PRODUCT OVERVIEW

SOUND BAR

WIRELESS SUBWOOFER

POWER/FM
BT AUX IN 1 AUX IN 2 OPTICAL
AUX IN 1 POWER SOURCE SCAN PAIR
ANT
R L
OPTICAL IN AUX IN 2 DC IN
1. INDICATORS
2. REMOTE SENSOR
3. AUX IN 1 JACK
4. VOLUME-
5. POWER BUTTON
Speakers
6. PLAY/PAUSE BUTTON
7. SOURCE BUTTON
8. SCAN BUTTON
9. VOLUME+
10. PAIR BUTTON
Indicator
DC IN 13 V
DC IN ( 13V ) Jack
POWER/FM
BT AUX IN 1
AUX IN 1
POWER SOURCE
5
3 4
ANT
OPTICAL IN
11 12
5
Speakers
AUX IN 2 OPTICAL
SCAN PAIR
9
8
7
6
R L
AUX IN 2 DC IN
13 14
11. ANTENNA
12. OPTICAL IN JACK
13. AUX IN 2 JACK
14. DC IN ( 18V )JACK
