REPLACEMENT PARTS LIST [AE-A07BE/A07BE-C]
REF. NO.
PART NO.
1- 1
PSEL-A345JBE0
1- 2
CMOTLA592JBE0
1- 3
NFANPA020JBEA
1- 4
PANGKA018JBP0
1- 5
PSKR-0106JBP0
1- 6
GPLTPA014JBFA
1- 7
CFTA-A261JBKZ
1- 7
CFTA-A271JBKZ
1- 8
PBOX-A351JBWZ
1- 9
GCAB-A105JBTA
1-10
GGADFA030JBEA
1-11
PSEL-C147JBE0
1-12
PSPF-A776JBEZ
1-12
PSPF-A833JBEZ
1-13
CPLT-A058JBKZ
1-14
TSPC-D660JBRZ
1-14
TSPC-E040JBRZ
1-15
TLABBA029JBRA
1-16
CCHS-A746JBTA
1-16
CCHS-A636JBTA
1-17
PSPF-A277JBE0
1-18
PSEL-A347JBE0
1-19
PSEL-A344JBE0
1-20
LBSHCA022JBF0
1-21
GPLTMA058JBTA
1-22
PSEL-C141JBEZ
1-23
PSEL-C142JBEZ
1-24
PSEL-C144JBEZ
1-25
PSEL-C071JBEZ
1-26
TLABCB411JBRZ
1-26
TLABCB572JBRZ
1-27
PSEL-C152JBEZ
1-28
PSEL-C145JBEZ
2- 1
RHOG-A186JBZZ
2- 2
LBNDKA062JBW0
2- 3
QW-IZA014JBZZ
2- 3
QW-IZA028JBZZ
2- 4
RC-HZA316JBE0
2- 4
RC-HZA301JBE0
2- 5
RC-HZA419JBZZ
2- 6
QTANZA003JBZZ
2- 7
LHLD-0261JBM0
3- 1
FCMPRA106JBKZ
3- 1
FCMPRA118JBKZ
3- 1-1
PCMPRA334JBEZ
3- 1-1
PCMPRA351JBEZ
3- 1-2
PSEL-B379JBE0
3- 1-2
PSEL-B172JBE0
3- 1-3
PSEL-B380JBE0
3- 1-3
PSEL-B722JBE0
3- 1-4
PCOV-A628JBEZ
3- 1-4
PCOV-A378JBE0
3- 1-5
GLEG-A097JBE0
3- 1-5
GLEG-A085JBE0
3- 1-6
LX-NZA164JBE0
3- 1-6
LX-NZA152JBE0
3- 2
PCON-A457JBPZ
3- 2
PCON-A476JBPZ
3- 3
DVLV-A189JBK0
3- 4
PSEN-A004JBK0
3- 5
LX-NZA033JBE0
3- 6
PPIPCB449JBE0
3- 7
DVLV-A212JBK0
3- 8
PSEN-A005JBK0
3- 9
LX-NZA034JBE0
3-10
CCIL-A098JBEZ
3-11
PCPY-A775JBPZ
3-11
PCPY-A883JBPZ
3-12
PCPY-A776JBPZ
3-12
PCPY-A884JBPZ
DESCRIPTION
CABINET AND UNIT PARTS
Cabinet seal
Fan motor
Propeller fan
Fan motor angle
Bulkhead
Left side cover
Terminal cover ass'y [AE-A07BE]
Terminal cover ass'y [AE-A07BE-C]
Control box
Cabinet
Fan guard
Seal
Compressor cover [AE-A07BE]
Compressor cover [AE-A07BE-C]
Side cover ass'y
Name label [AE-A07BE]
Name label [AE-A07BE-C]
SHARP badge
Base pan ass'y [AE-A07BE]
Base pan ass'y [AE-A07BE-C]
Angle seal
Angle seal
Condenser seal
Bushing
Side cover R
Insulator
Insulator
Insulator
Aluminum tape
Wiring diagram [AE-A07BE]
Wiring diagram [AE-A07BE-C]
Insulator
Insulator
CONTROL BOX PARTS
Protector
Capacitor clamp
Compressor cord [AE-A07BE]
Compressor cord [AE-A07BE-C]
Running capacitor [AE-A07BE]
Running capacitor [AE-A07BE-C]
Fan motor capacitor
Terminal board
Cord holder
CYCLE PARTS
Compressor ass'y(Including for Ref.No.2-1) [AE-A07BE]
Compressor ass'y(Including for Ref.No.2-1) [AE-A07BE-C]
Compressor [AE-A07BE]
Compressor [AE-A07BE-C]
Terminal gasket [AE-A07BE]
Terminal gasket [AE-A07BE-C]
Gasket washer [AE-A07BE]
Gasket washer [AE-A07BE-C]
Terminal cover [AE-A07BE]
Terminal cover [AE-A07BE-C]
Compressor cushion [AE-A07BE]
Compressor cushion [AE-A07BE-C]
Special nut [AE-A07BE]
Special nut [AE-A07BE-C]
Condenser [AE-A07BE]
Condenser [AE-A07BE-C]
2 Way valve ass'y
Flare nut assembly 1/4"
Valve cap
Check valve
3 way valve unit
Flare nut assembly 3/8"
Service cap
Coil
Capillary tube [AE-A07BE]
Capillary tube [AE-A07BE-C]
Capillary tube [AE-A07BE]
Capillary tube [AE-A07BE-C]
47
AH-A07BE-C/09BE-C
AH-A07BE/09BE/12BE
AY-A07BE-C/09BE-C
AY-A07BE/09BE/12BE
Q'TY
CODE
1
AK
1
BP
1
AW
1
AP
1
AM
1
AR
1
AS
1
AU
1
AK
1
BA
1
AY
1
AC
1
AT
1
AR
1
AW
1
AD
1
AD
1
AD
1
BF
1
BF
1
AK
2
AK
1
AK
1
AE
1
AV
1
AU
1
AU
1
AD
1
AC
1
AC
1
AC
1
AE
1
AC
1
AT
1
AD
1
AN
1
AP
1
AY
1
AX
1
AP
1
AR
1
AB
1
CC
1
CC
1
CB
1
CB
1
AN
1
AD
1
AG
1
AE
1
AK
1
AH
3
AF
3
AK
1
AE
1
AD
1
BS
1
BS
1
BA
1
AE
2
AF
1
AM
1
BB
1
AG
1
AD
1
AY
1
AK
1
AH
1
AK
1
AK
