- Page 1 Performer 695 Assembly & User Manual model: SPPP-AE695 reference no. 55-4695U 10/08 1-IN-SPPP-AE695-UK/1.1...
-
Page 2: Introduction
Incorporating my AeroPilates routine into your life, at least three days a week and more if possible, will change your life as it has dramatically changed mine. -
Page 3: Table Of Contents
Contents Introduction ..............................2 General Information ............................3 Before You Start .............................. 4 Safety ................................4 Parts Identification ............................5 Assembly ................................. 6 Operation ................................ 9 Storage ................................. 10 Maintenance ..............................11 Parts Drawing ..............................12 Parts List ............................... 13 Order Form/Guarantee .......................... -
Page 4: Before You Start
This product is designed for indoor use in clean dry conditions. Do not store in cold or damp conditions as this may cause corrosion. It is recommended that two people move the AeroPilates. Attach one of the TENSION CORDS(10) in the slot on the FRONT FRAME(1) to prevent the CARRIAGE(7) from moving. Lift from the REAR FRAME(2) and use the Wheels(27) on the FRONT FRAME(1). -
Page 5: Parts Identification
Parts Identification Part no. Description Screw, Round Head (M5 x 0.8 x 35mm) Nylock Nut (M8 x 1.25) Washer (M8) Locking Knob Plastic Wheel Rubber Foot Components Left Pulley Hook Cushion m. Front Frame Pulley Riser b. Pulley Set Cardio Rebounder Tension Cord Rear Cover Front Cover... -
Page 6: Assembly
FRAME (1) with WASHERS (M8)(47) and NYLOCK NUTS (M8 X 1.25)(42). Step 3 Unfold your AeroPilates to a flat position by moving the FRONT FRAME(1) away from the platform end of the product in a clockwise position until fully extended. - Page 7 Assembly Step 7 Step 5, Note Step 4, 5, 6 and 7 Step 4 Remove the paper covering from the foam tape inside the FRONT COVER(3) and REAR COVER(4). Place the FRONT COVER(3) over the FRONT FRAME(1). Place the REAR COVER(4) over the REAR FRAME(2).
- Page 8 Assembly Step 8 Insert the FOAM SHOULDER PAD ASSEMBLIES(16) into the holes located on the CARRIAGE(7). Place the HAND STRAPS(20) onto the FOAM SHOULDER PAD ASSEMBLIES(16) for storage.
-
Page 9: Operation
Operation load adjustment The resistance of the CARRIAGE(7) can be adjusted by securing Slots the TENSION CORDS(10) in the slots located on the FRONT FRAME(1). You can achieve various levels of resistance by securing different numbers of the TENSION CORDS(10) in the slots. -
Page 10: Storage
Storage To store simply keep in a clean dry place. The AeroPilates can be folded as illustrated for easy storage. Step 1 Remove the LOCKING KNOBS(26) and CARDIO REBOUNDER(50), or the FOOTBAR(5), from the FRONT FRAME(1). Step 2 Remove the TENSION CORDS(10) from the slots on the FRONT FRAME(1). Move the CARRIAGE(7) back to the REAR FRAME(2). -
Page 11: Maintenance
Maintenance The safety and integrity designed into the AeroPilates can only be maintained when regularly examined for damage and wear. Special attention should be given to the following: It is the sole responsibility of the user/owner to ensure that regular maintenance is performed. -
Page 12: Parts Drawing
Parts Drawing Model no: 55-4695U Part code: 1-IN-SPPP-AE695-UK/1.1... -
Page 13: Parts List
Socket Wrench (not shown) ....................1 Manual (not shown) ......................1 Workout Chart (not shown) ....................1 AeroPilates Level 1 Workout DVD (not shown) ..............1 AeroPilates Cardio Workout DVD (not shown) ..............1 Rubber Foot ........................4 Model no: 55-4695U... -
Page 14: Order Form/Guarantee
On receipt of the completed guarantee registration slip below, The Dezac Group Limited will guarantee this product for two years against failure due to faulty workmanship or components. Please complete in block capitals. Model: AeroPilates Premier 695 Date of purchase: _____________ Purchased from: __________________...
