 ELECT CAP 4.7 MFD/50V +-20% (5x11) 006-004000-50D C427 ELECT CAP 10 MFD/50V +-20% (5x11) 006-010000-50D C407,421 *CdF ELECT CAP 100 MFD/10V +-20% (VX/5x11)
-
Page 12: Alignment Set-Up Procedures
ALIGNMENT SET-UP PROCEDURES TUNER SECTION AM COIL T404 test point L404 R419 T401 L405 test point IC402 TC401 T402 CD1831T-02-01 1. AM IF Adjustment 4. FM Frequency Range Adjustment Test point: IC402 (TA2149BN) 16 PIN Test point: R419 Adjustmnet location: T402 Adjustment location: L404 T402 -------------------- 450kHz Set tuner frequency to be 87.5MHz. -
Page 13: Equipment Connection Diagrams
EQUIPMENT CONNECTION DIAGRAMS AM SECTION LOOP AM COIL 60cm R419 DIGITAL MULTMETER IC402 2CH AC VOLTMETER OSCILLOSCOPE AM/FM ST SG CASSETTE SECTION CN301 FREQUENCY COUNTER 2CH AC VOLTMETER... - Page 14 FM SECTION R419 IC402 DIGITAL MULTMETER FM ANT. 2CH AC VOLTMETER OSCILLOSCOPE AM/FM ST SG...
-
Page 15: Voltage Chart
VOLTAGE CHART THE MEASURED VALUE IS DC VOLTAGE UNIT: V TUNER SECTION TEST CONDITION: SET AM/FM TUNER ON ONE FREQUENCY IC401 (TC9257P) PIN'S NUMBER 2.32 2.42 4.15 4.15 0.35 0.30 4.92 2.29 2.39 4.15 4.15 4.71 1.22 4.69 PIN'S NUMBER 4.89 2.43 2.27... - Page 16 VOLTAGE CHART - CONTINUED IC801 (UTC8227P) PIN'S NUMBER 12.48 6.53 12.24 0.56 PIN'S NUMBER 0.56 6.72 12.53 6.72 12.70 CD & DISPLAY SECTION TEST CONDITION: CD PLAY IC101 (TA2109F) PIN'S NUMBER CD PLAY 4.11 1.74 1.74 1.78 2.84 2.03 PIN'S NUMBER CD PLAY 1.69 1.74...
-
Page 17: Ic Lead Identification And Internal Diagrams
IC LEAD IDENTIFICATION AND INTERNAL DIAGRAMS IC102 TA94A09F-202 V REF Clock gene. XV SS Data V REF slicer SLCO CD clock XV DD TMAX ZDET SERVO DV SR control V REF P2V REF VCOF DV RR PV REF DV DD LPFO DV RL Digital equailzer... - Page 18 IC103 TA2092N IC801 UTC8227P VCC2 VCC1 PW GND PW GND B.S.1 OUT(-)1 OUT(-)4 OUT1 CH-1 PV CC1 PV CC4 OUT(+)4 OUT(+)1 V IN4 BIAS CIRCUIT RIPPLE SV CC1 V RI THERMAL SHUT DOWN PROTECTION CIRCUIT SGND V IN3 OUT2 CH-2 OUT(+)2 OUT(+)3 B.S.2...
- Page 19 IC402 TA2149BN RFout RFin LPF1 LPF2 BUFF BUFF DECODE DIVIDE 1/1 or 1/16 BUFF BUFF LEVEL SW/MO FM/AM FMRF AMIF FMIF MUTE QUAD FM IF R-OUT L-OUT AM IF RFin IC301 LS22241 Channel2 Channel1 MUTE OUT1 Out2 IC802 L7805CV...
- Page 20 IC101 TA2109F 15k Ω Ω 15k Ω 10k Ω 7.67k Ω 5BAD 10k Ω µ 20 A 50k Ω 10k Ω 20pF 36pF 29k Ω 21k Ω 10k Ω 2VRO 7.96k Ω 10k Ω 24k Ω 24k Ω 3 STATE 21k Ω...
-
Page 21: Block Diagrams
BLOCK DIAGRAMS TUNER, CASSETTE & POWER AMP. SECTION... - Page 22 CD & DISPLAY SECTION...
-
Page 23: Exploded Drawing Parts List
EXPLODED DRAWING PARTS LIST Ref. No. Description Mfr's Part No. Qty. CASS DOOR LENS, MOLD TRANS, w/PNT (SAN) CAV:4 500-183213-xxx CASS DOOR COVER, MOLD C.GR 8C, (ABS) CAV:1, w/SPY & PNT 500-183204-xxx LCD-P-04D-4026SM021P TCM-2978A-011, 40x26x2.85mm LCD101 112-002978-001 TRANSMISSIVE/REFLECTIVE(TIAN-MA) CONTROL KNOB SET, MOLD L.GREY(420C) (ABS) CAV:2, w/SPY 510-183207-xxx KEY &... - Page 24 EXPLODED DRAWING PARTS LIST - CONTINUED Ref. No. Description Mfr's Part No. Qty. BATTERY DOOR, MOLD C.GREY 8C (HIPS) CAV:2 500-181105-001 SCREW ST3x10mm BB HEAD V5.9-6.3 BRASS BASED 720-110300-100 METAL WASHER Ø2.7xØ12.7x0.6mm 1/LEAF S/W 532-202712-760 METAL WASHER DIA:2.8/DIA:9.5x0.5mm 4/CD MECH 532-202809-550 *CdF SPONGE, 12x12x8mm WHITE 700-000001-020...
-
Page 25: Exploded Drawing
EXPLODED DRAWING... - Page 26 NOTES...
- Page 27 October, 2002 808-01832T-010 Printed in Hong Kong...
