Handset
Flash button
Handset jack
Figure 1. 8101 Telephone, Top View
Positive disconnect
Ringer
volume
SIDE VIEW
control
(Lo/Med/Hi)
Figure 2. 8101 Telephone, Side and Bottom Views
Data jack
Dial pad
TOP VIEW
(Off/On)
Mode
selector
(pulse/tone)
Labeling
designation
card
Redial button
Hold light
Hold button
Message light
Line jack
BOTTOM VIEW
